NHTSA ID Number: 10226937
Manufacturer Communication Number: TSB 22-2436
Summary
This article supersedes TSB 22-2073 to update the Service Procedure. Some 2021-2022 Bronco vehicles equipped with a hard top may exhibit a loose and/or sagging headliner. This may be due to the factory installation process. To correct the condition, follow the Service Procedure to re-adhere the headliner.
This bulletin supersedes 22-2073.
Model:
Ford
2021-2022 Bronco |
Summary
This article supersedes TSB 22-2073 to update the Service Procedure.
Issue: Some 2021-2022 Bronco vehicles equipped with a hard top may exhibit a loose and/or sagging headliner. This may be due to the factory installation process. To correct the condition, follow the Service Procedure to re-adhere the headliner.
Action: Follow the Service Procedure to correct the condition on vehicles that meet all of the following criteria:
- 2021-2022 Bronco
- Equipped with a hard top roof
- Loose and/or sagging headliner
Parts
Service Part Number | Quantity | Description |
Obtain Locally | As Needed | 3M™ 4298UV Adhesion Promoter |
Parts
Parts To Inspect And Replace Only If Necessary
Service Part Number | Quantity | Description |
M2DZ-9854310-B | 1 | Headliner – 3 Door – Right Front Panel |
M2DZ-9854310-A | 1 | Headliner – 3 Door – Left Front Panel |
M2DZ-9854310-C | 1 | Headliner – 3 Door – Rear Panel |
M2DZ-7854310-A | 1 | Headliner – 5 Door – Right Front Panel |
M2DZ-7854310-D | 1 | Headliner – 5 Door – Left Front Panel |
M2DZ-7854310-E | 1 | Headliner – 5 Door – Middle Panel |
M2DZ-7854310-C | 1 | Headliner – 5 Door – Rear Panel |
Service Procedure
1. Inspect the interior headliner. Is the headliner loose and/or sagging? (Figure 1)
Figure 1
(1). Yes – proceed to Step 2.
(2). No – this article does not apply.
2. Use gloves and a sponge to apply 3M™ 4298UV Adhesion Promoter on the area where the headliner is not adhered to the hard top. Make sure to not extend the adhesion promoter outside of the headliner area. (Figure 2)
Figure 2
3. Press the headliner back into position and hold for at least 40 seconds to allow the adhesive to set. (Figure 3)
Figure 3
4. Does the headliner properly adhere to the roof with no visible gaps? (Figure 4)
Figure 4
(1). Yes – repair is complete.
(2). No – replace the affected headliner.
2 Affected Products
Vehicle
MAKE | MODEL | YEAR |
FORD | BRONCO | 2021-2022 |
1 Associated Document
Manufacturer Communications
22-2436
16 November 2022
https://www.nhtsa.gov/recalls?nhtsaId=10226937
MC-10226937-0001.pdf 203.682KB
NHTSA ID Number: 10208823
Manufacturer Communication Number: TSB 22-2073
Summary
Some 2021-2022 Bronco vehicles equipped with a hard top may exhibit a loose and/or sagging headliner. This may be due to the factory installation process. To correct the condition, follow the Service Procedure to re-adhere the headliner.
1 Associated Document
Manufacturer Communications
22-2073
01 March 2022
https://www.nhtsa.gov/recalls?nhtsaId=10208823
NHTSA ID Number: 10201065
Manufacturer Communication Number: TSB 21-2285
Summary
Some 2021 Bronco vehicles equipped with a hard top may exhibit a loose and/or sagging headliner. This may be due to the factory installation process. To correct the condition, follow the Service Procedure to re-adhere the headliner.
1 Associated Document
Manufacturer Communications
21-2285
30 August 2021
https://www.nhtsa.gov/recalls?nhtsaId=10201065
MC-10201065-0001.pdf 221.552KB
