21M08 – Unintended Tailgate Opening – 2021-2022 Ford F-150

“This site contains affiliate links for which OEMDTC may be compensated”

NHTSA ID Number: 10226950

Manufacturer Communication Number: 21M08 S2

Summary

Certain 2021-2022 Model Year F-150 Vehicles Equipped with a Power Release Tailgate – Unintended Tailgate Opening

REASON FOR THIS SUPPLEMENT

Vehicles Covered By This Program: Updated affected vehicle build dates.

Technical Information: Updated with revised instructions to account for wiring harness changes that were implemented into production. As a result, the Labor Allowances and Parts Requirements / Ordering Information have also been updated accordingly.

Parts Requirements / Ordering Information: All parts are on open order. Special Service Support Center (SSSC) contact is no longer required to order tailgate actuator ground wiring kit




November 7, 2022

Customer Satisfaction Program 21M08 Supplement #2
Certain 2021-2022 Model Year F-150 Vehicles Equipped with a Power Release
Tailgate – Unintended Tailgate Opening



REASON FOR THIS SUPPLEMENT

  • Vehicles Covered By This Program: Updated affected vehicle build dates.
  • Technical Information: Updated with revised instructions to account for wiring harness changes that were implemented into production. As a result, the Labor Allowances and Parts Requirements / Ordering Information have also been updated accordingly.
  • Parts Requirements / Ordering Information: All parts are on open order. Special Service Support Center (SSSC) contact is no longer required to order tailgate actuator ground wiring kit.



PROGRAM TERMS

This program provides a no-cost repair (if needed) to the power release tailgate feature for 10 years of service or 150,000 miles from the warranty start date of the vehicle, whichever occurs first.

This program may be used multiple times as long as the vehicle is within time and mileage limits of the program. Once the program has expired, Service Part Warranty (SPW) and Extended Service Plan (ESP) may be eligible.

If a vehicle has already exceeded either the time or mileage limits, this no-cost repair will last through February 28, 2023.

Coverage is automatically transferred to subsequent owners.



VEHICLES COVERED BY THIS PROGRAM

Vehicle Model Year Assembly Plant Build Dates
F-150 2021-2022 Dearborn January 10, 2020 through April 19, 2022
Kansas City February 12, 2020 through May 11, 2022

Affected vehicles are identified in OASIS.



REASON FOR PROVIDING A NO-COST REPAIR

In the affected vehicles, some customers report experiencing an unintended tailgate opening and may have previously serviced their vehicle for this concern. Ford has developed an enhanced remedy for customers who may want this enhanced repair performed on their vehicle.



SERVICE ACTION

If a vehicle included in Field Service Action (FSA) 21M08 has sustained damage to the tailgate due to an unintended tailgate opening, please refer to the claiming instructions for related damage.

If an affected vehicle owner has reported an unintended tailgate opening, dealers are to modify the power release tailgate system wiring, install a new tailgate handle release switch and reprogram the BCM software using the Ford Diagnosis and Repair System (FDRS).

NOTE: IDS cannot be used for programming on 2021-2022 F-150 vehicles.

Customer Information Sheet and Owner’s Manual Addendum: At the completion of this repair, dealership service management is to provide a copy of the “Customer Information Sheet” and “Owner’s Manual Addendum” that is posted with this bulletin to the vehicle owner.

This service must be performed on all affected vehicles at no charge to the vehicle owner.

NOTE: The tailgate is required to be installed on the vehicle to perform the repair.

NOTE: Parts are currently not available in sufficient quantities to repair all vehicles. Part orders can be requested through the Special Service Support Center (SSSC) using the SSSC link at the bottom of the OASIS VIN report screen to repair vehicles. The SSSC will only accept orders if:

  • The vehicle is currently at the dealership and the customer has reported experiencing an unintended tailgate opening.
  • The dealer has an open Repair Order (RO) on the Vehicle Identification Number (VIN) with an unintended tailgate opening concern.



OWNER NOTIFICATION AND MAILING SCHEDULE

Owners of affected vehicles have been notified. Dealers should repair any affected vehicles that experience unintended tailgate opening, whether or not the customer has received a letter.



SOLD VEHICLES

  • Only owners with affected vehicles that exhibit the covered condition will be directed to dealers for repairs.
  • Dealers are to prioritize repairs of customer vehicles over repairs of new and used vehicle inventory.



STOCK VEHICLES

Do not perform this program unless the affected vehicle exhibits the covered condition.



TITLE BRANDED / SALVAGED VEHICLES

Vehicles with cancelled warranties are not eligible for this service action.



OWNER REFUNDS

  • Ford Motor Company is offering a refund for owner-paid repairs covered by this program if the repair was performed before the date of the Owner Notification Letter. This refund offer expires February 28, 2023.
  • Dealers are also pre-approved to refund owner-paid emergency repairs that were performed away from an authorized servicing dealer after the date of the Owner Notification Letter. Noncovered repairs, or those judged by Ford to be excessive, will not be reimbursed.
  • Refunds will only be provided for the cost associated with repairs associated with unintended tailgate opening.



RENTAL VEHICLES

The use of rental vehicles is not approved for this program.



PARTS REQUIREMENTS

Part Number  Description Order Quantity
ML3Z-14A411-S Tailgate Actuator Ground Wiring Kit 1 As Needed
GB5Z-9C888-B Tailgate Handle Release Switch 1
ML3Z-9941018-AB Tailgate Moulding – WITHOUT Tailgate Step As Required
ML3Z-9941018-AC Tailgate Moulding – WITH Tailgate Step
PM-13-BeBay Motorcraft® Anti-Corrosion Coating*

(Only F-150 Super Cab vehicles, As Needed)

– 6 fl. Oz per container, sell pack of 1, 1/2 Oz per repair, repair 32 vehicles per can.

As Needed
or Equivalent
Part Number  Description Order Quantity
Obtain Locally Electrical Wire Harness Tape*

Coroplast® 837 or Equivalent.

– Can be obtained from Rotunda (NAI837X) or Narin.

Claim as Misc.

OTHER

Black Electrical Tape*
Rosin Core Solder*

* The listed tapes and chemicals can be used on multiple vehicles.




CERTAIN 2021-2022 MODEL YEAR F-150 VEHICLES EQUIPPED WITH A POWER RELEASE TAILGATE — UNINTENDED TAILGATE OPENING

For Vehicles Built AFTER December 14, 2021 complete the Factory Installation Inspection
For Vehicles Built ON December 14, 2021 OR PRIOR, proceed to the next page



Factory Installation Inspection

NOTE: Service Procedure Steps on Page 6, Step 8, Figure 4 through Page 11, Step 18, Figure 14, and Page 19, Step 35, Figure 30 through Page 29, Step 50, Figure 47 can be skipped if the wires are in the correct pin locations for ALL 3 of the following inspections. ALL of the Service Procedure Steps listed above will need to be completed if any one of the circuits in Steps 1, 2, or 3 are missing. This may require depinning circuit(s) to install the Relay Harness and Body Length Harness.

NOTE: Tailgate Harness Inspection needs to be performed on ALL vehicles.

1. Page 7, Step 10, Figure 6. Inspect the female end of C212 for a Gray (GY) wire in pin 1 and a Gray-Orange (GY-OG) wire in pin 4. If both wires are present, Proceed to Step 2.

2. Page 28, Step 48, Figure 45. Inspect the male end of C212 for a Blue-Gray (BL-GY) wire in pin 1 and a GY-OG wire in pin 4. If both wires are present, Proceed to Step 3.

3. Page 19, Step 35, Figure 30. Inspect the female end of C4002 for a Black-Violet (BK-VT) wire in pin 2. If the wire is present, Proceed to Step 4.



Tailgate Harness Inspection – Must be performed on ALL vehicles

4. Page 20, Step 36, Figure 31. Inspect the male end of C4002 for a BK-VT wire in pin 2. If the wire is present the tailgate harness rework will not need to be completed. If any other color of wire is present, then the tailgate harness rework must be completed.



Complete Tailgate Actuator Ground Wiring Part Kit

ITEM DESCRIPTION QUANTITY
A Relay Harness 1
B Tie Strap
C Edge Biter Style Tie Strap
D Oval Push Pin Style Tie Strap
E Round Push Pin Style Tie Strap
F Tailgate Jumper Harness 1
G Grommet 1
H Heat Shrink Tubing
I Body Length Jumper Harness 1



NOTE: Not all parts in the kit will be used for some vehicles built after December 14, 2021.

NOTE: The parts being installed in this procedure are not labeled. Refer to Figure 1 for component identification.



SERVICE PROCEDURE

NOTE: At the completion of this repair, dealership service management is to provide a copy of the “Customer Information Sheet” and a copy of the “Owner’s Manual Addendum” that is posted with this bulletin to the vehicle owner.

NOTE: The tailgate is required to be installed on the vehicle to perform the repair.

1. Position the vehicle on a hoist. Please follow the Workshop Manual (WSM) procedures in Section 100-02.

2. Remove the Glove Compartment. Please follow the WSM procedures in Section 501-12.

3. Lower the tailgate of the vehicle.

4. Disconnect the negative battery cable(s) and position aside. Please follow the WSM procedures in Section 414-01.

5. Remove the Right Hand (RH) Front Scuff Plate Trim Panel. Please follow the WSM procedures in Section 501-05.

6. Release the clips and remove the RH lower cowl trim panel. See Figure 2.

  • Release the molded snap in the fuse panel cover then rotate fuse panel inboard and forward to disengage hooks from the cowl trim.



7. Using an Interior Trim Remover, remove the push pins and the RH insulation panel. See Figure 3.



8. Place the Relay Harness, included in the kit, onto the Body Control Module (BCM) wiring harness and secure using a tie strap. See Figure 4.



9. Locate and disconnect C212 on the climate control housing. See Figure 5.



10. Remove the green locking tab on the female end of C212. See Figure 6.



11. Install the Black (BK) wire from the relay into Pin 1 of the female end of C212. See Figure 7.



12. Install the green locking tab into the female end of C212. See Figure 8.

NOTE: Do not reconnect the electrical connector at this time.



CAUTION: Do not over torque the ground stud nut.

13. Install the ground eyelet to the ground stud. See Figure 9.

  • Remove the nut from the ground stud.
  • Install the BK ground wire with the eyelet onto the ground stud.
  • Reinstall the nut to the ground stud.
  • Torque: 70 lb. in (8 Nm)



14. Disconnect C2280A and C2280B from the BCM. See Figure 10.



15. Remove the red locking tab of C2280A. See Figure 11.



16. Release and position aside the connector cover. Route the Grey (GY) wire from the relay through the cover and install the terminal into Pin 7. See Figure 12.



17. Position back the connector cover and install the red locking tab of C2280A. See Figure 13.



18. Install the Grey-Orange (GY-OG) wire from the relay into C2280B. See Figure 14.

  • Remove the tie strap.
  • Release the locking tabs.
  • Remove the inserts from the connector cover.
  • Install the GY-OG wire into Pin 12.
    • If Pin 12 is occupied, remove the terminal and follow sub-steps a through d.

a. Cut off the terminal from the GY-OG wire from the relay.
b. In-line splice the GY-OG wire from the relay onto the wire that occupied Pin 12.
c. Apply solder to the splice and seal using heat shrink tubing.
d. Reinstall the wire into Pin 12.

  • Reinstall the inserts into the connector cover.
  • Install a new tie strap and trim any excess.



19. Position aside the RH carpet to expose the floorboard. Use a block of wood or similar device to retain the carpet away from the area to be clear of obstruction. See Figure 15.

CAUTION: The area highlighted below should be kept clear from obstruction to avoid any damage to carpeting and/or wiring.



20. If equipped, push the tailgate step release button. See Figure 16.



21. If equipped, open the tailgate step. See Figure 17.



22. If equipped, remove the bedliner tailgate cover. See Figure 18.



23. If equipped, remove the tailgate access panel bolts and the tailgate access panel. See Figure 19.



24. If equipped, remove the workspace tailgate access panel bolts and the workspace tailgate access panel. See Figure 20.



25. Remove the tailgate latch control assembly nuts and position the tailgate latch control assembly towards the rear of the vehicle. See Figure 21.



26. Disconnect the electrical connector and the push pin retainer. See Figure 22.

NOTE: Tailgate latch control assembly shown outside of the vehicle for clarity.



27. Remove the white locking tab and the Black-Yellow (BK-YW) wire from the tailgate latch control assembly connector. Cut off the terminal of the BK-YW wire. See Figure 23.



28. Seal the BK-YW wire using heat shrink tubing. Bend back the sealed wire and secure using Coroplast® 837 or Equivalent Electrical Wire Harness Tape. See Figure 24.



29. Install the Tailgate Jumper Harness non-sealed end terminal into the open pin in the tailgate latch control assembly electrical connector. Secure using Coroplast® 837 or Equivalent Electrical Wire Harness Tape. Reinstall the white locking tab. See Figure 25.



30. Reconnect the electrical connector and the push pin retainer. See Figure 26.

NOTE: Tailgate latch control assembly shown outside of the vehicle for clarity.



31. Using a straightened coat hanger, tape the sealed terminal end of the Tailgate Jumper Harness Wire to one end of the coat hanger. Route the wire and coat hanger on the Left Hand (LH) side of the tailgate latch control assembly and through the opening in the center bottom of the tailgate. Continue to pass through the opening in the bed and down through the bottom of the vehicle. See Figure 27.



32. Secure the Tailgate Jumper Harness using tie straps and trim any excess length of tie strap. See Figure 28.



33. Position back the tailgate latch control assembly and install the nuts. See Figure 29.

  • Torque 80 lb.in (9 Nm)



34. Replace the Tailgate Release Switch. Please follow the WSM procedures in Section 501-14.

  • For vehicle equipped with the 360 Degree View Camera system or with the digital Rear Only Parking Aid Camera system, do not perform the 360 Degree View Camera Alignment at this time.

35. Release the C4002/C4003 retainer and disconnect C4002, C4003 and C4321. See Figure 30.



36. Remove any tape and/or convolute from the gray C4002 male end to expose the Black (BK) dummy wire. Cut the BK dummy wire just in front of the heat shrink tubing and discard the heat shrink end. Cut off the sealed terminal on the Tailgate Jumper Harness. Install a new piece of heat shrink tubing, twist the Tailgate Jumper Harness and the C4002 male end BK dummy wire together. See Figure 31.



37. Solder the twisted wires and apply and seal the heat shrink tubing. See Figure 32. Reapply the convolute and/or black electrical tape.



38. Remove any tape and/or convolute from the gray C4002 female end to expose the Black (BK) dummy wire. Cut the BK dummy wire just in front of the heat shrink tubing and discard the heat shrink end. Cut off the sealed terminal on the Body Length Jumper Harness. Install a new piece of heat shrink tubing, twist the Body Length Jumper Harness and the C4002 female end black dummy wire together. Solder the twisted wires and apply and seal the heat shrink tubing. Reapply the convolute and/or black electrical tape. See Figure 33.



39. Reconnect C4002, C4003, C4321 and the C4002/C4003 retainer. See Figure 34.



40. Route the Body Length Jumper Harness along the LH frame rail towards the front of the vehicle keeping the harness as close to the bed as possible. Secure using tie straps approximately every 12 in (305 mm). See Figure 35.

NOTE: The tie straps were left untrimmed for clarity. Trim any excess from the tie straps once installed.



41. Continue to route the Body Length Jumper Harness along the LH frame rail. Once at the fuel tank, route the Body Length Jumper Harness across the crossbrace to the RH side of the frame rail. Secure the Body Length Jumper Harness to the existing harness and to the holes within the crossbrace using the assorted supplied tie straps approximately every 12 in (305 mm). See Figures 36 and 37.



42. Route the Body Length Jumper Harness over the RH frame rail and continue on the outboard RH frame rail as close to the bed as possible. Secure the Body Length Jumper Harness to the holes within the underside of the bed and the outboard RH frame using the assorted supplied tie straps approximately every 12 in (305 mm). See Figure 38.



43. ALL vehicles equipped WITH power running boards have a grommet located on the front passenger floorboard. Super Cab vehicles WITHOUT power running boards have no hole present on the front passenger floorboard. Crew Cab vehicles WITHOUT power running boards have a plug on the front passenger floorboard. See Figure 39.

– Is the vehicle equipped with power running boards or have a body plug on the floor?

YES – Proceed to Step 46.
NO – Proceed to Step 44.

NOTE: Floorboard grommet shown, floorboard plug similar.



44. Locate the floorboard stamped circular hole on the under side of the front passenger floorboard. Using a Center Punch, mark the center of the circular hole. Using a 1-1/2 inch (38 mm) Bi-Metal Hole Saw with arbor and pilot bit, drill through the floorboard towards the inside of the vehicle. De-burr the hole. See Figure 40.



45. Following the directions on the can, liberally apply some PM-13-BeBay Anti Corrosion Coating or equivalent to the edge and surface around the hole drilled into the floorboard. Allow to fully dry. See Figure 41.



NOTE: If equipped with power running boards, the grommet will already be installed into the floorboard. If equipped with a body plug, remove and discard.

46. Install the grommet and route the Body Length Jumper Harness. See Figure 42.

  • As needed, install the grommet included in the Tailgate Actuator Ground Wiring Part Kit into the hole drilled into the floorboard being sure that the grommet is fully seated.

a. If equipped with power running boards, remove the electrical tape off of the grommet that is already installed into the floorboard.

  • Route the Body Length Jumper Harness through the center of the grommet.

b. If equipped with power running boards, route the Body Length Jumper Harness through the center of the existing grommet along side of the existing wire. See Figure 43.

  • Apply black electrical tape over the end of the grommet and the Body Length Jumper Harness.

NOTE: Grommet on vehicle without power running boards shown, other similar.



NOTE: Grommet on vehicle with power running boards shown, other similar.



47. Disconnect the push pin of the male end of C212 from the instrument panel bracket. See Figure 44.



48. Remove the green locking tab and install the Body Length Jumper Harness terminal into the Pin 1 cavity of the C212 male end. See Figure 45.



49. Reinstall the green locking tab, position back the push pin of the male end of C212 into the instrument panel bracket and reconnect the C212 electrical connector. See Figure 46.



50. Position back the carpet. Reconnect C2280A and C2280B to the BCM. Secure the relay wiring to the existing BCM wiring harness using tie straps. Trim any tie straps excess. See Figure 47.



51. Connect the electrical connectors, install the RH insulation panel and the push pins. See Figure 48.



52. Install the RH lower cowl trim panel and the fuse panel cover. See Figure 49.



53. Install the RH Front Scuff Plate Trim Panel. Please follow the WSM procedure in Section 501-05.

54. Connect the negative battery cable(s). Please follow the WSM procedures in Section 414-01.

55. Install the Glove Compartment. Please follow the WSM procedures in Section 501-12.

56. For vehicles equipped with the 360 Degree View Camera system or with the digital Rear Only Parking Aid Camera system, perform 360 Degree View Camera Alignment. Please follow the WSM procedures in Section 413-13B.



Module Programming

NOTE: Program appropriate vehicle modules before performing diagnostics and clear all DTC’s after programming. For DTC’s generated after programming, follow normal diagnostic service procedures.

57. Connect a battery charger to the 12V battery.

NOTE: Verify that the negative cable of the charger is installed on a chassis or engine ground, and not the 12 volt battery negative terminal to prevent the battery saver mode from activating on the vehicle.

NOTE: If the diagnostic software does not load or if the vehicle cannot be identified properly, make sure there is a good internet connection and the VCM is properly connected to the DLC.

58. Log into Ford Diagnostic and Repair System (FDRS).

NOTE: Vehicle information is automatically retrieved by the diagnostic software and a Network Test is run. Vehicle identification data appears on the screen when this is complete.

59. Click ‘Read VIN from Vehicle’ or manually enter the VIN.

NOTE: Available modules are shown on the LH side of the screen, and available procedures are listed on the RH side of the screen. Modules that are communicating are highlighted in green.

60. Select Toolbox tab.

61. From the list on the LH side of the screen, select the BCM.

62. From the list on the RH side of the screen, select BCMBody Control Module (BCM) Software Update.

63. Click RUN. Follow all on-screen instructions carefully.

64. If equipped, from the list on the RH side of the screen, select BCMTailgate Interior Release Switch Configuration.

65. Click RUN. Follow all on-screen instructions carefully.

66. When prompted to choose a parameter state, select Double Press.

67. From the list on the RH side of the screen, select Tailgate Ajar Message.

68. Click RUN. Follow all on-screen instructions carefully.

69. When prompted to choose a parameter state, select Disable.

70. From the list on the RH side of the screen, select Self-Test and click RUN.

71. Click the Run Selected Tests button in the lower right.



72. Click the Clear & Retest button at the top of the screen to clear DTC’s in all modules.

73. Disconnect the battery charger from the 12V battery once the programming has completed. This completes the recall.



Important Information for Module Programming

NOTE: When programming a module, use the following basic checks to ensure programming completes without errors.

  • Make sure the 12V battery is fully charged before carrying out the programming steps and connect FDRS/scan tool to a power source.

NOTE: A good internet connection is necessary to identify the vehicle and to load the diagnostic software.

  • Inspect Vehicle Communication Module II (VCM IIeBay)/Vehicle Communication and Measurement Module (VCMM) and cables for any damage. Make sure scan tool connections are not interrupted during programming.
  • A hardwired connection is strongly recommended.
  • Turn off all unnecessary accessories (radio, heated/cooled seats, headlamps, interior lamps, HVAC system, etc.) and close doors.
  • Disconnect/depower any aftermarket accessories (remote start, alarm, power inverter, CB radio, etc.).
  • Follow all scan tool on-screen instructions carefully.
  • Disable FDRS/scan tool sleep mode, screensaver, hibernation modes.
  • Create all sessions key on engine off (KOEO). Starting the vehicle before creating a session will cause errors within the programming inhale process.



Recovering a module when programming has resulted in a blank module

a. Disconnect the VCMII or VCMM from the data link connector (DLC) and your PC.

b. After ten seconds, reconnect the VCMII/VCMM to the DLC and the PC. Launch FDRS. The VCMII/VCMM icon should turn green in the bottom right corner of the screen. If it does not, troubleshoot the FDRS to VCM connection.

c. If you are using the same FDRS as the initial programming attempt, select the appropriate VIN from the Vehicle Identification menu. If you are using a different FDRS, select “Read VIN from Vehicle” and proceed through the Network Test.

d. In the Toolbox menu, navigate to the failed module and Download/Run Programmable Module Installation (PMI). Follow the on-screen prompts. When asked if the original module is installed, select “No” and continue through the installation application.

e. Once programming has completed, a screen may list additional steps required to complete the programming process. Make sure all applicable steps are followed in order.

IMPORTANT NOTE: Federal law prohibits selling motor vehicle parts or components that are under safety, compliance, or emissions recall. Unless a part is requested to be returned to Ford, all parts replaced under this FSA must be scrapped in accordance with all applicable local, state and federal environmental protection and hazardous material regulations. Refer to the Parts Retention, Return, & Scrapping section of the FSA dealer bulletin for further information.




2 Affected Products

Vehicle

MAKE MODEL YEAR
FORD F-150 2021-2022




1 Associated Document

Manufacturer Communications

November 7, 2022
Customer Satisfaction Program 21M08 – Supplement #2

https://www.nhtsa.gov/recalls?nhtsaId=10226950

MC-10226950-0001.pdf 19887.78KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [18.97 MB]




NHTSA ID Number: 10218634

Manufacturer Communication Number: 21M08 S1

Summary

Certain 2021-2022 Model Year F-150 vehicles equipped with a power release tailgate- Unintended Tailgate opening; Supplement 1: Parts ordering information and full repair instructions are now available to support completion of this customer satisfaction program.



1 Associated Document

Manufacturer Communications

August 8, 2022
Customer Satisfaction Program 21M08 – Supplement #1

https://www.nhtsa.gov/recalls?nhtsaId=10218634

MC-10218634-0001.pdf 14466.735KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [13.80 MB]




NHTSA ID Number: 10211997

Manufacturer Communication Number: 21M08

Summary

Certain 2021-2022 Model Year F-150 Vehicles Equipped with a Power Release Tailgate – Unintended Tailgate Opening – In the affected vehicles, some customers report experiencing an unintended tailgate opening and may have previously serviced their vehicle for this concern. Ford has developed an enhanced remedy for customers who may want this enhanced repair performed on their vehicle.



1 Associated Document

Manufacturer Communications

Customer Satisfaction Program 21M08
May 20, 2022

https://www.nhtsa.gov/recalls?nhtsaId=10211997

MC-10211997-0001.pdf 179.127KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [174.93 KB]




NHTSA ID Number: 10214132

Manufacturer Communication Number: 21M08

Summary

In the affected vehicles, some customers report experiencing an unintended tailgate opening and may have previously serviced their vehicle for this concern. Ford has developed an enhanced remedy for customers who may want this enhanced repair performed on their vehicle.



1 Associated Document

Manufacturer Communications

Owner Letter
June 2022

https://www.nhtsa.gov/recalls?nhtsaId=10214132

MC-10214132-0001.pdf 157.2KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [153.52 KB]






SaleBestseller No. 1
Stromberg Carlson VG-15-4000 Louvered Tailgate 4000 Series-Ford F150, F250/F350 Super Duty
  • Glass-filled composite material – lightweight and durable
  • Lockable, single handed entry
  • Louvers improve vision and reduce drag
  • Rotary latches, cables and inserts included
  • This gate is not designed for weight bearing applications. DO NOT stand on this gate
Bestseller No. 2
Evan Fischer Tailgate Compatible with 2008-2016 Ford F-250 Super Duty, 2008-2016 Ford F-350 Super Duty & 2010-2016 Ford F-450 Super Duty Primed Steel
  • Tailgate Compatible with 2008-2016 Ford F-250 Super Duty
  • Tailgate Compatible with 2008-2016 Ford F-350 Super Duty
  • Feature: Sold individually, Finish: Primed, Material: Steel
  • This Aftermarket Tailgate Replacement is for an OE, Original Equipment, DC3Z9940700A Partslink FO1900125
  • Interchange Part Number: DC3Z9940700A, FO1900125
Bestseller No. 3
MBI AUTO - Primered Steel, Tailgate Shell for 1997-2003 Ford F150 1999-2007 F250 F350 F450 F550 Super Duty Styleside, FO1900113
  • Direct Fit OE Replacement Part
  • Tailgate Shell ONLY; NO Hardware Included; For Styleside Models ONLY. NOT for F150 Super Crew Models. Made of Steel.
  • Lifetime Warranty
Bestseller No. 4
KUAFU Rear Tailgate Replacement Compatible with 1987-1996 Ford F-Series F150 F250 F350 Truck Pick up Bed Replace for Part Number E7TZ9940700A F2TZ9940700A FO1900104
  • Package included: 1 x Rear Tailgate. This is a replacement. It can directly replace the broken and old. Replace for Part Number : FO1900114.
  • Fitment: Compatible with 1987-1996 Ford Full-Size Pickup. Will not compatible with step side Style Models, ONLY fits 1996-1997 HD Models.
  • Premium quality oriented: Made of high-quality reinforced steel, which is smooth to the touch. It can directly replace old and damaged parts.
  • Color: Black | Material: Steel | Placement on Vehicle: Rear. Superior durability and impact resistance can be adapted to any weather, environment.
  • Installation: Hardware does not contain. Professional installation is highly recommended.
Bestseller No. 5
Garage-Pro Tailgate Compatible with 1973-1979 Ford F-100, Fits 1975-1979 Ford F-150, Fits 1973-1979 Ford F-250, Fits 1973-1979 Ford F-350, Fits 1975-1977 Ford F-500
  • Aftermarket Replacement Tailgate Compatible with 1973-1979 Ford F-100, Fits 1975-1979 Ford F-150, Fits 1973-1979 Ford F-250, Fits 1973-1979 Ford F-350, Fits 1975-1977 Ford F-500
  • Interchange Part Numbers: D7TZ9940700A, FO1900101
  • Primed Tailgate
  • Fits Fleetside type bed
  • 1-Year Warranty When Purchased through Auto Parts Giant
Bestseller No. 6
Mile Marker Go Industries Inc. 6618B Air Flow Tailgate, Black Painted, for Select Ford Trucks
  • Many products require vehicle-specific fitment
  • View the Compatibility table to ensure the part fits your year, make, model and submodel
  • Please reference the submodel information located on the far left within the Compatibility table under "Notes"
  • Please note: Due to our high sales volume, it may take up to 2-business days for us to reply to all questions and/or requests.
  • We do not offer shipping to APO/FPO
Bestseller No. 7
Garage-Pro Tailgate Kit Compatible with 1998-2003 Ford F-150, Fits 1999-2007 Ford F-250 Super Duty, Fits 1999-2007 Ford F-350 Super Duty with Tailgate Handle and Tailgate Latch
  • Note: Your order may be split and fulfilled from multiple locations - arriving on different days
  • Tailgate Kit Compatible with 1998-2003 Ford F-150, Fits 1999-2007 Ford F-250 Super Duty, Fits 1999-2007 Ford F-350 Super Duty, Fits 2004-2004 Ford F-150 Heritage, Fits 1998-1999 Ford F-250
  • Interchange Part Numbers: Performance, FO1900121, 1L3Z9943400BAA, FO1915114, F85Z9943170AA, FO1911103. Kit components: (1) Tailgate, (1) Tailgate Handle, and (1) Tailgate Latch
  • Primed Tailgate
  • Direct Fit Replacement Extended Cab Pickup, Styleside, New Body Style. 1-Year Warranty When Purchased through Auto Parts Giant
Bestseller No. 8
KUAFU Rear Tailgate Assembly Compatible with 1997-2003 Ford F150 Styleside 1999-2007 F250 F350 Super Duty Tailgate Shell Primed w/Access Cover Replace for FO1900113 F65Z9940700AX
  • GOOD PERFORMANCE,Solid all-welded steel construction ensure the vehicle is protected against damage from road impacts. Not easy to crack or break.
  • FITMENT, The Rear Tailgate Shell Panel is compatible with 1997-2003 Ford F150 Styleside; compatible with 1998-1999 F250; compatible with 1999-2007 F250 F350 Super Duty, replace for part number FO1900113 F65Z9940700AX.
  • MATERIAL, This Rear Tailgate Shell Panel is made from high quality steel, surface primed treatment for maximum strength and durability.
  • EASY INSTALLATION, No cutting and no drilling. Bolt installation,easy slip-on. Direct replace your old damaged one.
  • PACKAGE INCLUDED, 1X Rear Tailgate Shell Panel and 1X Tailgate Cover Panel (The cover panel could prevent the shell from rusting due to water intake); Instruction is not included. Latch and hardware are not included. Come with the access panel over the internal components.
Bestseller No. 9
Garage-Pro Tailgate Compatible with 1997-2003 Ford F-150, For 2004 F-150 Heritage, For 1999-2007 F-Series Super Duty, Primed Steel Styleside
  • Tailgate Compatible with 1997-2003 Ford F-150, Fits 2004 F-150 Heritage, Fits 1999-2007 F-Series Super Duty
  • Interchange Part Number: F65Z9940700AX,FO1900113
  • Primed Tailgate
  • Direct Fit Replacement
  • 1-Year Warranty When Purchased through Auto Parts Giant
Bestseller No. 10
Stromberg Carlson VG-97-100 Vented Tail Gate - F250 and F350 Super Duty, 1999-2016 , White , 66 Inch
  • All-steel construction
  • Open design improves vision
  • Custom-fitted
  • 100 lb. weight capacity
  • Fits F250 and F350 Super Duty, 1999-2016

Last update on 2024-04-07 / Affiliate links / Images from Amazon Product Advertising API

This product presentation was made with AAWP plugin.




Leave a Comment

Share to...
