NHTSA ID Number: 10244714
Manufacturer Communication Number: TSB 23-2311
Summary
Some 2024 Mustang vehicles built on or before 29-June-2023 may exhibit a rub/scratch/buzz noise coming from the right front passenger side of the IP Topper. This may be due to contact between the IP topper contacting sheet metal by the defroster grille. To correct the condition, follow the Service Procedure to remove the windshield and apply flock tape to the leading edge of the IP topper.
Model:
Ford
2024 Mustang |
Built on or before 29-June-2023 |
Issue: Some 2024 Mustang vehicles built on or before 29-June-2023 may exhibit a rub/scratch/buzz noise coming from the right front passenger side of the IP topper. This may be due to contact between the IP topper contacting sheet metal by the defroster grille. To correct the condition, follow the Service Procedure to remove the windshield and apply flock tape to the leading edge of the IP topper.
Action: Follow the Service Procedure to correct the condition on vehicles that meet all of the following criteria:
- 2024 Mustang
- Built on or before 29-June-2023
- Rub/scratch/buzz noise coming from the right front passenger side of the IP topper
Parts
Service Part Number | Quantity | Description | Unit of Issue | Piece Quantity | Note |
ZC-23 | As Needed | Motorcraft® Ultra-Clear Spray Glass Cleaner | |||
164-R4903 | 1 | Flock Tape Fuzzy Strips (Rotunda Part Number) | 24 | 1 | If unavailable, the Squeak and Rattle Kit (164-R4900) contains this part |
Parts – Only One Of The Following Adhesives
Service Part Number | Quantity | Description |
Obtain Locally | As Needed | Sika® SikaTack® MACH 60 |
Obtain Locally | As Needed | Sika® SikaTack® MACH 30 |
Obtain Locally | As Needed | Dow® BETASEAL™ Express |
Obtain Locally | As Needed | Sika Tack ASAP Urethane Adhesive |
Parts – Only One Of The Following Primers
Service Part Number | Quantity | Description |
Obtain Locally | As Needed | Sika® Aktivator PRO |
Obtain Locally | As Needed | Dow® BETAPRIME™ 5504G |
Obtain Locally | As Needed | Sika® Primer-207 |
Parts – Parts To Inspect And Replace Only If Necessary
Service Part Number | Quantity | Description |
PR3Z-6303100-B | 1 | Acoustic Laminated Windshield, SYNC4 |
PR3Z-6303100-E | 1 | Laminated Windshield |
Service Procedure
Video 1 – Example of IP topper scratch noise with windshield taken out
Video 2 – Example of the IP topper scratch noise in vehicle
1. Does the IP topper make a rub/scratch/buzz noise from the forward right section directly adjacent to the defroster grille? Refer to Videos 1 and 2 for examples.
(1). Yes – proceed on to Step 2.
(2). No – this article does not apply. Refer to the Workshop Manual (WSM) for normal diagnostics.
2. Remove the defroster grille from the IP topper.
NOTE: Use a pry tool and be careful not to damage the topper.
3. Unclip the sun load sensor from the defroster grille.
4. Remove the front windshield. Refer to WSM, Section 501-11, General Procedures, Fixed Glass.
5. Obtain a full section (6 in. long x 1.75 in. wide x .0625 in. thick) of flock tape (fuzzy) strip tape from the Rotunda Squeak and Rattle Kit or obtain flock tape separately from the kit. Wrap the flock tape around the leading edge of the IP topper as seen in Figures 1-2 with only 10 mm of the flock tape should be exposed on the top side of the IP topper, isolating the IP topper from directly touching the sheet metal.
Figure 1 – View from right side of the vehicle with flock tape installed
Figure 2 – View from left side of the vehicle with flock tape installed
6. Re-clip the sun load sensor to the defroster grille and re-install the defroster grille on the IP topper.
7. Re-install the windshield. Refer to WSM, Section 501-11, General Procedures, Fixed Glass.
1 Affected Product
Vehicle
MAKE | MODEL | YEAR |
FORD | MUSTANG | 2024 |
1 Associated Document
Manufacturer Communications
23-2311
02 October 2023
https://www.nhtsa.gov/recalls?nhtsaId=10244714
