Right Rear Door Lock Inoperative – 2020 Ford F-150 & Super Duty

“This site contains affiliate links for which OEMDTC may be compensated”

NHTSA ID Number: 10181923

Manufacturer Communication Number: TSB 20-2359

Summary

Some 2020 F-150/F-Super Duty vehicles built on 18-May-2020 and through 30-Jun-2020 may exhibit a concern where the right rear door lock is inoperative but the manual lock rod works. This may be due to stack up tolerances of the handle, cable and latch. To correct the condition, follow the Service Procedure to remove the cable barrel sleeve.




2020 Ford F-Super Duty
2020 Ford F-Super Duty




Model:

Ford

2020 F-150

2020 Super Duty



Issue: Some 2020 F-150/F-Super Duty vehicles built on 18-May-2020 and through 30-Jun-2020 may exhibit a concern where the right rear door lock is inoperative but the manual lock rod works. This may be due to stack up tolerances of the handle, cable and latch. To correct the condition, follow the Service Procedure to remove the cable barrel sleeve.



Action: Follow the Service Procedure steps to correct the condition on vehicles that meet all of the following criteria:

  • 2020 F-150/F-Super Duty
  • Built on 18-May-2020 and through 30-Jun-2020
  • Right rear door lock inoperative
  • Manual lock rod operates



Parts

Description Quantity Part Number
Exterior Door Handle Cable Wiper Clip 1 LL3Z-15264B28-AeBay



Service Procedure

  1. Remove the right rear exterior door Refer to Workshop Manual (WSM), Section 501-14. Discard the cable wiper clip. (Figure 1)

Figure 1

cable wiper clip



  1. Remove the plastic sleeve from the barrel end of the cable and slide away from the barrel. (Figure 2)

Figure 2

plastic sleeve



CAUTION: Use caution to prevent damage to the cable in Step 3.



  1. Clip/cut the sleeve from the cable and discard the sleeve. (Figures 3-4)

Figure 3

Clip/cut the sleeve from the cable and discard the sleeve



Figure 4

Clip/cut the sleeve from the cable and discard the sleeve



  1. Reinstall the exterior door handle including the new exterior door handle cable wiper Refer to WSM, Section 501-14. (Figure 5)

Figure 5

Reinstall the exterior door handle including the new exterior door handle cable wiper clip




7 Affected Products

Vehicles

MAKE MODEL YEAR
FORD F-150 2020
FORD F-250 SD 2020
FORD F-350 SD 2020
FORD F-450 SD 2020
FORD F-550 SD 2020
FORD F-650 SD 2020
FORD F-750 SD 2020




1 Associated Document

Manufacturer Communications

20-2359
13 October 2020

https://www.nhtsa.gov/recalls?nhtsaId=10181923

MC-10181923-0001.pdf 523.719KB
