Uneven And/Or Excessive Gap Between The Center Tray/Upfitter Switch Assembly And The Instrument Panel Topper – 2019-2022 Ford Ranger

“This site contains affiliate links for which OEMDTC may be compensated”

NHTSA ID Number: 10207137

Manufacturer Communication Number: SSM 50442

Summary

Some 2019-2022 Ranger vehicles may experience an uneven and/or excessive gap existing between the instrument panel (IP) topper and the center tray/upfitter switch assembly. This may be due to a lack of rigidity in the IP topper not allowing the tray/upfitter switch assembly to latch properly. The following foam block service kits should be used to correct this condition. For vehicles equipped with an IP tray, order service part # KB3Z-2104338-AG, which includes a new IP tray and foam blocks. For vehicles equipped with the upfitter switch assembly, order service part # KB3Z-2104338-A, which only includes the foam blocks. If a new upfitter switch assembly is required, this must be ordered separately. Follow the installation instructions included with each kit to install the foam blocks and repair the vehicle.




2022 Ford Ranger
2022 FordeBay Ranger




APPLICABLE VEHICLES

2019 – 2022 TRUCK: FG P375N RANGER




4 Affected Products

Vehicle

MAKEMODELYEAR
FORDeBayRANGER2019-2022




1 Associated Document

Manufacturer Communications

SSM 50442 – 2019-2022 Ranger – Uneven And/Or Excessive Gap Between The Center Tray/UpfitterSwitch Assembly And The Instrument Panel Topper

MC-10207137-0001.pdf 115.481KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [112.77 KB]




NHTSA ID Number: 10204039

Manufacturer Communication Number: SSM 50305

Summary

Some 2019-2021 Ranger vehicles may experience an uneven and/or excessive gap existing between the instrument panel (IP) topper and the center tray/upfitter switch assembly. This may be due to a lack of rigidity in the IP topper not allowing the tray/upfitter switch assembly to latch properly. The following foam block service kits should be used to correct this condition. For vehicles equipped with an IP tray, order service part # KB3Z-2104338-AG, which includes a new IP tray and foam blocks. For vehicles equipped with the upfitter switch assembly, order service part # KB3Z-2104338-A, which only includes the foam blocks. If a new upfitter switch assembly is required, this must be ordered separately. Follow the installation instructions included with each kit to install the foam blocks and repair the vehicle.





1 Associated Document

Manufacturer Communications

SSM 50305 – 2019-2021 Ranger – Uneven And/Or Excessive Gap Between The Center Tray/Upfitter Switch Assembly And The Instrument Panel Topper

MC-10204039-0001.pdf 115.2KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [112.50 KB]




NHTSA ID Number: 10203873

Manufacturer Communication Number: SSM 50275

Summary

Some 2019-2021 Ranger vehicles may experience an uneven and/or excessive gap existing between the instrument panel (IP) topper and the center tray/upfitter switch assembly. This may be due to a lack of rigidity in the IP topper not allowing the tray/upfitter switch assembly to latch properly. The following foam block service kit (SPN: KB3Z-2104338-A) should be used to correct this condition. Follow the installation instructions included with the kit to install the foam blocks into the IP topper and repair the vehicle.



1 Associated Document

Manufacturer Communications

SSM 50275
2019-2021 Ranger – Uneven And/Or Excessive Gap Between The Center Tray/Upfitter Switch Assembly And The Instrument Panel Topper

MC-10203873-0001.pdf 98.089KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [95.79 KB]
