NHTSA ID Number: 10171858
Manufacturer Communication Number: TSB-20-2016
Summary
Some 2017 F-150 vehicles equipped with a 3.5L EcoBoost engine may exhibit a rattle type noise from the engine compartment under various operating conditions. This noise may be due to excessive play the turbocharger wastegate linkage. To correct the condition, follow the Service Procedure to install the wastegate linkage spring kit.
1 Affected Product
Vehicle
FORD | F-150 | 2017 |
Model:
Issue: Some 2017 F-150 vehicles equipped with a 3.5L EcoBoost engine may exhibit a rattle type noise from the engine compartment under various operating conditions. This noise may be due to excessive play in the turbocharger wastegate linkage. To correct the condition, follow the Service Procedure to install the wastegate linkage spring kit.
Action: Follow the Service Procedure to correct the condition on vehicles that meet all of the following criteria:
- 2017 F-150
- 3.5L EcoBoost engine
- Customer concern of rattle type noise from the engine compartment under various operating conditions
NOTE: Part quantity refers to the number of that service part number required, which may be different than the number of individual pieces. Service part numbers contain 1 piece unless otherwise stated.
Parts
| Description | Quantity | Part Number | |
| 1 Kit Required Per Actuator | Spring Washer Kit | 2 | HL3Z-9G488-C |
SEOCONTENT-START
TECHNICAL SERVICE BULLETIN
3.5L EcoBoost – Rattle Type Noise from Engine Compartment Under
Various Operating Conditions
Warranty Status: Eligible under provisions of New Vehicle Limited Warranty (NVLW)/Service Part Warranty (SPW)/Special Service Part (SSP)/Extended Service Plan (ESP) coverage. Limits/policies/prior approvals are not altered by a TSB. NVLW/SPW/SSP/ESP coverage limits are determined by the identified causal part and verified using the OASIS part coverage tool.
Labor Times
| Description | Operation No. | Time |
| 2017 F-150 3.5L EcoBoost: Install A Spring Washer Kit On Both (2) Actuators Following The Service Procedure (Do Not Use With Any Other Labor Operations) | 202016A | 1.9
Hrs. |
Repair/Claim Coding
| Causal Part: | 6K682 |
| Condition Code: | 33 |
SEOCONTENT-END
Service Procedure
NOTE: Perform the repair on both turbocharger wastegate control actuators.
- Disconnect the question mark bracket from the wastegate control actuator. Refer to the Workshop Manual (WSM), Section 303-04F.
- Remove the lever arm e-clip.
- Disconnect the dog bone and question mark assembly from the turbocharger.
- Remove the e-clip to separate the question mark and dog bone.
- Install the spring with the curved end toward the dog bone.
- Assemble the dog bone, spring, and question mark bracket together and fasten with the e-clip.
- Install the dog bone, spring, and question mark bracket assembly onto the turbocharger.
- Install the e-clip. The e-clip should be sitting next to the spring.
- Connect the question mark bracket to the wastegate control actuator and adjust the linkage. Refer to the WSM, Section 303-04F.
20-2016
13 February 2020
