16B32 – Electronic Throttle Body Replacement – 2015-2016 Ford & Lincoln

“This site contains affiliate links for which OEMDTC may be compensated”

October 27, 2016

TO: All U.S. Ford and Lincoln Dealers

SUBJECT: NEW VEHICLE DEMONSTRATION / DELIVERY HOLD – Customer Satisfaction Program 16B32 – Supplement #1
Certain 2015 Model Year Edge, 2015-2016 Model Year F-150, MKT, and Police
Interceptor Sedan, and 2016 Model Year Escape, Explorer, Flex, Fusion, MKX,
Mustang, Police Interceptor Utility, Taurus, and Transit Vehicles
Electronic Throttle Body Replacement

REF: NEW VEHICLE DEMONSTRATION / DELIVERY HOLD – Customer Satisfaction Program 16B32
Dated: September 14, 2016



New! REASON FOR THIS SUPPLEMENT

Service Action Update:  All vehicles in this program are to receive an Electronic Throttle Body (ETB) replacement.  Powertrain Control Module (PCM) reprogramming is no longer required.  Vehicles that previously received a PCM reprogram are now eligible for ETB replacement under this program and are identified in OASIS.



PROGRAM TERMS

This program will be in effect through September 30, 2017.  There is no mileage limit for this program.



URGENCY / EXPIRATION DATE

This Customer Satisfaction Program has an expiration date of September 30, 2017 to encourage dealers and customers to have this service performed as soon as possible.



AFFECTED VEHICLES

Vehicle Model Year Assembly Plant Build Dates
Edge 2015 Oakville September 1, 2015 through December 21, 2015
F-150 2015-2016 Dearborn August 1, 2015 through May 17, 2016
Kansas City August 31, 2015 through April 27, 2016
MKT Oakville September 1, 2015 through May 10, 2016
Police Interceptor Sedan Chicago September 1, 2015 through March 19, 2016
Escape 2016 Louisville September 1, 2015 through March 14, 2016
Explorer Chicago August 4, 2015 through May 25, 2016
Flex Oakville September 22, 2015 through April 14, 2016
Fusion Flat Rock September 1, 2015 through February 29, 2016
Hermosillo September 1, 2015 through April 4, 2016
MKX Oakville September 1, 2015 through May 16, 2016
Mustang 2016 Flat Rock September 1, 2015 through April 26, 2016
Police Interceptor Utility Chicago September 1, 2015 through May 26, 2016
Taurus Chicago September 28, 2015 through May 2, 2016
Transit Kansas City September 1, 2015 through May 21, 2016



Affected vehicles are identified in OASIS and FSA VIN Lists.



REASON FOR THIS PROGRAM

In all of the affected vehicles, the electronic throttle body internal motor contacts may develop contamination resulting in increased electrical resistance.  If this condition is present, the malfunction indicator lamp will illuminate, diagnostic trouble codes P2111 and P2112 will set, and the vehicle may enter a Failure Mode Effects Management (FMEM) of default throttle position with fixed RPM.  In this mode, while engine power and vehicle speed are reduced, the power steering, power braking, lighting, and climate control systems remain fully functional.



New! SERVICE ACTION

Before demonstrating or delivering any new in-stock vehicles involved in this program, dealers are to replace the ETB.  This service must be performed on all affected vehicles at no charge to the vehicle owner.

NOTE:  Vehicles that previously received a PCM reprogram are now eligible for ETB replacement under this program and are identified in OASIS.



New! OWNER NOTIFICATION MAILING SCHEDULE

Owner letter mailing began the week of October 10, 2016, and is expected to be completed the week of October 31, 2016.  Dealers should repair any affected vehicles that arrive at their dealerships, whether or not the customer has received a letter.



New! ATTACHMENTS

Attachment I: Administrative Information
Attachment II: Labor Allowances and Parts Ordering Information
Attachment III: Technical Information
Owner Notification Letters



QUESTIONS & ASSISTANCE

For questions and assistance, contact the Special Service Support Center (SSSC) via the SSSC Web Contact Site.  The SSSC Web Contact Site can be accessed through the Professional Technician Society (PTS) website using the SSSC link listed at the bottom of the OASIS VIN report screen or listed under the SSSC tab.

Sincerely,



Michael A. Berardi



ATTACHMENT I

DEMONSTRATION / DELIVERY HOLD – Customer Satisfaction Program 16B32 – Supplement #1
Certain 2015 Model Year Edge, 2015-2016 Model Year F-150, MKT, and
Police Interceptor Sedan, and 2016 Model Year Escape, Explorer, Flex, Fusion,
MKX, Mustang, Police Interceptor Utility, Taurus, and Transit Vehicles
Electronic Throttle Body Replacement



OASIS ACTIVATION

OASIS will be activated on September 14, 2016.



FSA VIN LISTS ACTIVATION

FSA VIN Lists will be available through https://web.fsavinlists.dealerconnection.com on September 14, 2016.  Owner names and addresses will be available by November 10, 2016.

NOTE:  Your FSA VIN Lists may contain owner names and addresses obtained from motor vehicle registration records.  The use of such motor vehicle registration data for any purpose other than in connection with this program is a violation of law in several states, provinces, and countries.  Accordingly, you must limit the use of this listing to the follow-up necessary to complete this service action.



SOLD VEHICLES

  • Owners of affected vehicles will be directed to dealers for repairs.
  • Immediately contact any of your affected customers whose vehicles are not on your VIN list but are identified in OASIS. Give the customer a copy of the Owner Notification Letter (when available) and schedule a service date.
  • Correct other affected vehicles identified in OASIS which are brought to your dealership.
  • Dealers are to prioritize repairs of customer vehicles over repairs of new and used vehicle inventory.



STOCK VEHICLES

  • Correct all affected units in your new vehicle inventory before delivery.
  • Use OASIS to identify any affected vehicles in your used vehicle inventory.



TITLE BRANDED / SALVAGED VEHICLES

Affected title branded and salvaged vehicles are eligible for this service action.



ADDITIONAL REPAIR (LABOR TIME AND/OR PARTS)

Additional repairs identified as necessary to complete the FSA should be managed as follows:

  • For vehicles within new vehicle bumper-to-bumper warranty coverage, follow existing warranty and policy guidelines for related damage claims. No SSSC approval is required for these vehicles:
    • Ford vehicles – 3 years or 36,000 miles o Lincoln vehicles – 4 years or 50,000 miles
  • For vehicles outside new vehicle bumper-to-bumper warranty coverage, submit an Approval Request to the SSSC Web Contact Site prior to completing the repair.



New! OWNER REFUNDS

  • Ford Motor Company is offering a refund for owner-paid repairs covered by this program if the repair was performed before the date of the Owner Notification Letter. This refund offer expires March 14, 2017.
  • Dealers are also pre-approved to refund owner-paid emergency repairs that were performed away from an authorized servicing dealer after the date of the Owner Notification Letter. There is no expiration date for emergency repair refunds.  Non-covered repairs, or those judged by Ford to be excessive, will not be reimbursed.
  • Refunds will only be provided for the cost associated with electronic throttle body replacement.



RENTAL VEHICLES

The use of rental vehicles is not approved for this program.



LINCOLN CLIENT SPECIAL HANDLING

To ensure the best possible experience for Lincoln owners, Lincoln Dealers are encouraged to utilize the Lincoln Loyalty Program to provide clients with surprise and delight offerings, such as:

  • Fuel fill
  • Gift Card for the client’s favorite restaurant
  • Transportation assistance
  • Courtesy pick-up and delivery of client vehicles

The Lincoln Loyalty Program is exclusive to Lincoln Dealers.  Owners will not be notified of this service in owner mailings.  Reference EFC04453, Lincoln Loyalty Program Announcement for additional details.



New! CLAIMS PREPARATION AND SUBMISSION

  • Enter claims using Direct Warranty Entry (DWE) or One Warranty Solution (OWS).
    • DWE: refer to ACESII manual for claims preparation and submission information.
    • OWS: when entering claims in DMS software, select claim type 31: Field Service Action. The FSA number (16B32) is the sub code.
  • Additional labor and/or parts must be claimed as related damage on a separate repair line from the FSA.
  • Submit refunds on a separate repair line.
    • Program Code: 16B32                   –  Expense:  ADMIN
    • Expense: REFUND  –  Misc. Expense:  0.2 Hrs.
  • Multiple refunds should be submitted on one repair line and the invoice details for each repair should be detailed in the comments section of the claim.
  • PROGRAM TERMS: This program will be in effect through September 30, 2017.  There is no mileage limit for this program.
  • For Lincoln Client Special Handling, reference EFC04453, Lincoln Loyalty Program Announcement and EFC04165, Lincoln Loyalty Rental Claims for Requirements and Claiming Instructions.  Claims for Lincoln Loyalty should be submitted as a separate line on the same Repair Order.
  • Claims for PCM reprogramming under labor operation code 16B32D must have a repair date on or before November 4, 2016 to be eligible for payment.



ATTACHMENT II

DEMONSTRATION / DELIVERY HOLD – Customer Satisfaction Program 16B32 – Supplement #1
Certain 2015 Model Year Edge, 2015-2016 Model Year F-150, MKT, and
Police Interceptor Sedan, and 2016 Model Year Escape, Explorer, Flex, Fusion,
MKX, Mustang, Police Interceptor Utility, Taurus, and Transit Vehicles
Electronic Throttle Body Replacement



New! LABOR ALLOWANCES

Description Labor Operation Labor Time
Replace ETB – Escape, F-150, Fusion, Mustang, and Transit 16B32B 0.5 Hours
Replace ETB – Edge, Explorer, Flex, MKT, MKX, Police Interceptor Sedan, Police Interceptor Utility, and Taurus   16B32C 0.6 Hours



NOTE:  Claims for PCM reprogramming under labor operation code 16B32D must have a repair date on or before November 4, 2016 to be eligible for payment.



New! PARTS REQUIREMENTS / ORDERING INFORMATION

Part Number Description Order Quantity
AT4Z-9E926-B 16B32 - Electronic Throttle Body Replacement - 2015-2016 Ford & Lincoln | small light Electronic throttle body Edge, Explorer, F-150, Flex, MKT,

MKX, Mustang, Police Interceptor Sedan, Police Interceptor

Utility, Taurus, and Transit vehicles

1
DS7Z-9E926-D 16B32 - Electronic Throttle Body Replacement - 2015-2016 Ford & Lincoln | small light Electronic throttle bodyEscape and Fusion vehicles 1



The DOR/COR number for this program is 51054.

Order your parts requirements through normal order processing channels.  To guarantee the shortest delivery time, an emergency order for parts must be placed.



DEALER PRICE

For latest prices, refer to DOES II.



PARTS RETENTION AND RETURN

Follow the provisions of the Warranty and Policy Manual, Section 1 – WARRANTY PARTS RETENTION AND RETURN POLICIES.



EXCESS STOCK RETURN

Excess stock returned for credit must have been purchased from Ford Customer Service Division in accordance with Policy Procedure Bulletin 4000.



ATTACHMENT III

CERTAIN 2015 MODEL YEAR EDGE, 2015-2016 MODEL YEAR F-150, MKT, AND POLICE INTERCEPTOR SEDAN, AND 2016 MODEL YEAR ESCAPE, EXPLORER, FLEX, FUSION, MKX, MUSTANG , POLICE INTERCEPTOR UTILITY, TAURUS , AND TRANSIT VEHICLES — ELECTRONIC THROTTLE BODY REPLACEMENT



OVERVIEW

In all of the affected vehicles, the electronic throttle body (ETB) internal motor contacts may develop contamination resulting in increased electrical resistance. If this condition is present, the malfunction indicator lamp will illuminate, diagnostic trouble codes (DTCs) P2111 and P2112 will set, and the vehicle may enter a Failure Mode Effects Management (FMEM) of default throttle position with fixed RPM. In this mode, while engine power and vehicle speed are reduced, the power steering, power braking, lighting, and climate control systems remain fully functional. Dealers are to replace the ETB.



SERVICE PROCEDURE

Electronic Throttle Body Replacement

  1. Replace the electronic throttle body. Please follow the Workshop Manual (WSM) procedure in Section 303-04.



November, 2016

Customer Satisfaction Program 16B32
Programa de satisfacción del cliente 16B32



Mr. John Sample
123 Main Street
Anywhere, USA 12345



Your Vehicle Identification Number (VIN):  12345678901234567

At The Lincoln Motor Company, we are committed not only to building high quality, dependable products, but also to building a community of happy, satisfied customers. To demonstrate that commitment, we are providing a no-charge Customer Satisfaction Program for your vehicle with the VIN shown above.

Why are you receiving this  notice? On your vehicle, the electronic throttle body may develop contamination and result in the vehicle entering a protective low-speed mode accompanied by illumination of the service engine soon indicator (shown to the left).  In this mode, while engine power and vehicle speed are reduced, the power steering, power braking, lighting, and climate control systems remain fully functional.
What will Lincoln and your dealer do? In the interest of customer satisfaction, The Lincoln Motor Company has authorized your dealer to replace the electronic throttle body free of charge (parts and labor) under the terms of this program.
How long will it take? The time needed for this repair is less than one-half day.  However, due to service scheduling requirements, your dealer may need your vehicle for a longer period of time.
What should you do? Please call your dealer without delay and request a service date for Customer Satisfaction Program 16B32. Provide the dealer with the VIN of your vehicle.  The VIN is printed near your name at the beginning of this letter.

If you do not already have a servicing dealer, you can access www.Lincolnowner.com for dealer addresses, maps, and driving instructions.

The Lincoln Motor Company wants you to have this service action completed on your vehicle.  The vehicle owner is responsible for making arrangements to have the work completed.

Your vehicle may be equipped with a diagnostic feature called the Vehicle Health Report which can inform you about all available recalls, as well as other key vehicle health information. Please see https://owner.lincoln.com/vehicle-health for more information.



Have you previously paid for this repair? If you have previously paid for a repair that addresses the issue described in this letter, you still need to have this service action performed to ensure the correct parts were used.

If the previously paid for repair was performed before the date of this letter, you may be eligible for a refund.  Refunds will only be provided for service related to electronic throttle body replacement.  To verify eligibility and expedite reimbursement, give your paid original receipt to your dealer before March 14, 2017.  To avoid delays, do not send receipts to The Lincoln Motor Company.

What if you no longer own this vehicle? If you no longer own this vehicle, and have an address for the current owner, please forward this letter to the new owner.

You received this notice because our records, which are based primarily on state registration and title data, indicate that you are the current owner.

Can we assist you further? If you have difficulties getting your vehicle repaired promptly and without charge, please contact your dealership’s Service Manager for assistance.

RETAIL OWNERS:  If you have questions or concerns, please contact our Ford Customer Relationship Center at 1-866-436-7332 and one of our representatives will be happy to assist you. If you wish to contact us through the Internet, our address is:  www.Lincolnowner.com.

For the hearing impaired call 1-800-232-5952 (TDD).  Representatives are available Monday through Friday:  8:00AM – 8:00PM (Eastern Time).

FLEET OWNERS:  If you have questions or concerns, please contact our Fleet Customer Information Center at 1-800-34-FLEET, choose Option #3, and one of our representatives will be happy to assist you.  If you wish to contact us through the Internet, our address is:  www.fleet.ford.com.

Representatives are available Monday through Friday:  8:00AM – 8:00PM (Eastern Time).

Para asistencia en Español Visite nuestro sitio web para ver este anuncio en Español al siguiente dirección: https://es.owner.lincoln.com/recall.

Si necesita ayuda o tiene alguna pregunta, por favor llame al Centro de Relación con Clientes al 1-866-436-7332 y presione 2 para Español.



Thank you for your attention to this important matter.

The Lincoln Motor Company



November, 2016

Customer Satisfaction Program 16B32
Programa de satisfacción del cliente 16B32



Mr. John Sample
123 Main Street
Anywhere, USA 12345



Your Vehicle Identification Number (VIN):  12345678901234567

At Ford Motor Company, we are committed not only to building high quality, dependable products, but also to building a community of happy, satisfied customers. To demonstrate that commitment, we are providing a no-charge Customer Satisfaction Program for your vehicle with the VIN shown above.

Why are you receiving this  notice? On your vehicle, the electronic throttle body may develop contamination and result in the vehicle entering a protective low-speed mode accompanied by illumination of the service engine soon indicator (shown to the left).  In this mode, while engine power and vehicle speed are reduced, the power steering, power braking, lighting, and climate control systems remain fully functional.
What will Ford and your dealer do? In the interest of customer satisfaction, Ford Motor Company has authorized your dealer to replace the electronic throttle body free of charge (parts and labor) under the terms of this program.

This Customer Satisfaction Program will be in effect until September 30, 2017, regardless of mileage.  Coverage is automatically transferred to subsequent owners.

How long will it take? The time needed for this repair is less than one-half day.  However, due to service scheduling requirements, your dealer may need your vehicle for a longer period of time.
What should you do? Please call your dealer without delay and request a service date for Customer Satisfaction Program 16B32.  Provide the dealer with the VIN of your vehicle.  The VIN is printed near your name at the beginning of this letter.

If you do not already have a servicing dealer, you can access www.Fordowner.com for dealer addresses, maps, and driving instructions.

Ford Motor Company wants you to have this service action completed on your vehicle.  The vehicle owner is responsible for making arrangements to have the work completed.

Your vehicle may be equipped with a diagnostic feature called the Vehicle Health Report which can inform you about all available recalls, as well as other key vehicle health information. Please see https://owner.ford.com/vehicle-health for more information.

Have you previously paid for this repair? If you have previously paid for a repair that addresses the issue described in this letter, you still need to have this service action performed to ensure the correct parts were used.

If the previously paid for repair was performed before the date of this letter, you may be eligible for a refund.  Refunds will only be provided for service related to electronic throttle body replacement.  To verify eligibility and expedite reimbursement, give your paid original receipt to your dealer before March 14, 2017.  To avoid delays, do not send receipts to Ford Motor Company.

What if you no longer own this vehicle? If you no longer own this vehicle, and have an address for the current owner, please forward this letter to the new owner.

You received this notice because our records, which are based primarily on state registration and title data, indicate that you are the current owner.

Can we assist you further? If you have difficulties getting your vehicle repaired promptly and without charge, please contact your dealership’s Service Manager for assistance.

RETAIL OWNERS:  If you have questions or concerns, please contact our Ford Customer Relationship Center at 1-866-436-7332 and one of our representatives will be happy to assist you.  If you wish to contact us through the Internet, our address is:  www.Fordowner.com.

For the hearing impaired call 1-800-232-5952 (TDD).  Representatives are available Monday through Friday:  8:00AM – 8:00PM (Eastern Time).

FLEET OWNERS:  If you have questions or concerns, please contact our Fleet Customer Information Center at 1-800-34-FLEET, choose Option #3, and one of our representatives will be happy to assist you.  If you wish to contact us through the Internet, our address is:  www.fleet.ford.com.

Representatives are available Monday through Friday:  8:00AM – 8:00PM(Eastern Time).

Para asistencia en Español Visite nuestro sitio web para ver este anuncio en Español al siguiente dirección: https://es.owner.ford.com/recall.

Si necesita ayuda o tiene alguna pregunta, por favor llame al Centro de Relación con Clientes al 1-866-436-7332 y presione 2 para Español.



Thank you for your attention to this important matter.

Ford Customer Service Division
