NHTSA ID Number: 10239474
Manufacturer Communication Number: TSB 23-2208
Summary
Some 2020-2023 Explorer/Aviator non-hybrid vehicles may exhibit radio static and/or poor radio sound quality when moving. This may be more noticeable on AM radio stations. This may be caused by an electromagnetic interference concern. To correct the condition, follow the Service Procedure to install new grounds on the rear knuckle.
This bulletin supersedes 22-2040.
Model:
| Ford
2020-2023 Explorer |
Non-hybrid
|
| Lincoln
2020-2023 Aviator |
Non-hybrid
|
Summary
This article supersedes TSB 22-2040 to update the vehicle model years affected.
Issue: Some 2020-2023 Explorer/Aviator non-hybrid vehicles may exhibit radio static and/or poor radio sound quality when moving. This may be more noticeable on AM radio stations. This may be caused by an electromagnetic interference concern. To correct the condition, follow the Service Procedure to install new grounds on the rear knuckle.
Action: Follow the Service Procedure to correct the condition on vehicles that meet all of the following criteria:
- 2020-2023 Explorer/Aviator
- Non-hybrid powertrain
- Radio static and/or poor radio sound quality when moving
Parts
| Service Part Number | Quantity | Description | Unit of Issue | Piece Quantity |
| L1MZ-14A411-N | 2 | Ground Strap Jumper Harness | 1 | 2 |
Quantity refers to the amount of the service part number required to repair the vehicle.
Unit of Issue refers to the number of individual pieces included in a service part number package.
Piece Quantity refers to the total number of individual pieces required to repair the vehicle.
Service Procedure
1. Install new ground straps on each side of the vehicle on top of the brake hose bracket bolt on the rear knuckle. Tighten to 133 lb-in (15 Nm). Refer to Workshop Manual (WSM), Section 204-02. (Figure 1-2)
Figure 1
Figure 2
2. Install the other side of the ground straps underneath the rear wheel speed sensor harness bracket mounting stud. Tighten to 62 lb-in (7 Nm). Refer to WSM, Section 206-09. (Figure 1-2)
8 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| FORD | EXPLORER | 2020-2023 |
| LINCOLN | AVIATOR | 2020-2023 |
1 Associated Document
Manufacturer Communications
23-2208
12 July 2023
https://www.nhtsa.gov/recalls?nhtsaId=10239474
MC-10239474-0001.pdf 451.728KB
Loading...
Reload document
Open in new tab
