NHTSA ID Number: 10177860
Manufacturer Communication Number: TSB 20-2223
Summary
Some 2017 Ford GT vehicles equipped with parallel transmission gearset and clutch coolers may exhibit intermittent clutch fluid overheating when used in track conditions.
1 Affected Product
Vehicle
| MAKE | MODEL | YEAR |
| FORD | GT | 2017 |
| TECHNICAL SERVICE BULLETIN Transmission Clutch Fluid Overheating During Track Use – Vehicles Equipped With Parallel Coolers Only |
20-2223 07 July 2020 |
This bulletin supersedes 18-2391. Reason for update: Incorrect Procedure
Model:
2017 Ford GT
Summary
This article supersedes TSB 18-2391 to update the Service Procedure attachments.
Issue: Some 2017 Ford GT vehicles equipped with parallel transmission gearset and clutch coolers may exhibit intermittent clutch fluid overheating when used in track conditions.
Action: Follow the Service Procedure steps to correct the condition on vehicles that meet all of the following criteria:
- 2017 Ford GT
- Equipped with parallel transmission gearset and clutch coolers
- Intermittent clutch fluid overheating when used in track conditions
NOTE: Part quantity refers to the number of that service part number required, which may be different than the number of individual pieces. Service part numbers contain 1 piece unless otherwise stated. “As Needed” indicates the part is required but the number may vary or is not a whole number; parts can be billed out as non-whole numbers, including less than 1.
Parts
| Description | Quantity | Part Number |
| Transmission Clutch Oil Cooler Repair Kit | 1 | HG7Z-7K177-A |
Warranty Status: Eligible under provisions of New Vehicle Limited Warranty (NVLW)/Service Part Warranty (SPW)/Special Service Part (SSP)/Extended Service Plan (ESP) coverage. Limits/policies/prior approvals are not altered by a TSB. NVLW/SPW/SSP/ESP coverage limits are determined by the identified causal part and verified using the OASIS part coverage tool.
Labor Times
| Description | Operation No. | Time |
| 2017 Ford GT: Install The Gear Set Cooler And Fan Assembly Following The Work Instructions | MT202223 | Actual Time |
Repair/Claim Coding
| Causal Part: | 7A095 |
| Condition Code: | 42 |
Service Procedure
NOTE: Only a certified GT service dealer can order parts for a GT, submit warranty claims on GT repairs, and service a GT. Certified GT dealers cannot order parts for dealers that are not GT certified.
- Inspect the factory equipped transmission gearset and clutch cooler by looking thru the rear fascia grille opening at the left side of the rear bumper cover. (Figure 1) Is the vehicle equipped with a perpendicular transmission gearset and clutch cooler? (Figure 2-3)
(1). Yes – this article does not apply. Refer to Workshop Manual (WSM), Section 307-02 for normal diagnostics.
(2). No – proceed to Step 2.
- Complete the transmission clutch cooler repair using the attached work instructions.
NOTE: This procedure is considered one that is complex and involves a high level of repair difficulty. For all technical assistance from Multimatic, contact the Ford GT Concierge using the Ford dealer access phone number.
NOTE: A bill of materials (BOM) is attached for the transmission clutch cooler repair kit. Please review the BOM to verify all parts are present before beginning the repair.
- Place the revised Owners Manual addendum card provided in the parts kit into the Owners Manual sleeve and notify the customer.
(1). If the Owners Manual kit is covered in original shipping material, do not remove from packaging. If the Owners Manual is not present, place the addendum card in the storage bag.
SEOCONTENT-START
TECHNICAL SERVICE BULLETIN
Transmission Clutch Fluid Overh eating During Track Use – Vehicles
Equipped With Parallel Coolers Only
Warranty Status: Eligible Under Provisions Of New Vehicle Limited Warranty Coverage Warranty/ESP coverage limits/policies/prior approvals are not altered by a TSB. Warranty/ESP coverage limits are determined by the identified causal part and verified using the OASIS part coverage tool.
Labor Times
| Description | Operation No. | Time |
| 2017 Ford GT: Install The Gear Set Cooler And Fan Assembly Following The Work Instructions | MT182391 | Actual Time |
Repair/Claim Coding
| Causal Part: | 7A095 |
| Condition Code: | 42 |
SEOCONTENT-END
1 Associated Document
Manufacturer Communications
20-2223
07 July 2020
https://www.nhtsa.gov/recalls?nhtsaId=10177860
MC-10177860-0001.pdf 544.132KB
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10153917
Manufacturer Communication Number: TSB 18-2391
Summary
Some 2017 Ford GT vehicles equipped with parallel transmission gearset and clutch coolers may exhibit intermittent clutch fluid overheating when used in track conditions. Follow the Service Procedure steps to correct the condition.
18-2391
02 January 2019
https://www.nhtsa.gov/recalls?nhtsaId=10153917
https://static.nhtsa.gov/odi/tsbs/2019/MC-10153917-9999.pdf
