NHTSA ID Number: 10233577
Manufacturer Communication Number: TSB 22-2406
Summary
Some 2021-2023 Explorer Timberline vehicles may exhibit differential fluid venting from the differential fluid vent. The customer may notice differential fluid pooling below the vehicle or saturating the wheel well liner. This may be due to the differential vent tube not having enough positive incline. To correct the condition, follow the Service Procedure to replace the differential vent tube.
Model:
Ford
2021-2023 Explorer | Timberline |
Issue: Some 2021-2023 Explorer Timberline vehicles may exhibit differential fluid venting from the differential fluid vent. The customer may notice differential fluid pooling below the vehicle, or saturating the wheel well liner. This may be due to the differential vent tube not having enough positive incline. To correct the condition, follow the Service Procedure to replace the differential vent tube.
Action: Follow the Service Procedure to correct the condition on vehicles that meet the following criteria:
- 2021-2023 Explorer Timberline
- Differential fluid venting from the rear axle vent tube
Parts
| Service Part Number | Quantity | Description |
| N1MZ-4A058-A | 1 | Rear Axle Vent Hose Assembly |
XL-3  | As Needed | Motorcraft® Friction Modifier Additive |
| XY-75W85-QL | As Needed | Motorcraft® SAE 75W-85 Premium Synthetic Hypoid Gear Lubricant |
As Needed indicates the amount of the part may vary and/or is not a whole number. Parts can be billed out as non-whole numbers, including less than 1.
Service Procedure
1. Remove and discard the differential vent tube. Refer to Workshop Manual (WSM), Section 205-02.
2. Install the new differential vent tube. Make sure that the vent tube is routed correctly and maintains a positive slope on the curvature near the differential. (Figures 1-3)
NOTE: It may be beneficial to use a borescope to view the differential vent tube mounting and make sure the vent tube is fully seated and is sloping upward.
Figure 1
Figure 2
Figure 3
3. Drain the differential. Refer to WSM, Section 205-02.
4. Add 85-100 ml of Motorcraft® Friction Modifier Additive to the differential.
5. Refill the differential. Refer to WSM, Section 205-02.
3 Affected Products
Vehicle
| MAKE | MODEL | YEAR |
| FORD | EXPLORER | 2021-2023 |
1 Associated Document
Manufacturer Communications
22-2406
28 March 2023
