NHTSA ID Number: 10236029
Manufacturer Communication Number: SSM 51601
Summary
Some 2021-2023 F-150 and 2022-2023 F-Super Duty/Expedition/Navigator/Maverick vehicles equipped with an integrated trailer module (iTRM) may exhibit a trailer lamp fault message with various related diagnostic trouble codes (DTC). Most trailer emulator testers will not draw enough current to correctly diagnose these concerns. They may be used to diagnose basic functionality of the iTRM, however, some trailer emulator testers may cause false trailer lamp fault messages to appear. The customer’s trailer should be used for diagnosis instead of a trailer emulator tester. Refer to Workshop Manual (WSM), Section 417-01 for normal diagnostics.
22 Affected Products
Vehicles
MAKE | MODEL | YEAR |
FORD | EXPEDITION | 2022-2023 |
FORD | F-150 | 2021-2023 |
FORD | F-250 SD | 2022-2023 |
FORD | F-350 SD | 2022-2023 |
FORD | F-450 SD | 2022-2023 |
FORD | F-550 SD | 2022-2023 |
FORD | F-600 SD | 2022 |
FORD | F-650 SD | 2022-2023 |
FORD | F-750 SD | 2022-2023 |
FORD | MAVERICK | 2022-2023 |
LINCOLN | NAVIGATOR | 2022-2023 |
1 Associated Document
Manufacturer Communications
SSM 51601
2022-2023 Expedition (U553) (B8)
2021-2023 F-150 (P702) (FD)
2022 F-Super Duty (P558) NA (FE)
2023 F-Super Duty (P708) (FH)
2022-2023 Maverick (P758N) (FE)
2022-2023 Navigator (U554) (B9
2021-2023 – Various Vehicles – Trailer Lamp Fault With Various DTCs
