NHTSA ID Number: 10187984
Manufacturer Communication Number: SSM 49580
Summary
Some 2020-2021 Explorer/Aviator/Police Interceptor Utility vehicles may exhibit various electrical concerns due to an open 3 or 4 post fuse array on the high current battery junction box (BJB). Service part LU5Z-14526-ALD has been released for the 3 post fuse array and LU5Z-14526-ANC has been released for the 4 post fuse array. It is no longer necessary to order the complete wiring harness to obtain these parts.
Explorer
APPLICABLE VEHICLES
2020 CAR: TV U611N AVIATOR
2020 CAR: TW U625N EXPLORER
2021 CAR: TV U611N AVIATOR
2021 CAR: TW U625N EXPLORER
5 Affected Products
Vehicles
1 Associated Document
Manufacturer Communications
SSM 49580 – 2020-2021 Explorer/Aviator/Police Interceptor Utility – Various Electrical Concerns – 3 And 4 Post Fuse Array On BJB Released For Service
MC-10187984-0001.pdf 113.725KB
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10180421
Manufacturer Communication Number: SSM 49204
Summary
Some 2020 Explorer/Aviator/Police Interceptor Utility vehicles may exhibit various electrical concerns due to an open 3 or 4 post fuse array on the high current battery junction box (BJB). Service part LU5Z-14526-ALD has been released for the 3 post fuse array and LU5Z-14526-ANC has been released for the 4 post fuse array. It is no longer necessary to order the complete wiring harness to obtain these parts.
1 Associated Document
Manufacturer Communications
SSM 49204 – 2020 Explorer/Aviator/Police Interceptor Utility – Various Electrical Concerns – 3 And 4 Post Fuse Array On BJB Released For Service
Loading...
