NHTSA ID Number: 10204997
Manufacturer Communication Number: TSB160032
Summary
4R75E Transmission – Grinding/Whine/Vibration/Gear Slippage – Service Kit available
FORD:
2008-2010 E-150, E-250, E-350, F-150
2008-2011 Crown Victoria
2013-2014 E-150, E-250, E-350
2008 Mark LT
2008-2011 Town Car
2008-2011 Grand Marquis
This article supersedes TSB 15-0179 to update the Service Labor Time Standards.
ISSUE:
A service kit has been released to assist with proper repair of the 4R75E transmission in 2008 Mark LT, 2008-2010 F-150, 2008-2010 / 2013-2014 E-Series, 2008-2011 Crown Victoria, Grand Marquis and Town Car vehicles that exhibit a grinding, whine-type noise, vibration and/or gear slippage while driving, or a loss of reverse resulting from a planetary gear assembly failure.
ACTION:
Follow the Service Procedure steps to correct the condition.
SERVICE PROCEDURE
1. Connect the Ford Integrated Diagnostic System (IDS) or equivalent service tool to the data link connector (DLC). Retrieve all diagnostic trouble codes (DTCs) and record.
(1). The following DTCs may be present: P0733, P0720, P0722, P0731, P1783, P0732, P0734, P0721, P0297, P0781, P0782, P1728, P1715, P1744, P1783, P0741, P1741, P1742 and/or P1743.
2. Remove the transmission fluid pan. Refer to Workshop Manual (WSM), Section 307-01.
3. Inspect the transmission fluid pan magnet for debris.
(1). If metallic debris is present, proceed to Step 4.
(2). If little or no metallic debris is present or if blackened friction material is present, this article does not apply. Refer to WSM, Section 307-01 for normal diagnosis.
4. Install transmission fluid pan, remove transmission and disassemble. Refer to WSM, Section 307-01.
(1). If cost cap directs transmission repair, proceed to Step 5.
(2). If cost cap directs transmission replacement, proceed to Step 10.
5. Clean all internal components thoroughly. Replace any friction material which have metal pieces embedded.
6. Disassemble and clean the main control valve body. Refer to WSM, Section 307-01.
7. Assemble the transmission using the parts provided in the service kit. Be certain to perform steps to determine number 1 thrust washer thickness. Refer to WSM, Section 307-01.
(1). Service kit contains seals and gaskets for all 4R75 models. Match up all removed seals and gaskets. Some seals and gaskets in the kit will not be required for certain models. Discard any unused components.
8. Were any of the following DTCs present in Step 1: P0741, P1741, P1742, P1743?
(1). No – proceed to Step 9.
(2). Yes – replace the torque convertor and proceed to Step 10.
9. Place the torque converter assembly on the bench and drain the old fluid. Refill with fresh transmission fluid and drain again. Repeat until clean oil is present when draining.
10. Perform transmission fluid cooler back flushing and cleaning. Refer to WSM, Section 307-01.
(1). The transmission fluid cooler on Crown Victoria, Grand Marquis and Town Car vehicles cannot be flushed due to an internal thermostatic bypass valve. These vehicles require replacement of the transmission fluid cooler (A/C condenser assembly). Refer to WSM, Section 307-02.
11. Install the transmission. Refer to WSM, Section 307-01.
| PART NUMBER | PART NAME |
| AL3Z-7A398-C | Planetary Upgrade Kit |
378941-441  |
Nut – Converter (4 req.) |
| 56142-S439 | Exhaust Bolts – Crown Vic / Grand Mar / Town Car (4 req.) |
| 391188-S441 | Exhaust Flange Nuts – Crown Vic / Grand Mar / Town Car (4 req.) |
| N800594-S100 |
Driveshaft Fasteners – Except Econoline |
| N811880-100 | Driveshaft Fasteners – Econoline |
| XL-5-A |
Motorcraft Multi-Purpose Grease Spray |
| XG-1-E1 |
Motorcraft Premium Long-Life Grease |
| XT-10-QLVC |
Motorcraft MERCON LV Automatic Transmission Fluid (2009-2012 MY) |
| XT-5-QMC |
Motorcraft MERCON V Automatic Transmission And Power Steering Fluid (2008 MY) |
TA-25-B |
Motorcraft Threadlock and Sealer |
| XL-12 |
Motorcraft Transfer Case Fluid |
| 56761-S439 |
Bolt – Two Piece Driveshaft – Econoline Center Bearing |
| W711116-S439 | Bolt – 2008 F-150 Multi-piece Driveshaft Center Bearing |
| 7L1Z-4B496-C |
Front Driveshaft Fasteners – 2009-2010 F-150 4X4 (2 req.) |
| 7L1Z-4B496-D |
Front Driveshaft Fasteners – 2009-2010 F-150 4X4 (3 req.) |
| W716375-S900 |
Transfer Case Bolts – 2009-2010 F-150 4X4 (9 req) |
| E7TZ-7086-A |
Gasket – Transfer Case |
| BW7Z-19712-A |
A/C Condenser-Cooler – Crown Victoria/Grand Marquis/Town Car |
| 7902 | Torque Converter Assembly – See The Dealer Catalog For Proper Replacement Part |
| 7000 | Transmission Assembly – See The Dealer Catalog For Proper Replacement Part |
31 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| FORD | CROWN VICTORIA | 2008-2011 |
| FORD | E-150 | 2008-2010, 2013-2014 |
| FORD | E-250 | 2008-2010, 2013-2014 |
| FORD | E-350 | 2008-2010, 2013-2014 |
| FORD | F-150 | 2008-2010 |
| LINCOLN | MARK LT | 2008 |
| LINCOLN | TOWN CAR | 2008-2011 |
| MERCURY | GRAND MARQUIS | 2008-2011 |
1 Associated Document
Manufacturer Communications
TSB 16-0032
https://www.nhtsa.gov/recalls?nhtsaId=10204997
MC-10204997-9999.pdf 109.688KB
Loading...
Reload document
Open in new tab
