NHTSA ID Number: 10228864
Manufacturer Communication Number: SSM 51247
Summary
Some 2020-2022 Explorer vehicles equipped with a 2.3L engine may exhibit an illuminated malfunction indicator lamp (MIL) with multiple diagnostic trouble codes (DTCs). These DTCs may include P04F0, P008A, P0451, P0455, P0456, P0496 and/or P018C. This may be due to the wiring harness connection at connector C1198 on driver’s side lower frame area underneath the brake lines that route near the electric brake booster (EBB). Prior to replacement of any components, inspect the connector and wiring harness for any damage or pin fit concerns. If any damage or pin fit concerns are found, repair the connector or harness as necessary. If no damage or pin fit concerns are found, refer to normal diagnostics. Refer to Wiring Diagram (WD) Cell 22-12 to view the 3 voltage reference (VREF) wires at C1198 on the 2.3L engine.
3 Affected Products
Vehicle
| MAKE | MODEL | YEAR |
| FORD | EXPLORER | 2020-2022 |
1 Associated Document
Manufacturer Communications
SSM 51247
2020-2022 Explorer – 2.3L – Illuminated Malfunction Indicator Lamp (MIL) With DTCs P04F0, P008A, P0451, P0455, P0456, P0496 And/Or P018C
https://static.nhtsa.gov/odi/tsbs/2022/MC-10228864-0001.pdf
MC-10228864-0001.pdf 102.161KB
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10224335
Manufacturer Communication Number: SSM 51132
Summary
Some 2020-2022 Explorer vehicles equipped with a 2.3L engine may exhibit an illuminated malfunction indicator lamp (MIL) with multiple diagnostic trouble codes (DTCs). These DTCs may include P04F0, P008A, P0451, P0455, P0456, P0496 and/or P018C. This may be due to the wiring harness connection at connector C1198. Prior to replacement of any components, inspect the connector and wiring harness for any damage or pin fit concerns. If any damage or pin fit concerns are found, repair the connector or harness as necessary. If no damage or pin fit concerns are found, refer to normal diagnostics.
1 Associated Document
Manufacturer Communications
SSM 51132 2020-2022 Explorer – 2.3L – Illuminated Malfunction Indicator Lamp (MIL) With DTCs P04F0, P008A, P0451, P0455, P0456, P0496 And/Or P018C
https://www.nhtsa.gov/recalls?nhtsaId=10224335
MC-10224335-0001.pdf 120.514KB
Loading...
NHTSA ID Number: 10205484
Manufacturer Communication Number: SSM 50348
Summary
Some 2020-2022 Explorer/Aviator vehicles may exhibit an illuminated MIL with multiple diagnostic trouble codes (DTC). These DTCs may include P04F0, P008A, P0451, P0455, P0456, P0496 and/or P018C. This may be due to the wiring harness connection at connector C1198. Prior to replacement of any components, inspect the connector and wiring harness for any damage or pin fit concerns. If any damage or pin fit concerns are found, repair the connector or harness as necessary. If no damage or pin fit concerns are found, refer to normal diagnostics.
1 Associated Document
Manufacturer Communications
SSM 50348 – 2020-2022 Explorer/Aviator – Illuminated Malfunction Indicator Lamp (MIL) With DTC P04F0, P008A, P0451, P0455, P0456, P0496 And/Or P018C
https://www.nhtsa.gov/recalls?nhtsaId=10205484
