NHTSA ID Number: 10152475
Manufacturer Communication Number: SSM 47671
Summary
For 2015-2019 Transit vehicles, multiple fuse assemblies for the high current battery junction box are available for service. Do not replace the high current battery junction box assembly/wire harness to service an open fuse. Use part number BK2Z-14526-A for the 40 amp/100 amp/470 amp assembly, BK2Z-14526-B for the 2×60 amp/2×80 amp/3×100 amp/200 amp assembly, and BK2Z-14S411-A for the 60 amp MIDIù fuses on the outboard side of the driver seat base. Refer to Wiring Diagram Cell 11-7 for proper location.
5 Affected Products
Vehicle
MAKE | MODEL | YEAR |
FORD | TRANSIT | 2015-2019 |
Part Description | Part Number |
40 Amp/100 Amp/470 Amp Assembly | BK2Z-14526-A |
2×60 Amp/2×80 Amp/3×100 Amp/200 Amp assembly | BK2Z-14526-B |
SSM 47671
https://www.nhtsa.gov/recalls?nhtsaId=10152475
https://static.nhtsa.gov/odi/tsbs/2018/MC-10152475-9999.pdf
