 Copyright 2023 Ford Motor Company
Stacy L. Balzer Ford Motor Company
Director P. O. Box 1904
Service Engineering Operations Dearborn, Michigan 48121
Ford Customer Service Division
October 26, 2023
TO: All U.S. Ford and Lincoln Dealers
SUBJECT: Customer Satisfaction Program 23B42
Certain 2023 Model Year Explorer, Bronco, Ranger
Vehicles Equipped with 2.3L Gas Engine
Engine Long Block Replacement
PROGRAM TERMS
This program will be in effect through October 31, 2026. There is no mileage limit for this program.
URGENCY / EXPIRATION DATE
This Customer Satisfaction Program has an expiration date of October 31, 2026, to encourage
dealers and customers to have this service performed as soon as possible.
We recommend dealers utilize their FSA VIN Lists name and address to contact customers with
affected vehicles. This will help minimize the number of vehicles that may experience engine coolant
leaks or engine failure, which may require towing. FSA VIN Lists are expected to be available on
October 26, 2023.
AFFECTED VEHICLES
Vehicle Model Year Assembly Plant Build Dates
Ranger 2023 Michigan March 27, 2023 through April 19, 2023
Bronco 2023 Michigan April 3, 2023 through May 18, 2023
Explorer 2023 Chicago April 3, 2023 through April 29, 2023
U.S. population of affected vehicles: 131. Affected vehicles are identified in OASIS and FSA VIN Lists.
Note: Some vehicles may be in the process of being repaired at the plant. Monitor OASIS before
opening an RO and/or beginning a repair. Parts purchased for an FSA can be returned for credit if
required. See the EXCESS STOCK RETURN details in Labor Allowances and Parts Ordering
Information for more information.
REASON FOR THIS PROGRAM
In the affected vehicles, a damaged tool used during the engine block casting process may lead to the
formation of a crack in the right side of the engine block assembly that can result in a coolant leak.
Customers may experience a progressive series of symptoms, including a low coolant pressure,
which could lead to a coolant leak that would be visible beneath the vehicle and finally may result in
an illuminated Service Engine Soon Indicator for an engine overheat condition.
SERVICE ACTION
Dealers are to replace the engine long block (Base Part # 6006) assembly. This service must be
performed on all affected vehicles at no charge to the vehicle owner.
 Copyright 2023 Ford Motor Company
OWNER NOTIFICATION MAILING SCHEDULE
Owner letters are expected to be mailed the week of November 13, 2023. Dealers should repair any
affected vehicles that arrive at their dealerships, whether or not the customer has received a letter.
ATTACHMENTS
• Administrative Information
• Labor Allowances and Parts Ordering Information
• Technical Instructions
• Mobile Service Repair Assessment
• Vehicle Pickup and Delivery Record
• Owner Notification
QUESTIONS & ASSISTANCE
For questions and assistance, contact the Special Service Support Center (SSSC) via the SSSC Web
Contact Site. The SSSC Web Contact Site can be accessed through the Professional Technician
System (PTS) website using the SSSC link listed at the bottom of the OASIS VIN report screen or
listed under the SSSC tab.
Sincerely,
Stacy L. Balzer
 Copyright 2023 Ford Motor Company
Administrative Information
Page 1 of 3
Customer Satisfaction Program 23B42
MOBILE SERVICE REPAIR ASSESSMENT LEVEL
• All repairs in this program have the following assessment level:
– Not a Mobile Service Repair
OASIS ACTIVATION
OASIS will be activated on October 26, 2023.
FSA VIN LISTS ACTIVATION
FSA VIN Lists will be available through https://web.fsavinlists.dealerconnection.com on October 26,
2023. Owner names and addresses will be available on December 1, 2023.
NOTE: Your FSA VIN Lists may contain owner names and addresses obtained from motor vehicle
registration records. The use of such motor vehicle registration data for any purpose other than in
connection with this program is a violation of law in several states, provinces, and countries.
Accordingly, you must limit the use of this listing to the follow-up necessary to complete this service
action.
SOLD VEHICLES
• Owners of affected vehicles will be directed to dealers for repairs.
• Immediately contact any of your affected customers whose vehicles are not on your VIN list
but are identified in OASIS. Give the customer a copy of the Owner Notification Letter (when
available) and schedule a service date.
• Correct other affected vehicles identified in OASIS which are brought to your dealership.
• Dealers are to prioritize repairs of customer vehicles over repairs of new and used vehicle
inventory.
STOCK VEHICLES
• Correct all affected units in your new vehicle inventory before delivery.
• Use OASIS to identify any affected vehicles in your used vehicle inventory.
BRANDED / SALVAGED TITLE VEHICLES
Affected branded / salvaged title vehicles are eligible for this service action.
OWNER REFUNDS
Refunds are not approved for this program.
RENTAL VEHICLES
Dealers are pre-approved for up to 3 days for a comparable rental vehicle. Follow Extended Service
Plan (ESP) guidelines for dollar amounts. Rentals will only be reimbursed for the day(s) the vehicle is
at the dealership for part replacement. Prior approval for more than 3 rental day(s) is required from
the SSSC via the SSSC Web Contact Site.
 Copyright 2023 Ford Motor Company
Administrative Information
Page 2 of 3
Customer Satisfaction Program 23B42
PICK-UP AND DELIVERY- Participating Dealers
Dealers participating in the Remote Experience Program:
• Refer to EFC12071, 2023 Remote Experience Program, Pickup & Delivery (PDL) Offset
section for additional details.
PICK-UP AND DELIVERY- Non-participating Dealers
Dealers not participating in the 2023 Remote Experience Program for Pick-up & Delivery are
authorized to claim unique services for completing this program.
• Dealers are authorized to claim one-half labor hour per repair for vehicle pick-up & delivery
services. Refer to Labor Allowances for details.
• Dealers must retain a Vehicle Pick-up & Delivery Record with the repair order documentation.
ALTERNATIVE TRANSPORTATION
If a customer is unable or does not wish to rent a vehicle but still requires transportation, the rental
reimbursement allowance can be used for alternative transportation. Alternative transportation is
approved for $100 per day for both Ford and Lincoln customers. The dollar-per-day allowance can be
cumulative across multiple rides per day (e.g. ride to work $20 and ride home $24).
• Alternative transportation reimbursement can be claimed for both short-term and long-term
scenarios.
• Any amount more than the cost-per-day limits will be the customer’s responsibility.
• The customer will need to pay upfront and provide proof of payment to the dealer.
• Dealers will then need to submit for reimbursement following the Rental Vehicle
Reimbursement Process and then refund the customer.
Examples of alternative transportation:
• Taxi
• Public Transportation – Subway, Train, or Bus
• Rideshare alternatives (Uber, Lyft, etc.)
ADDITIONAL REPAIR (LABOR TIME AND/OR PARTS)
Additional repairs identified as necessary to complete the FSA should be managed as follows:
• For related damage and access time requirements, refer to the Warranty and Policy Manual /
Section 6 – Ford & Lincoln Program Policies / General Information & Special Circumstances
for FSAs / Related Damage.
• For vehicles with powertrain warranty coverage, no SSSC approval is required, although
related damage must be on a separate repair line with the “Related Damage” radio button
checked.
o Ford vehicles – 5 years or 60,000 miles
• For vehicles outside powertrain warranty coverage, submit an Approval Request to the SSSC
Web Contact Site before completing the repair.
 Copyright 2023 Ford Motor Company
Administrative Information
Page 3 of 3
Customer Satisfaction Program 23B42
CLAIMS PREPARATION AND SUBMISSION
• Claim Entry: Enter claims using Dealer Management System (DMS) or One Warranty
Solution (OWS) online.
o When entering claims:
 Claim type 31: Field Service Action
 Sub Code: 23B42
 Customer Concern Code (CCC): D50 – Other engine troubles
 Condition Code (CC): 42 – Does not operate properly
 Causal Part Number: 6006, Quantity 0
o For additional claims preparation and submission information, refer to the Recall and
Customer Satisfaction Program (CSP) Repairs in the OWS User Guide.
• Related Damage/Additional labor and/or parts: Must be claimed as Related Damage on a
separate repair line from the FSA with the same claim type and subcode as described in Claim
Entry above.
IMPORTANT: Click the Related Damage Indicator radio button.
• Rentals: For rental vehicle claiming, follow Extended Service Plan (ESP) guidelines for dollar
amounts. Enter the total amount of the rental expense under Miscellaneous Expense code
RENTAL.
• Parts Handling Allowance: A parts handling allowance is being provided, unless otherwise
notified by the Company or as provided by state law, in addition to the dealer cost of the long
block assembly. To claim the allowance, enter $600.00 as HANDLG in the Misc. Expense area
of the claim form.
• Provision for Locally Obtained Supplies: Includes TA-26, ZC-30-A, ZC-31-B, ZC-20, PM-4-
A, PM-4-B, TA-39, CU7Z-19B508-A, XO-5W30-Q1SP or XO-5W30-Q1FS, TA-357, VC-3-B,
XL-5-A, Submit on the same line as the repair. Additional parts totaling more than $350.00
requires prior approval from the SSSC.
o Program Code: 23B42
o Misc. Expense: OTHER
o Misc. Expense: Claim up to $350.00
• Pickup & Delivery:
o Dealers participating in the Remote Experience Program –
 Refer to EFC12071, 2023 Remote Experience Program, Pickup & Delivery
(PDL) Offset section for additional details.
o Dealers NOT participating in the Remote Experience Program –
 Dealers are authorized to claim one-half labor hour per repair for vehicle pickup
and delivery services.
 Dealers must retain a Vehicle Pick-up and Delivery Record with the repair order
documentation.
 Copyright 2023 Ford Motor Company
Labor Allowances and Parts Ordering Information
Page 1 of 3
Customer Satisfaction Program 23B42
LABOR ALLOWANCES
Description Labor
Operation Labor Time
Ranger 2.3L – 4X2 (2WD) – Replace Engine Long Block.
(Includes time to transfer parts to new engine long block) and
(If Equipped, Time to replace/transfer Engine Oil Cooler)
MT23B42B Up to 16.8
Hours
Ranger 2.3L – 4X4 (AWD/4WD) –
Replace Engine Long Block.
(Includes time to transfer parts to new engine long block) and
(If Equipped, time to replace/transfer Engine Oil Cooler)
MT23B42C Up to 17.5
Hours
Bronco 2.3L – 4X4 (AWD/4WD) – With Automatic
Transmission – Replace Engine Long Block.
(Includes time to transfer parts to new engine long block) and
(If Equipped, time to replace/transfer Engine Oil Cooler)
MT23B42D Up to 14.9
Hours
Bronco 2.3L – 4X4 (AWD/4WD) – With Manual Transmission –
WITH-OUT Stabilizer Bar Disconnect.
Replace Engine Long Block.
(Includes time to transfer parts to new engine long block) and
(If Equipped, time to replace/transfer Engine Oil Cooler)
MT23B42E Up to 13.8
Hours
Bronco 2.3L – 4X4 (AWD/4WD) – With Manual Transmission,
WITH Stabilizer Bar Disconnect.
Replace Engine Long Block.
(Includes time to transfer parts to new engine long block) and
(If Equipped, time to replace/transfer Engine Oil Cooler)
(If Equipped, time for Front Stabilizer Bar Disconnect)
(If Equipped, time for Front Bumper Bar removal and installation)
MT23B42F Up to 14.2
Hours
Explorer 2.3L – 4X2 (2WD) – Replace Engine Long Block.
(Includes time to transfer parts to new engine long block) and
(If Equipped, time to replace/transfer Engine Oil Cooler)
MT23B42G Up to 16.1
Hours
Explorer 2.3L – 4X4 (AWD/4WD) – Replace Engine Long Block.
(Includes time to transfer parts to new engine long block) and
(If Equipped, time to replace/transfer Engine Oil Cooler)
MT23B42H Up to 17.6
Hours
Vehicle Pick-up and Delivery Allowance:
This allowance is only for non-eligible 2023 Remote
Experience Program Dealers.
NOTE: This allowance is for dealer-performed vehicle pickup/
delivery for dealership repairs only. Can only be claimed
once, regardless of outstanding FSAs repaired.
23B42PP 0.5 Hours
 Copyright 2023 Ford Motor Company
Labor Allowances and Parts Ordering Information
Page 2 of 3
Customer Satisfaction Program 23B42
PARTS REQUIREMENTS / ORDERING INFORMATION
Part Number Description Order
Quantity
Claim
Quantity
KB3Z-6006-* 2.3L Ranger Long Block Engine Assembly –
4X2 (2WD) or 4X4 (AWD/4WD) 1 1
MB3Z-6006-*
2.3L Bronco Long Block Engine Assembly –
4X4 (AWD/4WD) – With Automatic Transmission
4X4 (AWD/4WD) – With Manual Transmission
1 1
MB5Z-6006-* 2.3L Explorer Long Block Engine Assembly –
4X2 (2WD) 1 1
MB5Z-6006-*
2.3L Explorer Long Block Engine Assembly –
4X4 (AWD/4WD) 1 1
*- 6A642 – *
2.3L Engine Oil Cooler – All 2.3L Applications
(If equipped and If required during the repair) –
1 Required
If Needed
NOTE: To select the correct Long Block Engine Assembly (6006), enter the vehicle identification
number (VIN), in Professional Technician System (PTS), refer to the correct Workshop Manual
(WSM) Section 303-01 for service procedures and parts catalog for 2.3L engine long block
replacement.
NOTE: For additional required miscellaneous parts or One-Time-Use Parts needed when replacing
the 2.3L Long Block Engine assembly (Base Part # (*-6006-*), such as One-Time-Use parts, gaskets,
fasteners, coolers, seals, fluids, etc. enter the vehicle identification number (VIN) in Professional
Technician System (PTS). Refer to the Workshop Manual Tab, Select Workshop Manual (WSM)
Section 303-01 for engine disassembly section, follow the workshop manual procedures,
and (Click on the Shopping Cart Icon) use the One-Time-Use parts, tools, and Materials List to
service the Long-Block engine assembly.
NOTE: Order your parts requirements through normal order processing channels. To guarantee the
shortest delivery time, an emergency order for parts must be placed.
DEALER PRICE
For the latest prices, refer to DOES II.
HANDLING ALLOWANCE
An allowance of $600.00 per repair is being provided unless otherwise notified by the Company or as
provided by state law, in addition to the dealer cost of the (*-6006-*) long block assembly.
 Copyright 2023 Ford Motor Company
Labor Allowances and Parts Ordering Information
Page 3 of 3
Customer Satisfaction Program 23B42
PARTS RETENTION, RETURN, & SCRAPPING
Follow the provisions of the Warranty and Policy Manual, Section 1 – WARRANTY PARTS
RETENTION AND RETURN POLICIES. If a replaced part receives a scrap disposition, the part must
be scrapped by all applicable local, state, and federal environmental protection and hazardous
material regulations. Federal law prohibits selling motor vehicle parts or components that are under
safety, compliance, or emissions recall.
EXCESS STOCK RETURN
The excess stock returned for credit must have been purchased from Ford Customer Service Division
by Policy Procedure Bulletin 4000.
REPLACED FSA PARTS INSPECTION AND SIGN OFF
Effective March 1st, 2021, all parts replaced as part of an FSA repair with a repair order open date of
March 1st, 2021, or later must be inspected and signed off on the repair order by a member of your
dealer’s fixed operations management team or an employee the task has been delegated to. If the
task is to be delegated to a non-management employee, the employee needs to be someone other
than the technician who completed the repair and needs to understand the importance of completing
this task consistently and accurately.
• All parts replaced as part of an FSA repair should be returned to the parts department
following the Warranty Parts Retention and Return Policies.
• Inspect the replaced parts to verify the FSA repair was completed.
• If the FSA repair is found to be complete, the designated employee signs the repair order line
or parts return stamp area (electronic or hand signed) for the FSA repair indicating the parts
were inspected and validated to have been replaced.
• After the parts have been inspected, they should be handled based on the guidance in the
parts status report in the Online Warranty System (Hold, Return, CORE, Scrap, etc.). Please
visit FMCDEALER > PARTS & SERVICE > WARRANTY ADMINISTRATION & WARRANTY
PARTS RETURN for the latest Immediate Scrap List information.
• This process is subject to review during warranty audits for FSA repairs with a repair order
open date of March 1st, 2021, or later. Any eligible FSA claims requiring parts replacement
found not to have been inspected and signed off during a warranty audit will be subject to
chargeback and consideration for enrollment into the Dealer Incomplete Recall Repair
Process.
Note: Other approvals (electronic or handwritten) for add-on repair lines, dealer-owned vehicle
repairs, and repeat repairs do not qualify as FSA parts inspection approvals. The post-repair FSA
parts inspection process (electronic or handwritten) is independent of other warranty approval
requirements. The approval by the designated employee implies that the FSA parts were found to be
replaced and must be able to be identified on the Repair Order. If multiple FSAs require approval on a
single Repair Order, each applicable occurrence will require individual post-repair approval by the
designated employee.
 Copyright 2023 Ford Motor Company
Ford Motor Company
Ford Customer Service Division
P. O. Box 1904
Dearborn, Michigan 48121
November 2023
Customer Satisfaction Program 23B42
Mr. John Sample
123 Main Street
Anywhere, USA 12345
Your Vehicle Identification Number (VIN): 12345678901234567
At Ford Motor Company, we are committed not only to building high-quality, dependable products but
also to building a community of happy, satisfied customers. To demonstrate that commitment, we are
providing a no-charge Customer Satisfaction Program for your vehicle with the VIN shown above.
Why are you receiving
this notice?
On your vehicle, a damaged tool used during the engine block casting
process may lead to the formation of a crack in the right side of the block
assembly.
What is the effect?
Service Engine Soon
A crack in the right side of the engine block assembly can result in a coolant
leak. Customers may experience a progressive series of symptoms,
including low coolant pressure, coolant leak that would be visible beneath
the vehicle, and finally may result in an illuminated Service Engine Soon
Indicator (icon shown on the left) for an engine overheat condition.
What will Ford and
your dealer do?
In the interest of customer satisfaction, Ford Motor Company has authorized
your dealer to replace the engine long block free of charge (parts and labor)
under the terms of this program.
This Customer Satisfaction Program will be in effect until October 31, 2026
regardless of mileage. Coverage is automatically transferred to subsequent
owners.
How long will it take? The time needed for this repair is approximately 3 days. However, due to
service scheduling requirements, your dealer may need your vehicle for a
longer period of time. Additional time may be required to allow the engine to
cool before performing this repair.
What should you do?
Please call your dealer without delay to schedule a service appointment for
Customer Satisfaction Program 23B42. Provide the dealer with your VIN,
which is printed near your name at the beginning of this letter.
If you do not already have a servicing dealer, you can access
ford.com/support for dealer addresses, maps, and driving instructions.
 Copyright 2023 Ford Motor Company
What should you do?
(Continued)
Ford Motor Company wants you to have this service action completed on
your vehicle. The vehicle owner is responsible for making arrangements to
have the work completed.
NOTE: You can receive information about Recalls and Customer
Satisfaction Programs through our FordPass App. The app can be
downloaded through the App Store or Google Play. In addition, there are
other features such as reserving parking in certain locations and controlling
certain functions on your vehicle (lock or unlock doors, remote start) if it is
equipped to allow control.
Do you need a rental
vehicle?
Your dealer is authorized to provide a rental vehicle for your personal
transportation at no charge (except for fuel, insurance, and tax) while your
vehicle is at the dealership for repairs. Please see your dealer for guidelines
and limitations.
What if you no longer
own this vehicle?
If you no longer own this vehicle and have an address for the current owner,
please forward this letter to the new owner.
You received this notice because our records, which are based primarily on
state registration and title data, indicate that you are the current owner.
Can we assist you
further?
If you have difficulties getting your vehicle repaired promptly and without
charge, please contact your dealership’s Service Manager for assistance.
RETAIL OWNERS: If you have questions or concerns, please contact our
Ford Customer Relationship Center at 1-866-436-7332 and one of our
representatives will be happy to assist you. If you wish to contact us through
the Internet, our address is: ford.com/support.
For the hearing impaired call 1-800-232-5952 (TDD). Representatives are
available Monday through Friday: 8:00 AM – 8:00 PM (Eastern Time).
FLEET OWNERS: If you have questions or concerns, please contact our
Ford Pro Contact Center at 1-800-34-FLEET, choose Option #1, and one
of our representatives will be happy to assist you. If you wish to contact us
through the Internet, our address is fleet.ford.com.
Representatives are available Monday through Friday: 7:00 AM – 11:00 PM
and Saturday 7:00 AM – 5:00 PM (Eastern Time).
Thank you for your attention to this important matter.
Ford Customer Service Division
Mobile or Pick-Up and Delivery Repair Record
Page 1 of 1
Customer Satisfaction Program 23B42
VEHICLE PICK-UP AND DELIVERY RECORD
VIN ____________________________ received (check one):
☐ Pick-up and/or delivery service
As outlined below for the 23B42 Field Service Action program.
☐ Pick-up – Date: _______________
☐ Delivery – Date: _______________
Repair Order # Repair Order Date
Service Manager Signature Date
Mobile Service Repair Assessment
Page 1 of 2
Customer Satisfaction Program 23B42
Mobile Service Repair Assessment
Assessment levels have been identified to help determine the ease of performing eligible mobile
service repairs for a Field Service Action (FSA) outside of the dealership service facility.
Dealer Bulletin
Within Attachment I of the dealer bulletin a mobile service repair assessment level(s) will be
provided. These assessment levels have been determined using the amount of time, equipment
and labor identified to perform the intended service action.
Assessment Levels
– Mobile Reprogramming
– Light Mobile Service
– Enhanced Mobile Service
– Advanced Mobile Service
– Wheel and Tire Mobile Service
– Not a Mobile Service Repair
Description of each level that is used to determine the overall assessment.
– Mobile Reprogramming
• Module Programming or similar type services
• Minimum tools maybe required other than an IDS/FDRS setup
• FDRS programming that requires internet connection (wi-fi or mobile hotspot)
• Make sure vehicle has a charge port to ensure battery voltage is maintained during
flashing of the module(s)
• Repairs not greater than 1 hour in length (including time to wait for programming)
Note: The location will need a charging station or wall box to maintain the 12-volt battery.
– Light Mobile Service
• Interior repair procedures that do not require seat, dash, or headliner removal
• Under hood repairs that do not require large component removal
• Exterior repairs that do not require large component/panel removal
• Repairs may require standard hand tools (Access to a Technician starter kit or similar)
Mobile Service Repair Assessment
Page 2 of 2
Customer Satisfaction Program 23B42
– Enhanced Mobile Service
• A two-person process is required anytime a procedure requires work under the
vehicle
• Brake Inspection and Brake Repair/Replacement
• Limited Suspension Component replacement (no alignment)
• Under Vehicle access for limited repairs (no large component removal)
• Vehicle Check Up – VCU
• Pre-Delivery Inspection – PDI
• Used Car Inspection/Presale Inspection
• May require floor jack, jack stands, and impact tools
Note: Wheel lock may be required.
– Advanced Mobile Service
• Fluid Exchange/Oil Change
• Light Repairs
• Brake Hydraulic Repairs
– Wheel and Tire Mobile Service
• Tire Removal from Wheel
• Tire Balancing
• Tire Repair
Note: Specialized Mobile Service unit and equipment including Tire balancer and Tire
Changer required.
– Not a Mobile Service Repair
• Large component removal
• BEV Battery Replacement
• Requires a vehicle hoist – to complete the repair (more than inspection)
• Required vehicle alignment
• Requires significant vehicle disassembly
• Repairs greater than 2-3 hours
• Any repairs that require M-Time
• Includes a service procedure where the vehicle owner may be distressed about the state
of their vehicle
TECHNICAL INSTRUCTIONS
PAGE 1 OF 2
CUSTOMER SATISFACTION PROGRAM 23B42
CPR © 2023 FORD MOTOR COMPANY
DEARBORN, MICHIGAN 48121
10/2023
CERTAIN 2023 MODEL YEAR EXPLORER, RANGER, AND BRONCO VEHICLES
EQUIPPED WITH A 2.3L GAS ENGINE — ENGINE LONG BLOCK REPLACEMENT
SERVICE PROCEDURE
NOTICE: During engine repair procedures, cleanliness is extremely important. Any foreign
material, including any material created while cleaning gasket surfaces, that enters the
oil passages, coolant passages or the oil pan, can cause engine failure.
1. Remove the 2.3L Long Block engine assembly (Base Part # 6006).
For Ranger Vehicles follow Workshop Manual (WSM) procedures in Section 303-01.
For Explorer and Bronco Vehicles follow WSM procedures in Section 303-01A.
2. Install the new 2.3L Long Block engine assembly (Base Part # 6006).
For Ranger Vehicles follow WSM procedures in Section 303-01.
For Explorer and Bronco Vehicles follow WSM procedures in Section 303-01A.
NOTE: For additional required miscellaneous parts needed when replacing the Long Block Engine
assembly (Base Part # (*-6006-*), such as gaskets, fasteners, coolers, seals, fluids, etc..
Enter the vehicle identification number (VIN), in Professional Technician System (PTS), refer to
the correct Workshop Manual (WSM) Section 303-01 for service procedures and parts catalog
for 2.3L Long Block Engine Replacement.
NOTE: For additional required miscellaneous parts or One-Time-Use Parts needed when replacing the
2.3L Long Block Engine assembly (Base Part # (*-6006-*), such as One-Time-Use parts, gaskets,
fasteners, coolers, seals, fluids, etc.. Enter the vehicle identification number (VIN) in Professional
Technician System (PTS). Refer to the Workshop Manual Tab, Select Workshop Manual (WSM)
Section 303-01 for engine disassembly section, follow the workshop manual procedures,
and (Click on the Shopping Cart Icon) use the One-Time-Use parts, tools, and Materials List to
service the Long-Block engine assembly. See Figure 1.
FIGURE 1
2342A
TECHNICAL INSTRUCTIONS
PAGE 2 OF 2
CUSTOMER SATISFACTION PROGRAM 23B42
CPR © 2023 FORD MOTOR COMPANY
DEARBORN, MICHIGAN 48121
10/2023
NOTE: Transfer components as necessary. These components include and are not limited to: Intake
Manifold, Exhaust, Fuel system, wiring harness, engine sensors, rear engine components,
Front Engine Accessory Components (F.E.A.D) and IF equipped, replace the engine oil cooler.
Refer to the WSM for the individual component procedures.
3. Lower the vehicle. Clear any Diagnostic Trouble Codes (DTCs), and road test the vehicle per WSM
instructions in the Engine Installation Section.
For Ranger Vehicles follow WSM procedures in Section 303-01.
For Explorer and Bronco Vehicles follow WSM procedures in Section 303-01A.
The repair is complete.

**************************************************************************************************************

**************************************************************************************************************

SEOCONTENT-END
