NHTSA ID Number: 10165703
Manufacturer Communication Number: TSB 19-2274
Summary
This article supersedes TSB 18-2268 to update the Service Procedure and the Parts List. Some 2017-2019 F-250/F-350 4WD vehicles may exhibit a sustained steering wheel oscillation after hitting rough pavement or an expansion joint above 72 Km/h (45 mph). This may be due to excessive lag/lash of the steering linkage damper. To correct the condition, follow the Service Procedure steps to replace the steering linkage damper. Follow the Service Procedure steps to correct the condition on vehicles that meet all of the following criteria: *2017-2019 F-250 and F-350 vehicles only *4WD *Customer complaint of sustained steering wheel oscillation after hitting rough pavement or an expansion joint above 72 Km/h (45 mph).
12 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| FORD | F-250 SD | 2017-2019 |
| FORD | F-350 SD | 2017-2019 |
| FORD | F-450 SD | 2017-2019 |
| FORD | F-550 SD | 2017-2019 |
This bulletin supersedes 18-2268. Reason for update: New Part/Procedure For Same Condition
Model:
2017-2019 F-Super Duty
Summary
This article supersedes TSB 18-2268 to update the Service Procedure and the Parts List.
Issue: Some 2017-2019 F-250/F-350 4WD vehicles may exhibit a sustained steering wheel oscillation after hitting rough pavement or an expansion joint above 72 Km/h (45 mph). This may be due to excessive lag/lash of the steering linkage damper. To correct the condition, follow the Service Procedure steps to replace the steering linkage damper.
Action: Follow the Service Procedure steps to correct the condition on vehicles that meet all of the following criteria:
- 2017-2019 F-250 and F-350 vehicles only
- 4WD
- Customer complaint of sustained steering wheel oscillation after hitting rough pavement or an expansion joint above 72 Km/h (45 mph)
Parts
| Description | Quantity | Part Number |
| Steering Linkage Damper | 1 | HC3Z-3E651-F |
Service Procedure
NOTE: With customer consent first, all aftermarket modifications to the chassis, steering and suspension systems should be removed prior to performing this service procedure. Removal of the aftermarket modifications is not warrantable.
- Is the customer complaint that the vehicle exhibits a sustained steering wheel oscillation after hitting rough pavement or an expansion joint at speeds above 72 Km/h (45 mph)?
(1). Yes – proceed to Step 2.
(2). No – this article does not apply. Refer to Workshop Manual (WSM), Section 204-00 for diagnosis.
- Check and adjust the tire pressure as indicated on the driver’s door placard.
- Obtain a new steering linkage damper. Check the steering linkage damper package date code (Figure 1). Does the package date code indicate a package date on or after 01-May-2018?
(1). Yes – replace the steering linkage damper. Refer to WSM Section 211-03.
(2). No – repeat Step 3 until a new steering linkage damper is received with a package date code on or after 01-May-2018.
SEOCONTENT-START
TECHNICAL SERVICE BULLETIN
4-Wheel Drive (4WD) – Sustained Steering Wheel Oscillation –
Above 72 Km/h (45 Mph)
Labor Times
Description
Operation
No.
Time
2017-2019 F-Super Duty 4X4 250/350: Inspect The Vehicle, Set Tire Pressure,
Replace The Steering Linkage Damper (Do Not Use With Any Other Labor
Operations)
192274A 0.4
Hrs.
Repair/Claim Coding
Causal Part: 3E651
Condition Code: 42
19-2274
10 September 2019
https://www.nhtsa.gov/recalls?nhtsaId=10165703
https://static.nhtsa.gov/odi/tsbs/2019/MC-10165703-0001.pdf
Loading...
Reload document
Open in new tab
18-2268
31 August 2018
https://www.nhtsa.gov/recalls?nhtsaId=10149747
https://static.nhtsa.gov/odi/tsbs/2018/MC-10149747-9999.pdf
