NHTSA ID Number: 10242845
Manufacturer Communication Number: TSB 23-2072
Summary
Some 2020-2023 Explorer/Aviator all-wheel drive (AWD) vehicles with a hybrid powertrain may experience a harshness and/or vibration felt through the seat, steering wheel and/or center console at 25-50 mph (40-80 km/h). This may be due to constant velocity (CV) joint instability at dynamic angles close to zero. To correct the condition, follow the Service Procedure to install a driveline shim.
Model:
Issue: Some 2020-2023 Explorer/Aviator all-wheel drive (AWD) vehicles with a hybrid powertrain may experience a harshness and/or vibration felt through the seat, steering wheel and/or center console at 25-50 mph (40-80 km/h). This may be due to constant velocity (CV) joint instability at dynamic angles close to zero. To correct the condition, follow the Service Procedure to install a driveline shim.
Action: Follow the Service Procedure to correct the condition on vehicles that meet all of the following criteria:
- 2020-2023 Explorer/Aviator
- AWD
- Hybrid
- Driveline vibration at 25-50 mph (40-80 km/h) felt through the seat, steering wheel and/or center console
Parts
| Service Part Number | Quantity | Description | Unit of Issue | Piece Quantity |
| W722615-S439 | 1 | Shim | 4 | 2 |
W719768-S439 | 1 | Bolt | 4 | 2 |
Quantity refers to the amount of the service part number required to repair the vehicle.
Unit of Issue refers to the number of individual pieces included in a service part number package.
Piece Quantity refers to the total number of individual pieces required to repair the vehicle.
Service Procedure
1. Remove one of the driveshaft center bearing bolts. Do not remove or loosen both bolts at the same time.
2. Insert the shim between the driveshaft center bearing bracket and the body where the bolt was removed (Figures 1-2).
Figure 1
Figure 2
3. Install the longer driveshaft center bearing bracket bolt
4. Hand-tighten the driveshaft center bearing bracket bolt.
5. Repeat Steps 1-4 for the other driveshaft center bearing bracket bolt.
NOTE: Do not remove the driveshaft.
6. Tighten the new longer driveshaft center bearing bracket bolts to 35 lb-ft (48 Nm). Refer to Workshop Manual (WSM) Section 205-01.
8 Affected Products
Vehicles
1 Associated Document
Manufacturer Communications
23-2072
19 September 2023
MC-10242845-0001.pdf 107.101KB
Loading...
Reload document
Open in new tab
