NHTSA ID Number: 10201590
Manufacturer Communication Number: SSM 50110
Summary
Some 2020-2021 Transit vehicles may exhibit an open master fuse in the high current battery junction box. The master fuses are now available as a separate service part and can be replaced without replacing the high current battery junction box or wiring harness. For master fuses F9 (500A), F10 (300A), F11 (250A), and F12 (150A), use service part number LJ8Z-14526-C. For master fuses F1 (125A), F2 (80A), F3 (150A), and F6 (150A), use service part number LJ8Z-14526-D. Tighten M8 nuts to 12 +/- 1.8 Nm (106 +/- 16 lb-in). Tighten M5 nuts to 5.4 +/- 0.9 Nm (48 +/- 8 lb-in).
2 Affected Products
Vehicle
| MAKE | MODEL | YEAR |
FORD | TRANSIT | 2020-2021 |
APPLICABLE VEHICLES
2020 – 2021 TRUCK: TH V363N TRANSIT
1 Associated Document
Manufacturer Communications
SSM 50110 – 2020-2021 Transit – High Current Battery Junction Box – Master Fuse Replacement
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10186677
Manufacturer Communication Number: SSM 49432
Summary
Some 2020 Transit vehicles may exhibit an open master fuse in the high current battery junction box. The master fuses are now available as a separate service part and can be replaced without replacing the high current battery junction box or wiring harness. For master fuses F9 (500A), F10 (300A), F11 (250A), and F12 (150A), use service part number LJ8Z-14526-C. For master fuses F1 (125A), F2 (80A), F3 (150A), and F6 (150A), use service part number LJ8Z-14526-D. Tighten M8 nuts to 12 +/- 1.8 Nm (106 +/- 16 lb-in). Tighten M5 nuts to 5.4 +/- 0.9 Nm (48 +/- 8 lb-in).
1 Associated Document
Manufacturer Communications
SSM 49432 – 2020 Transit – High Current Battery Junction Box – Master Fuse Replacement
MC-10186677-0001.pdf 114.208KB
Loading...
NHTSA ID Number: 10180389
Manufacturer Communication Number: SSM 49167
Summary
Some 2020 Transit vehicles may exhibit an open master fuse in the high current battery junction box. The master fuses are now available as a separate service part and can be replaced without replacing the high current battery junction box or wiring harness. Tighten M8 nuts to 12 +/- 1.8 Nm (106 +/- 16 lb-in). Tighten M5 nuts to 5.4 +/- .9 Nm (48 +/- 8 lb-in).
1 Associated Document
Manufacturer Communications
SSM 49167 – 2020 Transit – High Current Battery Junction Box – Master Fuse Replacement
Loading...
