Safety Recall 20S52 – Brake Pedal Bracket Fracture – 2020 Ford Mustang

September 23, 2020 NHTSA CAMPAIGN NUMBER: 20V573000

Brake Pedal Bracket May Facture

A broken brake pedal could affect braking ability, increasing the risk of a crash.



NHTSA Campaign Number: 20V573

Manufacturer Ford Motor Company

Components SERVICE BRAKES, HYDRAULIC, SERVICE BRAKES

Potential Number of Units Affected 38,005



Summary

Ford Motor Company (Ford) is recalling certain 2020 Mustang vehicles equipped with automatic transmissions. The brake pedal bracket may fracture during sudden stopping.



Remedy

Ford will notify owners, and dealers will replace the brake pedal bracket assembly, free of charge. The recall began January 26, 2021. Owners may contact Ford customer service at 1-866-436-7332. Ford’s number for this recall is 20S52.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.



Check if your Vehicle has a Recall




AFFECTED VEHICLES

Vehicle Model Year Assembly Plant Build Dates
Mustang 2020 Flat Rock September 17, 2019 through August 13, 2020



Affected vehicles are identified in OASIS and FSA VIN Lists.



REASON FOR THIS SAFETY RECALL
In some of the affected vehicles, the brake pedal bracket could fracture if rapid and forceful pressure is applied to the brake pedal, typically seen during track and competition driving. This may result in a loss of primary braking capability, increasing the risk of a crash. In the event of a loss of primary braking capability, the parking brake can be used to bring the vehicle to a stop.



SERVICE ACTION

Before demonstrating or delivering any new in-stock vehicles involved in this recall, dealers are to inspect the brake pedal and bracket assembly part number label and repair if necessary. Brake pedal and bracket assemblies with engineering part number FR3C-2D094-AE or FR3C-2D094-CE will be replaced following the dealer bulletin technical instructions. This service must be performed on all affected vehicles at no charge to the vehicle owner.

NOTE:  Parts are currently not available in sufficient quantities to repair all vehicles. Part orders can be requested through the Special Service Support Center (SSSC) using the SSSC link at the bottom of the OASIS VIN report screen to repair vehicles that meet the following criteria only:

  • Affected customer vehicles that arrive at your dealership.
  • New in-stock vehicles with a signed sales contract.

It is anticipated that parts will be available in sufficient quantities to repair all vehicles in the first quarter of 2021. Refer to Attachment II for additional information.



OWNER NOTIFICATION AND MAILING SCHEDULE

Owners of affected vehicles have been notified. Dealers should repair any affected vehicles that arrive at their dealerships, whether or not the customer has received a letter.



PARTS REQUIREMENTS / ORDERING INFORMATION

SSSC Web Contact Site:

Dealers must determine the correct service part number by VIN using the parts catalog.

To place an order for a brake pedal and bracket assembly, submit a VIN-specific Part Order contact via the SSSC Web Contact Site.

Part Number Description Order Quantity Claim Quantity
FR3Z-2455-AE Brake Pedal and Bracket Assembly (Standard Pedal) 1 1
FR3Z-2455-AF Brake Pedal and Bracket Assembly (Sport Pedal Package)



Order the parts below through normal order processing channels:

Part Number Description Order Quantity Claim Quantity
3M5Z-2L523-AA Safety Recall 20S52 - Brake Pedal Bracket Fracture - 2020 Ford Mustang » small light Brake Booster Push Rod Clevis-Locking Pin 1 1
W520212-S440 Brake Pedal and Bracket Assembly Nuts

(4 nuts required/4 nuts per package)

1 4



NOTE: For the inspection procedure it is not necessary to position the vehicle on a hoist. The part number for the brake pedal and bracket assembly can be obtained and cross referenced without the use of a service bay.



INSPECTION PROCEDURE

1. Locate the brake pedal and bracket assembly part number label, on the left upper side of the bracket as shown in Figure 1. Record the full engineering part number on the repair order.

PASS – For any one of the following part numbers FR3C-2D094-AF, FR3C-2D094-CF, FR3C-2D094-CD or FR3C-2D094-AD, no further action is required. The safety recall is complete.

DOES NOT PASS – For either one of the following part numbers FR3C-2D094-AE or FR3C-2D094-CE, replace the brake pedal and bracket assembly. Proceed to the Service Procedure on Page 2.



NOTE: Taking a picture with a cellular phone will aid in viewing and retaining the brake pedal and bracket assembly part number.



SERVICE PROCEDURE

NOTICE: Do not service the brake pedal or brake booster without first removing the stoplamp switch. The switch must be removed with the brake pedal in the at-rest position. The switch plunger must be compressed for the switch to rotate in the bracket. Attempting to remove the switch when the plunger is extended (during pedal apply) will result in damage to the switch.



NOTE: The brake pedal retaining nuts are one-time use only nuts and must be replaced when removed.



1. Remove the Stop Lamp Switch. Please follow the Workshop Manual (WSM) procedures in Section 417-01.

2. Detach the wiring harness retainers. See Figure 2.



NOTE: The booster push rod clevis-locking pin is a one-time use only part. Any time the booster push rod clevis-locking pin is removed, a new booster push rod clevis-locking pin should be used.



NOTE: Be sure that the push rod is aligned with the clevis during installation.



3. Remove and discard the booster push rod clevis-locking pin and position aside the booster push rod. See Figure 3.



4. Remove the retainers, discard the 4 nuts and remove the brake pedal and bracket. See Figure 4.

  • Torque: 17 lb.ft (22.5 Nm).



NOTICE: Do not press, pull or otherwise move the brake pedal while installing the stoplamp switch. The switch must be installed with the booster push rod attached to the brake pedal and with the brake pedal in the at-rest position. Installing the switch with the brake pedal in any other position will result in incorrect adjustment and may damage the switch.



NOTE: When installing the new brake pedal and bracket assembly ensure that the brake booster push rod clevis is aligned with the brake pedal attachment point before installing the retainers.



5. Install a new brake pedal and bracket by reversing the removal procedure.



IMPORTANT NOTE: Federal law prohibits selling motor vehicle parts or components that are under safety, compliance, or emissions recall. Unless a part is requested to be returned to Ford, all parts replaced under this FSA must be scrapped in accordance with all applicable local, state and federal environmental protection and hazardous material regulations. Refer to the Parts Retention, Return, & Scrapping section of the FSA dealer bulletin for further information.




FORD MOTOR COMPANY ISSUES ONE SAFETY COMPLIANCE RECALL AND TWO SAFETY RECALLS IN NORTH AMERICA

Sep 30, 2020 | DEARBORN, Mich.



DEARBORN, Mich., Sept. 30, 2020 Ford Motor Company is issuing one safety compliance recall and two safety recalls in North America.



Safety compliance recall for multiple 2020 model year vehicles for intermittent rearview camera operation

Affected vehicles have insufficient electrical conductivity within the printed circuit board internal to the camera. A rearview camera that intermittently displays a blank or distorted image would not comply with Federal Motor Vehicle Safety Standards and requires corrective action by the manufacturer.



Ford is not aware of any reports of accident or injury related to this condition.



This action affects 620,246 vehicles in the U.S. and federal territories, 76,566 in Canada and 4,302 in Mexico.



Affected 2020 vehicles include:

  • Ford Explorer vehicles built at Chicago Assembly Plant from Nov. 16, 2019, to May 18, 2020
  • Ford F-150 vehicles built at Dearborn Assembly Plant from Oct. 26, 2019, to May 18, 2020, and Kansas City Assembly Plant from Nov. 2, 2019, to May 18, 2020
  • Ford Mustang vehicles built at Flat Rock Assembly Plant from Nov. 18, 2019, to May 26, 2020
  • Ford Transit vehicles built at Kansas City Assembly Plant from Oct. 28, 2019, to May 20, 2020.
  • Ford Super Duty vehicles built at Kentucky Truck Plant from Nov. 3, 2019, to May 18, 2020, and Ohio Assembly Plant from Oct. 30, 2019, to May 18, 2020
  • Ford Expedition vehicles built at Kentucky Truck Plant from Oct. 30, 2019, to June 22, 2020
  • Ford Escape vehicles built at Louisville Assembly Plant from Nov. 5, 2019, to May 18, 2020 and Lincoln Corsair vehicles built there from Nov. 14, 2019, to May 18, 2020
  • Ford Ranger vehicles built at Michigan Assembly Plant from Dec. 9, 2019, to May 19, 2020
  • Ford Edge vehicles built at Oakville Assembly Plant from Nov. 13, 2019, to May 26, 2020, and Lincoln MKX and Nautilus vehicles built there from Nov. 21, 2019, to May 26, 2020



Dealers will replace the rearview camera. Official notification to dealers and customers will begin Nov. 7. The Ford reference number for this recall is 20C19.



Safety recall for select 2020 Ford Mustang vehicles

Affected vehicles are equipped with a brake pedal bracket that could fracture during sudden stopping. During a sudden stop, the driver may experience a loss of primary braking capability that could increase the risk of an accident.

Ford is not aware of any reports of accident or injury related to this condition.

This action affects 38,005 vehicles in the U.S. and federal territories, 2,251 in Canada and 322 in Mexico. Affected vehicles were built at Flat Rock Assembly Plant from March 4, 2019, to Aug. 13, 2020.

Dealers will replace the brake pedal bracket assembly. The Ford reference number for this recall is 20S52.



Safety recall for select 2019 Ford FSeries Super Duty vehicles

Affected F-250 and F-350 vehicles are equipped with front axles that may contain a wheel end yoke that was not properly welded to the axle tube end. An improperly welded attachment may cause steering effects that could impact vehicle control. This may include pulling to the right or left, misalignment of the steering wheel or change in steering sensitivity that could affect the response of the vehicle to driver input during a hard-braking event, increasing risk of a crash.

Ford is not aware of any reports of accident or injury related to this condition.

This action affects 9,628 vehicles in the U.S. and federal territories and 961 in Canada. Affected vehicles were built at Kentucky Truck Plant from Aug. 24 to Oct. 16, 2019.

Dealers will replace the axle assembly if the weld is found to be inaccurately located. The Ford reference number for this recall is 20S56.









1 Affected Product

Vehicle

MAKE MODEL YEAR
FORD MUSTANG 2020




15 Associated Documents

Recall Quarterly Report #2, 2021-2

RCLQRT-20V573-1641.PDF 211.237KB

RCLQRT-20V573-1641




Manufacturer Notices(to Dealers,etc) – Dealer Notification re NEW VEHICLE DEMONSTRATION / DELIVERY HOLD Safety Recall 20S52 – Supplement #2 Certain 2020 Model Year Left Hand Drive Mustang Vehicles Equipped with an Automatic TransmissionBrake Pedal Bracket Fracture

RCMN-20V573-8857.pdf 800.609KB

RCMN-20V573-8857




20S52 20S56 Media Correspondence

RMISC-20V573-2495.pdf 307.883KB

RMISC-20V573-2495




Manufacturer Notices(to Dealers,etc) – October 14, 2020 SUBJECT: NEW VEHICLE DEMONSTRATION / DELIVERY HOLD Safety Recall 20S52 Certain 2020 Model Year Left Hand Drive Mustang Vehicles Equipped with an Automatic TransmissionBrake Pedal Bracket Fracture

RCMN-20V573-7925.pdf 586.712KB

RCMN-20V573-7925




Defect Notice 573 Report

RCLRPT-20V573-8534.PDF 214.325KB

RCLRPT-20V573-8534




Recall 573 Report

RCLRPT-20V573-9962.PDF 214.325KB

RCLRPT-20V573-9962




Recall Acknowledgement

RCAK-20V573-5399.pdf 321.436KB

RCAK-20V573-5399




Manufacturer Notices(to Dealers,etc) – NEW VEHICLE DEMONSTRATION / DELIVERY HOLD Advance Notice – Safety Recall 20S52 Certain 2020 Model Year Left Hand Drive Mustang Vehicles Equipped with Automatic TransmissionBrake Pedal Bracket Fracture

RCMN-20V573-1184.pdf 111.278KB

RCMN-20V573-1184




Manufacturer Notices(to Dealers,etc) – NEW VEHICLE DEMONSTRATION / DELIVERY HOLD Safety Recall 20S52 – Supplement #1 Certain 2020 Model Year Left Hand Drive Mustang Vehicles Equipped with an Automatic TransmissionBrake Pedal Bracket Fracture

RCMN-20V573-7460.pdf 651.01KB

RCMN-20V573-7460




ISSUED Interim Owner Notification Letter(Part 577)

RIONL-20V573-0558.pdf 46.184KB

RIONL-20V573-0558




Renotification Notice

RCRN-20V573-9246.pdf 43.448KB

RCRN-20V573-9246




Recall 573 Report

RCLRPT-20V573-5646.PDF 214.325KB

RCLRPT-20V573-5646




Recall 573 Report

RCLRPT-20V573-7499.PDF 214.325KB

RCLRPT-20V573-7499




Recall Quarterly Report #1, 2021-1

RCLQRT-20V573-9317.PDF 211.131KB

RCLQRT-20V573-9317




Owner Notification Letter(Part 577)

RCONL-20V573-5700.pdf 52.129KB

RCONL-20V573-5700
