NHTSA ID Number: 10228892
Manufacturer Communication Number: 22G05 S2
Summary
Certain 2022 Model Year F-150 and Super Duty Vehicles Exterior Badge Retrofit
REASON FOR THIS SUPPLEMENT
Service Action: Dealers are to order parts through the SSSC as needed.
Claims Preparation And Submission: Causal part number correction.
Labor Allowances: Clarification – temporary fender vent badge adjustment is for Super Duty only.
Parts: Dealers are to order parts through the SSSC as needed.
Correction: The small King Ranch tailgate badge does not apply to the F-150 2022 Model Year in this program.
December 12, 2022
Recommended New Vehicle Delivery Hold –
Component Installation Program 22G05 – Supplement #2
Certain 2022 Model Year F-150 and Super Duty Vehicles
Exterior Badge Retrofit
REASON FOR THIS SUPPLEMENT
Service Action: Dealers are to order parts through the SSSC as needed.
Claims Preparation And Submission: Causal part number correction.
Labor Allowances: Clarification – temporary fender vent badge adjustment is for Super Duty only.
Parts: Dealers are to order parts through the SSSC as needed.
Correction: The small King Ranch tailgate badge does not apply to the F-150 2022 Model Year in this program.
PROGRAM TERMS
This program will be in effect through October 31, 2032, or a maximum of 150,000 miles, whichever occurs first. If a vehicle already has accumulated more than 150,000 miles, this coverage will last through October 31, 2023.
AFFECTED VEHICLES
Vehicle | Model Year | Assembly Plant | Build Dates |
F-150 | 2022 | Dearborn | Beginning July 28, 2022 |
Kansas City | Beginning July 31, 2022 | ||
Super Duty | 2022 | Kentucky | Beginning July 23, 2022 |
Ohio | Beginning August 11, 2022 |
Affected vehicles are identified in OASIS and FSA VIN Lists.
NOTE: The list of affected VINs may be updated daily as vehicles are added to the program. End build dates will be provided once they are established at all assembly plants.
NOTE – Verify VIN status: Some vehicles may be in the process of being repaired at the plant. Monitor OASIS before opening an RO and/or beginning a repair. Parts purchased for an FSA can be returned for credit, if required. See the EXCESS STOCK RETURN details in Attachment II for more information.
REASON FOR THIS PROGRAM
Due to a supplier shortage of exterior vehicle badges, some 2022 Model Year F-150 and Super Duty vehicles will be shipped and can be sold to customers with temporary or missing badges.
Temporary/missing badges will not impact the vehicle performance or function. Trucks may not have the same number of temporary badges and/or missing badges. All temporary badges will be molded in color black.
- F150 – Temporary F-150 badges could include both side fender vent nameplate/trim badges (e.g., molded in color black in place of F-150/XLT). Missing badges could include both door powertrain badges (e.g., PowerBoost), XLT Texas/Oklahoma badge and/or EcoBoost badge on tailgate.
- Super Duty – Temporary Super Duty badges could include both side fender vent nameplate/trim badges (e.g., molded in color black in place of F-250/Lariat). Missing badges could include both door powertrain badges (e.g.,6.7L Power Stroke), and/or King Ranch badge on tailgate.
Customers will be required to sign an acknowledgement letter, notifying them of the temporary or missing badges prior to vehicle sale.
Reference: Electronic Field Communication (EFC) – Supersede of Product Offering Changes: 22MY F150 & Super Duty Temporary Exterior Vehicle Badges.
SERVICE ACTION
Dealers will install missing badges for all impacted 2022 Model Year F-150 and Super Duty customers.
New in-stock vehicles: when possible, install badges prior to new vehicle delivery.
- Refer to parts section for updated part ordering details. Dealers are to order parts through the SSSC as needed.
- For special or unique situations, (non-involved VIN, different badge count vs. shipped parts, collision repair, etc.) please use the SSSC contact selection Badge Inquiry.
- Missing temporary fender vent badges are to be processed as a misbuild.
- Verify VIN status: Some vehicles may be in the process of being repaired at the plant. Monitor OASIS before opening an RO and/or beginning a repair.
- For Vehicles arriving with production badges – no update necessary:
Dealers are to install the missing badges per technical information – from 1 to 5 badges for F-150 or from 1 to 7 for Super Duty (vehicle specific). Dealers will also remove any temporary fender badges (side vents), clean surfaces, and install new badge(s) in the proper location(s). This service must be performed on all affected vehicles at no charge to the vehicle owner.
NOTE: There are temperature requirements in the technical information for certain badges.
To assist vehicle owners to have this update completed, dealers should:
- Arrange for a mobile repair at the owner’s location,
- Mobile service should be made available for all customers. Refer to the Claiming sections for further details.
NOTE: Please notify the SSSC if vehicle is being dealer traded or otherwise delivered by another dealer (include new delivering Dealer in SSSC contact).
NOTE: Ford Oval badges are not included in this program and should be considered a misbuild if missing.
CUSTOMER NOTIFICATION
Owner letters are expected to be mailed the week of December 19, 2022.
Dealers should repair any affected vehicles that arrive at their dealerships, whether or not the customer has received a letter.
MOBILE REPAIR RECOMMENDATIONS
- Confirm with customer a mobile repair is feasible.
- Check OASIS prior to going to the customer’s home or business to confirm if any other outstanding FSA needs to be completed.
- Transportation – due to the simplicity of this repair, a specialty vehicle is not required.
MOBILE REPAIR ADDITIONAL INFORMATION
Please ensure the technician brings the following to the mobile repair destination:
- Printed Technical Instructions.
- Printed Repair/Work Order or any other necessary documentation as customer copy(s) o Documents could also be emailed to the customer.
- Shirt/uniform and vehicle graphic with dealership or Ford logos are recommended.
- Recommended tools and cleaning supplies: Plastic trim removal tool, isopropyl alcohol, microfiber cleaning cloths, and making tape.
MOBILE REPAIR QUESTIONS AND ASSISTANCE
- For questions and assistance, contact the Special Service Support Center (SSSC) via the SSSC Web Contact Site. Work with Dealership warranty administrator to create a SSSC contact ID#.
- Once an SSSC agent responds to the new contact ID#, you may opt to call the SSSC hotline: (800) 325-5621.
SOLD VEHICLES
- Owners of affected vehicles will be directed to dealers for repairs.
- Immediately contact any of your affected customers whose vehicles are not on your VIN list but are identified in OASIS. Give the customer a copy of the Owner Notification Letter (when available) and schedule a service date.
- Correct other affected vehicles identified in OASIS which are brought to your dealership.
- Dealers are to prioritize repairs of customer vehicles over repairs of new and used vehicle inventory.
STOCK VEHICLES
- When possible, correct all affected units in your new vehicle inventory before delivery.
- Use OASIS to identify any affected vehicles in your used vehicle inventory.
TITLE BRANDED / SALVAGED VEHICLES
Affected title branded and salvaged vehicles are eligible for this service action.
OWNER REFUNDS
Refunds are not approved for this program.
RENTAL VEHICLES
Rental vehicles are not approved for this program.
PARTS REQUIREMENTS / ORDERING INFORMATION Special Program Part Ordering:
To place an order for exterior badges:
- Please use the VIN specific missing badges web site to determine parts:
- https://22g05badgecheck.com/ o Confirm parts to be ordered match what vehicle needs.
- Part orders: Submit a VIN-specific Part Order contact via the SSSC Web Contact Site.
- For special or unique situations, (non-involved VIN, different badge count vs. shipped parts, collision repair, etc.) please use the SSSC contact selection Badge Inquiry.
NOTE: Correction – The small King Ranch tailgate badge does NOT apply to the F-150 2022 Model Year in this program.
NOTE: Ford Oval, and temporary fender vent badges are not included in this program and should be considered a misbuild if missing.
NOTE: Dealers will be notified via a DOES II communication if circumstances warrant a change in part supply strategy and when open ordering resumes.
As you know, the supply chain tried to mess with some of our truck badges, but it can’t keep a good truck down. Permanent Ford name badges for your truck are now available, thanks to our hardworking buyers and suppliers.
To get your new badges, contact your dealer to place an order and schedule an appointment. One of our qualified service technicians can then replace them at no charge. Please reference your Vehicle Identification Number (VIN) XXXXXXXXXXX and program number 22G05 when you talk to your dealer. Rest assured that we’ll do our best to minimize any inconvenience. The official time frame for you to get this done is now through October 31, 2032, or before your truck reaches 150,000 miles, whichever comes first.*
You deserve a perfect owner experience from the moment you order a Ford vehicle. While the supply chain didn’t make that possible this time, we’re ready to make things right.
If you have any questions or concerns, please feel free to call our Customer Care Center at 1-866-436-7332. Or for fleet owners, please call our Ford Pro™ Contact Center at 1-800-34-FLEET (option #1).
*Coverage is automatically transferred to subsequent owners.
CERTAIN 2022 MODEL YEAR F-150 AND SUPER DUTY VEHICLES – EXTERIOR BADGE RETROFIT
SERVICE PROCEDURE
F-150 VEHICLES
Table Of Contents
Front Fender Vent Badges Left Hand/Right Hand (LH/RH) – 2
Front LH Door Badge – 3
PowerBoost – 3
Front RH Door Badge – 4
PowerBoost – 4
Tailgate Badge – 5
EcoBoost – 5
Texas Edition – 6
Oklahoma Edition – 7
Tremor – 8
Raptor – 9
NOTE: Ford Oval badges are not included in this program and should be considered a mis-build if missing.
IMPORTANT: Badges must be installed when ambient temperatures and surface temperatures of vehicle and badge are confirmed to be between 60°F (16°C) and 100°F (38°C).
Materials List
Ruler/Scale (12″/30cm minimum)
Clean Cloths
Masking Tape
Isopropyl Alcohol
Plastic Trim Tool
MOBILE SERVICE INSTRUCTIONS
NOTE: If you suspect that you will not have Internet access at the vehicle’s mobile service location then, you should print a copy of these instructions (including any required Workshop Manual references) for reference during the mobile service.
Front Fender Vent Door Badges (LH/RH)
NOTE: RH and LH front fender vent door badges are expected to be updated in pairs. If a normal production level badge is present, do not replace it (it should match the new part though).
1. Using a plastic trim tool, remove the LH side temporary front fender door badge. See Figure 1.
NOTE: RH side shown, LH side similar.
2. Using isopropyl alcohol and a clean cloth, wipe the area where the new badge is to be installed.
3. Using another clean cloth, dry the area that was cleaned.
4. Allow the isopropyl alcohol one minute to fully evaporate.
5. Remove the tape liner from the back of the new badge
6. Install the new badge by aligning the clips on the back with the holes in the sheet metal and pressing in until they click.
7. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered.
8. Repeat steps 1-7 for the RH side of the vehicle.
Front LH Door Badge – PowerBoost
9. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
10. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed.
11. Using another clean cloth, dry the area that was cleaned.
12. Allow the isopropyl alcohol one minute to fully evaporate.
13. Measure and apply locating masking tape to the front LH door outer panel. See Figure 2.
14. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 3.
15. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 3.
Front RH Door Badge – PowerBoost
16. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
17. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed.
18. Using another clean cloth, dry the area that was cleaned.
19. Allow the isopropyl alcohol one minute to fully evaporate.
20. Measure and apply locating masking tape to the front RH door outer panel. See Figure 4.
21. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 5.
22. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 5.
23. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
24. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed.
25. Using another clean cloth, dry the area that was cleaned.
26. Allow the isopropyl alcohol one minute to fully evaporate.
27. Measure and apply locating masking tape to the tailgate outer panel. See Figure 6.
28. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 7.
29. Using medium hand pressure, press for 3 seconds at a minimum of 3 separate locations along the length of the badge until the tape is fully adhered. See Figure 7.
Tailgate Badge – Texas Edition
30. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
31. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed.
32. Using another clean cloth, dry the area that was cleaned.
33. Allow the isopropyl alcohol one minute to fully evaporate.
34. Measure and apply locating masking tape to the tailgate outer panel. See Figure 10.
35. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 11.
36. Using medium hand pressure, press for 3 seconds at a minimum of 2 separate locations along the length of the badge until the tape is fully adhered. See Figure 11.
Tailgate Badge – Oklahoma Edition
37. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
38. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed.
39. Using another clean cloth, dry the area that was cleaned.
40. Allow the isopropyl alcohol one minute to fully evaporate.
41. Measure and apply locating masking tape to the tailgate outer panel. See Figure 12.
42. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 13.
43. Using medium hand pressure, press for 3 seconds at a minimum of 2 separate locations along the length of the badge until the tape is fully adhered. See Figure 13.
Tailgate Badge – Tremor
44. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
45. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed.
46. Using another clean cloth, dry the area that was cleaned.
47. Allow the isopropyl alcohol one minute to fully evaporate.
48. Measure and apply locating masking tape to the tailgate outer panel. See Figure 14.
49. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 15.
50. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 15.
51. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
52. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed.
53. Using another clean cloth, dry the area that was cleaned.
54. Allow the isopropyl alcohol one minute to fully evaporate.
55. Measure and apply locating masking tape to the tailgate outer panel. See Figure 16.
56. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 17.
57. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 17.
CERTAIN 2022 MODEL YEAR F-150 AND SUPER DUTY VEHICLES – EXTERIOR BADGE RETROFIT
SERVICE PROCEDURE
SUPER DUTY VEHICLES
Table Of Contents
Front Fender Vent Badges Left Hand/Right Hand (LH/RH) – 2
Front LH Door Badge – 3
Power Stroke – 3
6.7L – 4
Front RH Door Badge – 5
Power Stroke – 5
6.7L – 6
Tailgate Badge – 7
King Ranch – 7
NOTE: Ford Oval badges are not included in this program and should be considered a mis-build if missing.
NOTE: For temporary fender vent badge adjustments see Attachment VI – Interim Service Procedure.
IMPORTANT: Badges with adhesive must be installed when ambient temperatures and surface temperatures of vehicle and badge are confirmed to be between 60°F (16°C) and 100°F (38°C).
Materials List
Ruler/Scale (12″/30cm minimum)
Clean Cloths
Masking Tape
Isopropyl Alcohol
Plastic Trim Tool
MOBILE SERVICE INSTRUCTIONS
NOTE: If you suspect that you will not have Internet access at the vehicle’s mobile service location then, you should print a copy of these instructions (including any required Workshop Manual references) for reference during the mobile service.
Front Fender Vent Door Badges (LH/RH)
NOTE: RH and LH front fender vent door badges are expected to be updated in pairs. If a normal production level badge is present, do not replace it (it should match the new part though).
1. Using a plastic trim tool, remove the LH side temporary front fender door badge. See Figure 1.
NOTE: RH side shown, LH side similar.
NOTE: To remove temporary badge metal clips from the body – release the metal clip from the back side by pushing up so the clips rotate into the holes.
2. Using isopropyl alcohol and a clean cloth, wipe the area where the new badge is to be installed.
3. Using another clean cloth, dry the area that was cleaned.
4. Allow the isopropyl alcohol one minute to fully evaporate.
5. Install the new badge by aligning the clips on the back with the holes in the sheet metal and pressing in until they click.
6. Repeat steps 1-5 for the RH side of the vehicle.
Front LH Door Badge – Power Stroke
7. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
8. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed.
9. Using another clean cloth, dry the area that was cleaned.
10. Allow the isopropyl alcohol one minute to fully evaporate.
11. Measure and apply locating masking tape to the front LH door outer panel. See Figure 2.
12. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 3.
13. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 3.
Front LH Door Badge – 6.7L
14. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
15. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed.
16. Using another clean cloth, dry the area that was cleaned.
17. Allow the isopropyl alcohol one minute to fully evaporate.
18. Measure and apply locating masking tape to the front RH door outer panel. See Figure 4.
19. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 5.
20. Using medium hand pressure, press for 3 seconds at a minimum of 2 separate locations along the length of the badge until the tape is fully adhered. See Figure 5.
Front RH Door Badge – Power Stroke
21. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
22. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed.
23. Using another clean cloth, dry the area that was cleaned.
24. Allow the isopropyl alcohol one minute to fully evaporate.
25. Measure and apply locating masking tape to the front outer panel. See Figure 6.
26. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 7.
27. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 7.
Front RH Door Badge – 6.7L
28. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
29. Using isopropyl alcohol and a clean cloth, wipe the area that the badge is to be installed at.
30. Using another clean cloth, dry the area that was cleaned.
31. Allow the isopropyl alcohol one minute to fully evaporate.
32. Measure and apply locating masking tape to the front RH door outer panel. See Figure 8.
33. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 9.
34. Using medium hand pressure, press for 3 seconds at a minimum of 2 separate locations along the length of the badge until the tape is fully adhered. See Figure 9.
Tailgate Badge – King Ranch
35. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C).
36. Using isopropyl alcohol and a clean cloth, wipe the area that the badge is to be installed at.
37. Using another clean cloth, dry the area that was cleaned.
38. Allow the isopropyl alcohol one minute to fully evaporate.
39. Measure and apply locating masking tape to the tailgate outer panel. See Figure 10.
40. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 11.
41. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 11.
CERTAIN 2022 MODEL YEAR F-150 AND SUPER DUTY VEHICLES – EXTERIOR BADGE RETROFIT
INTERIM SERVICE PROCEDURE
SUPER DUTY VEHICLES – TEMPORARY FENDER VENT BADGE RESET
NOTE: This procedure is only for the temporary fender vent badges that are rubbing/touching the door.
WARNING: Too much force will break the temporary fender vent badge.
1. Using a plastic trim panel tool, perform the following steps; See Figure 1
- In the highlighted recessed section only
- Gently pull the badge outward from the inside edge of the badge
- Move the trim stick up and down several times to reset the plastic
- Recheck the door for rubbing/touching
NOTE: Driver’s side shown, passenger side similar.
NOTE: Temporary badges were NOT released for service and if missing are to be considered a misbuild from the assembly plant. A Special Support Service Center (SSSC) contact may also be created for support.
5 Affected Products
Vehicles
MAKE | MODEL | YEAR |
FORD | F-150 | 2022 |
FORD | F-250 SD | 2022 |
FORD | F-350 SD | 2022 |
FORD | F-450 SD | 2022 |
FORD | F-550 SD | 2022 |
1 Associated Document
Manufacturer Communications
December 12, 2022
Component Installation Program 22G05 – Supplement #2
https://www.nhtsa.gov/recalls?nhtsaId=10228892
MC-10228892-0001.pdf 4465.912KB
NHTSA ID Number: 10226957
Manufacturer Communication Number: 22G05 S1
Summary
Certain 2022 Model Year F-150 and Super Duty Vehicles Exterior Badge Retrofit
REASON FOR THIS SUPPLEMENT
Service Action: Interim Service Action for temporary fender vent badge interference as needed Added details for vehicles arriving with production badges. Labor Allowances: Added labor code for temporary fender vent badge adjustment as an interim repair Added labor code for a vehicle that has production badges to close out of the program. Technical Information: Updated service details including interim actions for temporary badges
1 Associated Document
Manufacturer Communications
November 10, 2022
Component Installation Program 22G05 – Supplement #1
https://www.nhtsa.gov/recalls?nhtsaId=10226957
MC-10226957-0001.pdf 4335.46KB
NHTSA ID Number: 10225544
Manufacturer Communication Number: 22G05
Summary
Certain 2022 Model Year F-150 and Super Duty Vehicles Exterior Badge Retrofit
Due to a supplier shortage of exterior vehicle badges, some 2022 Model Year F-150 and Super Duty vehicles will be shipped and can be sold to customers with temporary or missing badges.
Temporary/missing badges will not impact the vehicle performance or function. Trucks may not have the same number of temporary badges and/or missing badges. All temporary badges will be molded in color black.
1 Associated Document
Manufacturer Communications
October 21, 2022
Recommended Delivery Hold –
Component Installation Program 22G05
https://www.nhtsa.gov/recalls?nhtsaId=10225544
MC-10225544-0001.pdf 3629.764KB
- [High-quality material] : The shell part of front grille tailgate car emblem is made of ABS material, and the national flag part is made of aluminum material, which has the characteristics of ultraviolet resistance, high and low temperature resistance, not easy to fall off, not easy to deformation, not easy to fade, waterproof and anti-corrosion and durable, and can adapt to different weather changes. It is a perfect replacement for Ford emblem.
- [Compatibility]: This American flag overlay emblem is 9 inches wide and 3.5 inches tall, fit for Ford 2004-2014 F-150, 2005-2007 F-250/ F-350, 2011-2014 Edge, 2011-2016 Explorer, Ranger, Expedition, etc.
- [Unique appearance] : The metal emblem is designed with American flag, and you can mount it on the front grille or use it on the rear tailplate. It can not only reflect your patriotic feelings, but also improve the fashion sense of your car exterior accessories.
- [Easy installation] : The back of the car decal is equipped with 3M adhesive, peel off the back and press gently to make it firmer. (Be careful not to tear off the installation repeatedly, which will affect the adhesion)
- [Multi-color option] : The front grille American flag emblem for ford is available in three colors: red, black, and silver. You can always find a color you like, so buy our Metal Emblem to replace your damaged car Emblem and make your car more attractive.
- 【Compatible Vehicles】Fit for 2004-2014 F150, 2011-2014 Edge, 2011-2016 Explorer, 2006-2011 Ranger, 2007-2014 Expedition
- 【OEM Part Numbers】 # 4L34-15402A-CA 8C3Z-1542528-A
- 【Size】 9" Wide and 3.5" Height. lease peel off the front dust sticker and the sticky post on the back for installation
- 【Premium product】Brand new, never used.High quality design standards and undergo a rigorous series of tests. 180 Days Warranty
- 【24 Hours Service】LINOAH Auto Parts fit vehicle without error or installation problem. If you are not sure whether it fits your vehicle or have other issues, please contact us.
- Perfect Fitment-- This liftgate emblem badge trim cover is designed for Ford Bronco, for Bronco Sport 2021-2023.
- Easy Installation-- The tail gate emblem badge trim cover is easy to install and use, with heavily adhesive design, it will do no harm to your car and can easy to attach.
- Sense of Design-- This exterior accessory for Ford Bronco has a beautiful custom design that can upgrade your car with a greatly new look and add special style and attitude for your car.
- Premium Material-- This tailgate emblem badge trim cover is made of high quality ABS plastic, lightweight, colorfast and durable. It can give you a long time use life.
- Satisfactory Guarantee-- We provide one-year nice after-sales service, if you have any questions, please feel free to contact us.
- Perfect Fit: Specifically designed to perfectly fit the front grill or rear tailgate of 2015 2016 2017 2018 2019 2020 2021 F150
- Made of high-quality aluminum materials, this emblem is durable and will withstand any weather conditions.
- Size: Front Grille Tailgate Emblem is 9.5 inch. Please check your grille or tailgate size before ordering.
- Easy Installation: With pre-applied 3M adhesive tape, installation is quick and easy, allowing you to upgrade your vehicle's appearance in no time.
- Versatile: Not only can this emblem be used on the front grille, but it can also be used on the rear tailgate, adding a patriotic touch to the back of your vehicle.
- [High quality]: Front Grille Tailgate Car Emblem features a premium ABS+ Aluminum flag surface that is resistant to corrosion, water, UV and durability. Can withstand any weather conditions.
- [Scope of use]: Front Grille Tailgate Rear Aluminum Overlay American Black Flag Emblem is 9 inches by 3.5 inches, Oval American Black Flag Emblem suitable for Ford 2004-2014 F-150, 2005-2007 F-250/ F-350, 2011-2014 Edge, 2011-2016 Explorer, EXPEDITION, RANGER, etc.
- [Front Grill Rear Tailgate Emblem]: The front grille tailgate emblem fit for both the rear tailgate and front grille. Please check the dimensions of your original logo before purchasing to confirm if our car logo is suitable for your vehicle.
- [Fashion design]: Our Front Grille Tailgate Car Emblem is designed with the American flag pattern, which can reflect your patriotic feelings and enhance the fashion sense of your car's exterior, which is the best gift for friends and family.
- [Easy to install]: Simply remove the original badge, clean the installation location and keep it clean, tear off the Oval American Flag emblem back sticker, then simply place it on top, pressing gently to make it firmer and more secure.
- Perfect Fit: No need to disassemble the original ford emblem, it can be covered directly on the original ford 9 inch emblem.
- OEM Size: This emblem compatible with Ford 2004-2014 F-150, 2005-2007 F-250/ F-350, 2011-2014 Edge, 2011-2016 Explorer, EXPEDITION, RANGER, Etc.
- High Quality:Comes with 3M adhesive back for stick on. Made of ABS.UV Resistant, Durable enough to last under all weather conditions.
- Easy Installtion:Simply clean original badge with an Alcohol, then simply lay over the top, gently press to make it more secure. Great way to change style. Self adhesive.(The front grille tailgate emblem fit for both the rear tailgate and front grille..Please check the measurements of your original emblem to verify if this emblem will work on your vehicle. )
- After Service:Our service If you are not satisfied with our products, please contact us and leave us a message by email, we will solve your problem as soon as possible and make you satisfied.
- This fits a variety of Ford vehicles. We would note that the customer should reach out to the seller to verify fitment before purchasing. The VIN # is the only way to truly find fitment for any car part
- 【Function】This tailgate metal emblem for Ford can be used to cover up the chrome plating on your car, or it can be used as a car decoration to make your car more beautiful at a good price.
- 【High Quality】The overlay emblem fits for Ford is made of high-quality ABS and aircraft aluminum, which is corrosion-resistant and UV-resistant, not easy to deform and fade, and can be used in all weather conditions.
- 【Cmpatible】This aluminum oval emblem is compatible with Ford F150 04-14 F250 F350 2005-2007 Edge 2011-2014 Ranger 2006-2011 Expedition 2007-2014 Explorer 2011-2016. In addition to fitting the car grill, you can also stick it on other places of the car.
- 【Easy to Install】The American black flag car emblem has self-adhesive tape, just clean the sticking position, tear off the red sticker on the back of the emblem, then stick it on the original emblem of the car, press it for a while can stick it more firmly.
- 【Fashion Design】This overlay front grille tailgate rear emblems for Ford are unique in design, the pattern is the American flag logo, using exquisite embossed texture design, highlighting the layers with glossy and matte surfaces, low-key luxury, full of fashion and artistic sense.
- High Quality Material: Our 9 Inch American Flag Badge is made of premium ABS and aluminum alloy, ensuring it is not easy to fall off or deform. It is also waterproof and durable, guaranteeing long-lasting use.
- Perfect Fit for Multiple Models: Designed to fit perfectly on the front grill, rear tailgate, and oval emblem of F150 04-14, F250, F350 05-07, Expedition 07-14, Ranger 06-11, Edge 11-14, and Explorer 11-16. It is a great way to give your vehicle a patriotic and stylish look.
- Fits OEM Part : 4L34-15402A-CA 8C3Z-1542528-A
- Easy Installation: Removing the old badge and installing our emblem is a breeze. Simply clean the mounting surface, unscrew the fixing nut, and apply the self-adhesive tape on the back of the badge. No special tools or professional assistance required.
- Please note that it is not suitable for any tailgate with a backup camera.
Last update on 2024-04-09 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
Copyright 2022 Ford Motor Company Stacy L. Balzer Ford Motor Company Operating Director P. O. Box 1904 Service Engineering Operations Dearborn, Michigan 48121 Ford Customer Service Division December 12, 2022 TO: All U.S. Ford and Lincoln Dealers SUBJECT: Recommended New Vehicle Delivery Hold – Component Installation Program 22G05 – Supplement #2 Certain 2022 Model Year F-150 and Super Duty Vehicles Exterior Badge Retrofit REF: Recommended Delivery Hold – Supplement #1 Component Installation Program 22G05 Dated: November 10, 2022 EFC – Supersede of Product Offering Changes: 22MY F150 & Super Duty Temporary Exterior Vehicle Badges Dated: September 30, 2022 F-150 Customer Acknowledgement Form Super Duty Customer Acknowledgement Form New! REASON FOR THIS SUPPLEMENT Service Action: Dealers are to order parts through the SSSC as needed. Claims Preparation And Submission: Causal part number correction. Labor Allowances: Clarification – temporary fender vent badge adjustment is for Super Duty only. Parts: Dealers are to order parts through the SSSC as needed. Correction: The small King Ranch tailgate badge does not apply to the F-150 2022 Model Year in this program. PROGRAM TERMS This program will be in effect through October 31, 2032, or a maximum of 150,000 miles, whichever occurs first. If a vehicle already has accumulated more than 150,000 miles, this coverage will last through October 31, 2023. AFFECTED VEHICLES Vehicle Model Year Assembly Plant Build Dates F-150 2022 Dearborn Beginning July 28, 2022 Kansas City Beginning July 31, 2022 Super Duty 2022 Kentucky Beginning July 23, 2022 Ohio Beginning August 11, 2022 Affected vehicles are identified in OASIS and FSA VIN Lists. Copyright 2022 Ford Motor Company AFFECTED VEHICLES (continued) NOTE: The list of affected VINs may be updated daily as vehicles are added to the program. End build dates will be provided once they are established at all assembly plants. NOTE – Verify VIN status: Some vehicles may be in the process of being repaired at the plant. Monitor OASIS before opening an RO and/or beginning a repair. Parts purchased for an FSA can be returned for credit, if required. See the EXCESS STOCK RETURN details in Attachment II for more information. New! REASON FOR THIS PROGRAM Due to a supplier shortage of exterior vehicle badges, some 2022 Model Year F-150 and Super Duty vehicles will be shipped and can be sold to customers with temporary or missing badges. Temporary/missing badges will not impact the vehicle performance or function. Trucks may not have the same number of temporary badges and/or missing badges. All temporary badges will be molded in color black. • F150 – Temporary F-150 badges could include both side fender vent nameplate/trim badges (e.g., molded in color black in place of F-150/XLT). Missing badges could include both door powertrain badges (e.g., PowerBoost), XLT Texas/Oklahoma badge and/or EcoBoost badge on tailgate. o Correction: The small King Ranch tailgate badge does not apply to the F-150 2022 Model Year. • Super Duty – Temporary Super Duty badges could include both side fender vent nameplate/trim badges (e.g., molded in color black in place of F-250/Lariat). Missing badges could include both door powertrain badges (e.g.,6.7L Power Stroke), and/or King Ranch badge on tailgate. Customers will be required to sign an acknowledgement letter, notifying them of the temporary or missing badges prior to vehicle sale. Reference: Electronic Field Communication (EFC) – Supersede of Product Offering Changes: 22MY F150 & Super Duty Temporary Exterior Vehicle Badges. New! SERVICE ACTION Dealers will install missing badges for all impacted 2022 Model Year F-150 and Super Duty customers. New in-stock vehicles: when possible, install badges prior to new vehicle delivery. • Refer to parts section for updated part ordering details. Dealers are to order parts through the SSSC as needed. • For special or unique situations, (non-involved VIN, different badge count vs. shipped parts, collision repair, etc.) please use the SSSC contact selection Badge Inquiry. • Missing temporary fender vent badges are to be processed as a misbuild. • Verify VIN status: Some vehicles may be in the process of being repaired at the plant. Monitor OASIS before opening an RO and/or beginning a repair. • For Vehicles arriving with production badges – no update necessary: o See Labor Allowances for labor code. o For claim reimbursement please submit four (4) photos that clearly show: VIN Right hand (RH) side – Fender and door Left hand (LH) side – Fender and door Tailgate – Entire tailgate Copyright 2022 Ford Motor Company New! SERVICE ACTION (continued) Dealers are to install the missing badges per technical information – from 1 to 5 badges for F-150 or from 1 to 7 for Super Duty (vehicle specific). Dealers will also remove any temporary fender badges (side vents), clean surfaces, and install new badge(s) in the proper location(s). This service must be performed on all affected vehicles at no charge to the vehicle owner. NOTE: There are temperature requirements in the technical information for certain badges. To assist vehicle owners to have this update completed, dealers should: • Arrange for a mobile repair at the owner’s location, • Mobile service should be made available for all customers. Refer to the Claiming sections for further details. NOTE: Please notify the SSSC if vehicle is being dealer traded or otherwise delivered by another dealer (include new delivering Dealer in SSSC contact). NOTE: Ford Oval badges are not included in this program and should be considered a misbuild if missing. CUSTOMER NOTIFICATION Owner letters are expected to be mailed the week of December 19, 2022. Dealers should repair any affected vehicles that arrive at their dealerships, whether or not the customer has received a letter. New! ATTACHMENTS Attachment I: Administrative Information Attachment II: Labor Allowances and Parts Ordering Information Attachment III: Technical Information – F150 Attachment IV: Technical Information – Super Duty Attachment V: Mobile Service Record Attachment VI: Interim Service Procedure – Super Duty Fender Vent Owner Letter QUESTIONS & ASSISTANCE For questions and assistance, contact the Special Service Support Center (SSSC) via the SSSC Web Contact Site. The SSSC Web Contact Site can be accessed through the Professional Technician System (PTS) website using the SSSC link listed at the bottom of the OASIS VIN report screen or listed under the SSSC tab. Sincerely, Stacy L. Balzer Copyright 2022 Ford Motor Company ATTACHMENT I Page 1 of 3 Recommended New Vehicle Delivery Hold – Component Installation Program 22G05 – Supplement #2 Certain 2022 Model Year F-150 and Super Duty Vehicles Exterior Badge Retrofit MOBILE REPAIR RECOMMENDATIONS • Confirm with customer a mobile repair is feasible. • Check OASIS prior to going to the customer’s home or business to confirm if any other outstanding FSA needs to be completed. • Transportation – due to the simplicity of this repair, a specialty vehicle is not required. MOBILE REPAIR ADDITIONAL INFORMATION Please ensure the technician brings the following to the mobile repair destination: • Printed Technical Instructions. • Printed Repair/Work Order or any other necessary documentation as customer copy(s) o Documents could also be emailed to the customer. • Shirt/uniform and vehicle graphic with dealership or Ford logos are recommended. • Recommended tools and cleaning supplies: Plastic trim removal tool, isopropyl alcohol, microfiber cleaning cloths, and making tape. MOBILE REPAIR QUESTIONS AND ASSISTANCE • For questions and assistance, contact the Special Service Support Center (SSSC) via the SSSC Web Contact Site. Work with Dealership warranty administrator to create a SSSC contact ID#. • Once an SSSC agent responds to the new contact ID#, you may opt to call the SSSC hotline: (800) 325-5621. OASIS ACTIVATION OASIS will be activated on October 21, 2022. FSA VIN LISTS ACTIVATION FSA VIN Lists will begin to be available through https://web.fsavinlists.dealerconnection.com on October 21, 2022, and continuously updated as vehicles are added to the program. Owner names and addresses will be available once parts are in good status. NOTE: Your FSA VIN Lists may contain owner names and addresses obtained from motor vehicle registration records. The use of such motor vehicle registration data for any purpose other than in connection with this program is a violation of law in several states, provinces, and countries. Accordingly, you must limit the use of this listing to the follow-up necessary to complete this service action. SOLD VEHICLES • Owners of affected vehicles will be directed to dealers for repairs. • Immediately contact any of your affected customers whose vehicles are not on your VIN list but are identified in OASIS. Give the customer a copy of the Owner Notification Letter (when available) and schedule a service date. • Correct other affected vehicles identified in OASIS which are brought to your dealership. • Dealers are to prioritize repairs of customer vehicles over repairs of new and used vehicle inventory. Copyright 2022 Ford Motor Company ATTACHMENT I Page 2 of 3 Recommended New Vehicle Delivery Hold – Component Installation Program 22G05 – Supplement #2 Certain 2022 Model Year F-150 and Super Duty Vehicles Exterior Badge Retrofit STOCK VEHICLES • When possible, correct all affected units in your new vehicle inventory before delivery. • Use OASIS to identify any affected vehicles in your used vehicle inventory. TITLE BRANDED / SALVAGED VEHICLES Affected title branded and salvaged vehicles are eligible for this service action. OWNER REFUNDS Refunds are not approved for this program. RENTAL VEHICLES Rental vehicles are not approved for this program. PHOTO SUBMISSION – Only for vehicle that already have production badges Ford has requested photo evidence of repair completion for this FSA. For claim reimbursement please submit four (4) photos that clearly show: VIN RH side – Fender and door LH side – Fender and door Tailgate – Entire tailgate • Side views to include both fender and door even if door badges are not required. • Photos can be attached using the Mobile PTS “Report a Vehicle Concern”. You can access Mobile PTS using your mobile device at: https://m.fordtechservice.dealerconnection.com/. Note: If you have never used the web-based report a vehicle concern- you will need to create your User Profile prior to accessing “Report a Vehicle Concern” on Mobile PTS. Instructions on how to create a user profile and submit photos can be found in EFC08860. Note: Ensure that your “User Profile” is added/updated to include your STARS ID. This can be done by accessing your User Profile directly at: https://www.gcr.dealerconnection.com/asp/DealerProfile.asp; • After completing the report entry form you can upload a maximum of 5 attachments at once. o If submitting more than one attachment (photo), the files must be saved to the mobile device you’re using, PRIOR to submitting the report. ADDITIONAL REPAIR (LABOR TIME AND/OR PARTS) Additional repairs identified as necessary to complete the FSA should be managed as follows: • For related damage and access time requirements, refer to the Warranty and Policy Manual – Section 6 – Ford/Lincoln Program Policies – Field Service Actions (FSA) – Related Damage. Copyright 2022 Ford Motor Company ATTACHMENT I Page 3 of 3 Recommended New Vehicle Delivery Hold – Component Installation Program 22G05 – Supplement #2 Certain 2022 Model Year F-150 and Super Duty Vehicles Exterior Badge Retrofit ADDITIONAL REPAIR (LABOR TIME AND/OR PARTS) (continued) • For vehicles within new vehicle bumper-to-bumper warranty coverage, no SSSC approval is required. o Ford vehicles – 3 years or 36,000 miles • For vehicles outside new vehicle bumper-to-bumper warranty coverage, submit an Approval Request to the SSSC Web Contact Site prior to completing the repair. New! CLAIMS PREPARATION AND SUBMISSION • Claim Entry: Enter claims using Dealer Management System (DMS) or One Warranty Solution (OWS) online. o When entering claims: Claim type 31: Field Service Action The FSA number 22G05 is the sub code Customer Concern Code (CCC): B60 – Exterior nameplate/badge troubles Condition Code (CC): 39 – Missing Part Causal Part Number: 16720, Part Quantity: 0 o For additional claims preparation and submission information, refer to the Recall and Customer Satisfaction Program (CSP) Repairs in the OWS User Guide. • Related Damage/Additional labor and/or parts: Must be claimed as Related Damage on a separate repair line from the FSA with same claim type and sub code as described in Claim Entry above. IMPORTANT: Click the Related Damage Indicator radio button. • Special Allowances o Mobile service allowances can be claimed for dealer-performed mobile repairs. Dealers that are working with Ford-contracted mobile repair companies should refer to those companies for claiming instructions. o For dealer-performed mobile service, retain a copy of the Service Management signed record (see Attachment IV), with the repair order documentation. o Claim the mobile service allowance Labor Operation Code 22G05MM along with the applicable Labor Operation Code for the repair (refer to the Labor Allowances table in Attachment II). • Provision for Locally Obtained Supplies: Includes isopropyl alcohol, cleaning cloths, and making tape that can be used for multiple vehicles. Submit on the same line as the repair. o Program Code: 22G05 o Misc. Expense: OTHER o Misc. Expense: Claim up to $3.50 Copyright 2022 Ford Motor Company ATTACHMENT II Page 1 of 3 Recommended New Vehicle Delivery Hold – Component Installation Program 22G05 – Supplement #2 Certain 2022 Model Year F-150 and Super Duty Vehicles Exterior Badge Retrofit New! LABOR ALLOWANCES Description Labor Operation Labor Time General admin/processing (per Technical Information) and claimed with one or more of the following labor codes. Includes drive in/out. Cannot be claimed with AA or J. 22G05A 0.3 Hours Super Duty As Needed – Adjust Both Temporary Fender Vent Badges. Assumes Production Level Fender Badges are Unavailable. See Attachment VI – Interim Service Procedure. Claim alone. Can be done in service drive. Program stays open. 22G05AA 0.2 Hours Both LH/RH Front Fender Vent Badge Install – expected to be in pairs. Remove Temporary Badge – Includes Cleaning Surfaces – Any Vehicle line 22G05B 0.1 Hours LH – One Part – Front Door Badge Install (Peel-and-Stick) – F-150 Only (PowerBoost) – Includes Cleaning Surfaces 22G05C 0.1 Hours RH – One Part – Front Door Badge Install (Peel-and-Stick) – F-150 Only (PowerBoost) – Includes Cleaning Surfaces 22G05D 0.1 Hours LH – Two Parts – Front Door Badge Install (Peel-and-Stick) – Super Duty Only (6.7L Power Stroke) – Includes Cleaning Surfaces 22G05E 0.2 Hours RH – Two Parts – Front Door Badge Install (Peel-and-Stick) – Super Duty Only (6.7L Power Stroke) – Includes Cleaning Surfaces 22G05F 0.2 Hours One Tailgate Badge (Peel-and-Stick) – Includes Cleaning Surfaces – Any Vehicle Line – Cannot be claimed with H 22G05G 0.1 Hours Two Tailgate Badges (Peel-and-Stick) – Includes Cleaning Surfaces – Any Vehicle Line – Cannot be claimed with G 22G05H 0.2 Hours Vehicle arrived with Production Badges, No Installation. Submit 4 Photos: VIN, LH side, RH side, Tailgate CLOSES Program. Cannot be claimed with any other code 22G05J 0.2 Hours Labor Allowances continued below Copyright 2022 Ford Motor Company ATTACHMENT II Page 2 of 3 Recommended New Vehicle Delivery Hold – Component Installation Program 22G05 – Supplement #2 Certain 2022 Model Year F-150 and Super Duty Vehicles Exterior Badge Retrofit LABOR ALLOWANCES Mobile Service: Can be used when the repair takes place away from the dealership. If Additional Time is Required Due to Travel, Please Submit an SSSC Approval Form. 22G05MM 0.5 Hours New! PARTS REQUIREMENTS / ORDERING INFORMATION Special Program Part Ordering: To place an order for exterior badges: • Please use the VIN specific missing badges web site to determine parts: o https://22g05badgecheck.com/ o Confirm parts to be ordered match what vehicle needs. • Part orders: Submit a VIN-specific Part Order contact via the SSSC Web Contact Site. • For special or unique situations, (non-involved VIN, different badge count vs. shipped parts, collision repair, etc.) please use the SSSC contact selection Badge Inquiry. NOTE: Correction – The small King Ranch tailgate badge does NOT apply to the F-150 2022 Model Year in this program. NOTE: Ford Oval, and temporary fender vent badges are not included in this program and should be considered a misbuild if missing. NOTE: Dealers will be notified via a DOES II communication if circumstances warrant a change in part supply strategy and when open ordering resumes. DEALER PRICE For latest prices, refer to DOES II. PARTS RETENTION, RETURN, & SCRAPPING Follow the provisions of the Warranty and Policy Manual, Section 1 – WARRANTY PARTS RETENTION AND RETURN POLICIES. If a replaced part receives a scrap disposition, the part must be scrapped in accordance with all applicable local, state and federal environmental protection and hazardous material regulations. Federal law prohibits selling motor vehicle parts or components that are under safety, compliance, or emissions recall. EXCESS STOCK RETURN Excess stock returned for credit must have been purchased from Ford Customer Service Division in accordance with Policy Procedure Bulletin 4000. Copyright 2022 Ford Motor Company ATTACHMENT II Page 3 of 3 Recommended New Vehicle Delivery Hold – Component Installation Program 22G05 – Supplement #2 Certain 2022 Model Year F-150 and Super Duty Vehicles Exterior Badge Retrofit REPLACED FSA PARTS INSPECTION AND SIGN OFF Effective March 1st 2021 all parts replaced as part of an FSA repair with a repair order open date of March 1st 2021 or later must be inspected and signed off on the repair order by a member of your dealers fixed operations management team or an employee the task has been delegated to. If the task is to be delegated to a non-management employee, the employee needs to be someone other than the technician who completed the repair and needs to understand the importance of completing this task consistently and accurately. • All parts replaced as part of an FSA repair should be returned to the parts department following the Warranty Parts Retention and Return Policies. • Inspect the replaced parts to verify the FSA repair was completed. REPLACED FSA PARTS INSPECTION AND SIGN OFF (continued) • If the FSA repair is found to be complete, the designated employee signs the repair order line or parts return stamp area (electronic or hand signed) for the FSA repair indicating the parts were inspected and validated to have been replaced. • After the parts have been inspected, they should be handled based on the guidance in the parts status report in the Online Warranty System (Hold, Return, CORE, Scrap, etc.). • This process is subject to review during warranty audits for FSA repairs with a repair order open date of March 1st 2021 or later. Any eligible FSA claims requiring parts replacement, found not to have been inspected and signed off during a warranty audit will be subject to chargeback and consideration for enrollment into the Dealer Incomplete Recall Repair Process. Note: Other approvals (electronic or handwritten) for add-on repair lines, dealer owned vehicle repairs, and repeat repairs do not qualify as FSA parts inspection approvals. The post repair FSA parts inspection process (electronic or handwritten) is independent from other warranty approval requirements. The approval by the designated employee implies that the FSA parts were found to be replaced and must be able to be clearly identified on the Repair Order. If multiple FSA’s require approval on a single Repair Order, each applicable occurrence will require individual post repair approval by the designated employee. 22G05 Ford Motor Company Ms. Jane Sample 123 Main Street Anywhere, USA 12345 Get ready to flash a new badge. As you know, the supply chain tried to mess with some of our truck badges, but it can’t keep a good truck down. Permanent Ford name badges for your truck are now available, thanks to our hardworking buyers and suppliers. To get your new badges, contact your dealer to place an order and schedule an appointment. One of our qualified service technicians can then replace them at no charge. Please reference your Vehicle Identification Number (VIN) XXXXXXXXXXX and program number 22G05 when you talk to your dealer. Rest assured that we’ll do our best to minimize any inconvenience. The official time frame for you to get this done is now through October 31, 2032, or before your truck reaches 150,000 miles, whichever comes first.* You deserve a perfect owner experience from the moment you order a Ford vehicle. While the supply chain didn’t make that possible this time, we’re ready to make things right. If you have any questions or concerns, please feel free to call our Customer Care Center at 1-866-436-7332. Or for fleet owners, please call our Ford Pro™ Contact Center at 1-800-34-FLEET (option #1). Sincerely, Andrew Frick Vice President, Sales, Distribution and Trucks Ford Motor Company *Coverage is automatically transferred to subsequent owners. ATTACHMENT III PAGE 1 OF 9 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 CERTAIN 2022 MODEL YEAR F-150 AND SUPER DUTY VEHICLES – EXTERIOR BADGE RETROFIT SERVICE PROCEDURE F-150 VEHICLES Table Of Contents Front Fender Vent Badges Left Hand/Right Hand (LH/RH)………………………..2 Front LH Door Badge……………………………………………………………………………..3 PowerBoost………………………………………………………………………………..3 Front RH Door Badge……………………………………………………………………………..4 PowerBoost………………………………………………………………………………..4 Tailgate Badge……………………………………………………………………………………….5 EcoBoost……………………………………………………………………………………5 Texas Edition………………………………………………………………………………6 Oklahoma Edition……………………………………………………………………….7 Tremor………………………………………………………………………………………..8 Raptor………………………………………………………………………………………..9 NOTE: Ford Oval badges are not included in this program and should be considered a mis-build if missing. IMPORTANT: Badges must be installed when ambient temperatures and surface temperatures of vehicle and badge are confirmed to be between 60°F (16°C) and 100°F (38°C). Materials List Ruler/Scale (12″/30cm minimum) Clean Cloths Masking Tape Isopropyl Alcohol Plastic Trim Tool MOBILE SERVICE INSTRUCTIONS NOTE: If you suspect that you will not have Internet access at the vehicle’s mobile service location then, you should print a copy of these instructions (including any required Workshop Manual references) for reference during the mobile service. ATTACHMENT III PAGE 2 OF 9 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 Front Fender Vent Door Badges (LH/RH) NOTE: RH and LH front fender vent door badges are expected to be updated in pairs. If a normal production level badge is present, do not replace it (it should match the new part though). 1. Using a plastic trim tool, remove the LH side temporary front fender door badge. See Figure 1. NOTE: RH side shown, LH side similar. FIGURE 1 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624F ONLY REPLACE TEMPORARY FRONT FENDER VENT DOOR BADGES 2. Using isopropyl alcohol and a clean cloth, wipe the area where the new badge is to be installed. 3. Using another clean cloth, dry the area that was cleaned. 4. Allow the isopropyl alcohol one minute to fully evaporate. 5. Remove the tape liner from the back of the new badge 6. Install the new badge by aligning the clips on the back with the holes in the sheet metal and pressing in until they click. 7. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. 8. Repeat steps 1-7 for the RH side of the vehicle. ATTACHMENT III PAGE 3 OF 9 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 2 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624C 80 F 60 100 100 80 C 16 38 Front of Vehicle Front LH Door Badge – PowerBoost 9. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 10. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed. 11. Using another clean cloth, dry the area that was cleaned. 12. Allow the isopropyl alcohol one minute to fully evaporate. 13. Measure and apply locating masking tape to the front LH door outer panel. See Figure 2. 14. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 3. 15. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 3. FIGURE 3 22624D ATTACHMENT III PAGE 4 OF 9 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 4 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624A Front of Vehicle 80 F 60 100 100 80 C 16 38 Front RH Door Badge – PowerBoost 16. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 17. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed. 18. Using another clean cloth, dry the area that was cleaned. 19. Allow the isopropyl alcohol one minute to fully evaporate. 20. Measure and apply locating masking tape to the front RH door outer panel. See Figure 4. 21. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 5. 22. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 5. FIGURE 5 22624B ATTACHMENT III PAGE 5 OF 9 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 6 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624M 80 F 60 100 100 80 C 16 38 Tailgate Badge – EcoBoost 23. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 24. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed. 25. Using another clean cloth, dry the area that was cleaned. 26. Allow the isopropyl alcohol one minute to fully evaporate. 27. Measure and apply locating masking tape to the tailgate outer panel. See Figure 6. 28. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 7. 29. Using medium hand pressure, press for 3 seconds at a minimum of 3 separate locations along the length of the badge until the tape is fully adhered. See Figure 7. FIGURE 7 22624N ATTACHMENT III PAGE 6 OF 9 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 10 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624G 80 F 60 100 100 80 C 16 38 Tailgate Badge – Texas Edition 30. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 31. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed. 32. Using another clean cloth, dry the area that was cleaned. 33. Allow the isopropyl alcohol one minute to fully evaporate. 34. Measure and apply locating masking tape to the tailgate outer panel. See Figure 10. 35. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 11. 36. Using medium hand pressure, press for 3 seconds at a minimum of 2 separate locations along the length of the badge until the tape is fully adhered. See Figure 11. FIGURE 11 22624H ATTACHMENT III PAGE 7 OF 9 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 12 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624I 80 F 60 100 100 80 C 16 38 Tailgate Badge – Oklahoma Edition 37. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 38. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed. 39. Using another clean cloth, dry the area that was cleaned. 40. Allow the isopropyl alcohol one minute to fully evaporate. 41. Measure and apply locating masking tape to the tailgate outer panel. See Figure 12. 42. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 13. 43. Using medium hand pressure, press for 3 seconds at a minimum of 2 separate locations along the length of the badge until the tape is fully adhered. See Figure 13. FIGURE 13 22624J ATTACHMENT III PAGE 8 OF 9 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 14 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624Y 80 F 60 100 100 80 C 16 38 Tailgate Badge – Tremor 44. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 45. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed. 46. Using another clean cloth, dry the area that was cleaned. 47. Allow the isopropyl alcohol one minute to fully evaporate. 48. Measure and apply locating masking tape to the tailgate outer panel. See Figure 14. 49. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 15. 50. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 15. FIGURE 15 22624Z ATTACHMENT III PAGE 9 OF 9 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 16 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624AA 80 F 60 100 100 80 C 16 38 Tailgate Badge – Raptor 51. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 52. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed. 53. Using another clean cloth, dry the area that was cleaned. 54. Allow the isopropyl alcohol one minute to fully evaporate. 55. Measure and apply locating masking tape to the tailgate outer panel. See Figure 16. 56. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 17. 57. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 17. FIGURE 17 22624AB ATTACHMENT IV PAGE 1 OF 7 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 CERTAIN 2022 MODEL YEAR F-150 AND SUPER DUTY VEHICLES – EXTERIOR BADGE RETROFIT SERVICE PROCEDURE SUPER DUTY VEHICLES Table Of Contents Front Fender Vent Badges Left Hand/Right Hand (LH/RH)………………………..2 Front LH Door Badge……………………………………………………………………………..3 Power Stroke………………………………………………………………………………3 6.7L…………………………………………………………………………………………….4 Front RH Door Badge……………………………………………………………………………..5 Power Stroke………………………………………………………………………………5 6.7L…………………………………………………………………………………………….6 Tailgate Badge……………………………………………………………………………………….7 King Ranch…………………………………………………………………………………7 NOTE: Ford Oval badges are not included in this program and should be considered a mis-build if missing. NOTE: For temporary fender vent badge adjustments see Attachment VI – Interim Service Procedure. IMPORTANT: Badges with adhesive must be installed when ambient temperatures and surface temperatures of vehicle and badge are confirmed to be between 60°F (16°C) and 100°F (38°C). Materials List Ruler/Scale (12″/30cm minimum) Clean Cloths Masking Tape Isopropyl Alcohol Plastic Trim Tool MOBILE SERVICE INSTRUCTIONS NOTE: If you suspect that you will not have Internet access at the vehicle’s mobile service location then, you should print a copy of these instructions (including any required Workshop Manual references) for reference during the mobile service. ATTACHMENT IV PAGE 2 OF 7 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 Front Fender Vent Door Badges (LH/RH) NOTE: RH and LH front fender vent door badges are expected to be updated in pairs. If a normal production level badge is present, do not replace it (it should match the new part though). 1. Using a plastic trim tool, remove the LH side temporary front fender door badge. See Figure 1. NOTE: RH side shown, LH side similar. FIGURE 1 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624E ONLY REPLACE TEMPORARY FRONT FENDER VENT DOOR BADGES NOTE: To remove temporary badge metal clips from the body – release the metal clip from the back side by pushing up so the clips rotate into the holes. 2. Using isopropyl alcohol and a clean cloth, wipe the area where the new badge is to be installed. 3. Using another clean cloth, dry the area that was cleaned. 4. Allow the isopropyl alcohol one minute to fully evaporate. 5. Install the new badge by aligning the clips on the back with the holes in the sheet metal and pressing in until they click. 6. Repeat steps 1-5 for the RH side of the vehicle. ATTACHMENT IV PAGE 3 OF 7 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 2 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624O Front of Vehicle 100 80 80 F 60 100 100 80 C 16 38 12. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 3. 13. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 3. FIGURE 3 22624P Front LH Door Badge – Power Stroke 7. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 8. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed. 9. Using another clean cloth, dry the area that was cleaned. 10. Allow the isopropyl alcohol one minute to fully evaporate. 11. Measure and apply locating masking tape to the front LH door outer panel. See Figure 2. ATTACHMENT IV PAGE 4 OF 7 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 4 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624Q Front of Vehicle 80 F 60 100 100 80 C 16 38 Front LH Door Badge – 6.7L 14. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 15. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed. 16. Using another clean cloth, dry the area that was cleaned. 17. Allow the isopropyl alcohol one minute to fully evaporate. 18. Measure and apply locating masking tape to the front RH door outer panel. See Figure 4. 19. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 5. 20. Using medium hand pressure, press for 3 seconds at a minimum of 2 separate locations along the length of the badge until the tape is fully adhered. See Figure 5. FIGURE 5 22624R ATTACHMENT IV PAGE 5 OF 7 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 6 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624S Front of Vehicle 80 F 60 100 100 80 C 16 38 Front RH Door Badge – Power Stroke 21. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 22. Using isopropyl alcohol and a clean cloth, wipe the area where the badge is to be installed. 23. Using another clean cloth, dry the area that was cleaned. 24. Allow the isopropyl alcohol one minute to fully evaporate. 25. Measure and apply locating masking tape to the front outer panel. See Figure 6. 26. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 7. 27. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 7. FIGURE 7 22624T ATTACHMENT IV PAGE 6 OF 7 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 8 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624U Front of Vehicle 80 F 60 100 100 80 C 16 38 Front RH Door Badge – 6.7L 28. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 29. Using isopropyl alcohol and a clean cloth, wipe the area that the badge is to be installed at. 30. Using another clean cloth, dry the area that was cleaned. 31. Allow the isopropyl alcohol one minute to fully evaporate. 32. Measure and apply locating masking tape to the front RH door outer panel. See Figure 8. 33. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 9. 34. Using medium hand pressure, press for 3 seconds at a minimum of 2 separate locations along the length of the badge until the tape is fully adhered. See Figure 9. FIGURE 9 22624V ATTACHMENT IV PAGE 7 OF 7 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 FIGURE 10 PLACE COPY HERE PLACE COPY HERE PLACE COPY HERE STUD FOR MISSING NUT STUD FOR MISSING NUT 22624W 80 F 60 100 100 80 C 16 38 Tailgate Badge – King Ranch 35. Confirm that the ambient temperature and surface temperature of both the vehicle and badge are between 60°F (16°C) and 100°F (38°C). 36. Using isopropyl alcohol and a clean cloth, wipe the area that the badge is to be installed at. 37. Using another clean cloth, dry the area that was cleaned. 38. Allow the isopropyl alcohol one minute to fully evaporate. 39. Measure and apply locating masking tape to the tailgate outer panel. See Figure 10. 40. Remove the tape liner from the back of the badge and install to the door using the locating tape to properly align the badge. See Figure 11. 41. Using medium hand pressure, press for 3 seconds at a minimum of 4 separate locations along the length of the badge until the tape is fully adhered. See Figure 11. FIGURE 11 22624X ATTACHMENT VI PAGE 1 OF 1 COMPONENT INSTALLATION PROGRAM 22G05-S2 CPR © 2022 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121 12/2022 CERTAIN 2022 MODEL YEAR F-150 AND SUPER DUTY VEHICLES – EXTERIOR BADGE RETROFIT INTERIM SERVICE PROCEDURE SUPER DUTY VEHICLES – TEMPORARY FENDER VENT BADGE RESET NOTE: This procedure is only for the temporary fender vent badges that are rubbing/touching the door. WARNING: Too much force will break the temporary fender vent badge. 1. Using a plastic trim panel tool, perform the following steps; See Figure 1 • In the highlighted recessed section only • Gently pull the badge outward from the inside edge of the badge • Move the trim stick up and down several times to reset the plastic • Recheck the door for rubbing/touching NOTE: Driver’s side shown, passenger side similar. NOTE: Temporary badges were NOT released for service and if missing are to be considered a misbuild from the assembly plant. A Special Support Service Center (SSSC) contact may also be created for support. 2205K FIGURE 1
SEOCONTENT-END
