Deployable Rear Cup Holder Inoperative Or Broken

“This site contains affiliate links for which OEMDTC may be compensated”

NHTSA ID Number: 10187947

Manufacturer Communication Number: SSM 49626

Summary

Some 2018-2020 Navigator vehicles may exhibit an inoperative or broken second row deployable cup holder which is located on the rear side of the front floor console. The deployable cup holder part (service base part number 7813562 ) is now available separately as a lower-level service part. Refer to Workshop Manual (WSM), Section 415-00 > Rear Audio Control Module (RACM) for the procedure to remove the floor console rear trim panel. When installing the screws on the cup holder and carrier, tighten to 1.1 +/-0.2 Nm (9.7 +/-1.8 lb-in).

3 Affected Products

Vehicle

MAKE	MODEL	YEAR

LINCOLN	NAVIGATOR	2018-2020

APPLICABLE VEHICLES

2018 – 2020 TRUCK: B9 U554N NAVIGATOR

1 Associated Document

Manufacturer Communications

SSM 49626 – 2018-2020 Navigator – Deployable Rear Cup Holder Inoperative Or Broken

https://www.nhtsa.gov/recalls?nhtsaId=10187947

MC-10187947-0001.pdf 115.502KB

Taking too long?

Reload document

Open in new tab

Download [112.79 KB]
