NHTSA ID Number: 10236024
Manufacturer Communication Number: SSM 51590
Summary
Some 2021-2022 F-150 vehicles equipped with light duty electric park brake calipers (minor feature code FAJAK) may exhibit a squeal noise from the rear brakes after sitting for 8 hours or more. To confirm a vehicle is built with minor feature code FAJAK, review the build information by double-clicking the vehicle identification number in the upper left-hand corner in the Professional Technician System (PTS). To correct this condition, replace rear brake disc (ML1Z-2C026-C) and rear brake pads, caliper pin bolts, and brake pad holding clips (ML3Z-2200-E) on both sides of the vehicle. Refer to Workshop Manual Section 206-04 Rear Disc Brake. For claiming, use causal part number 2552 and applicable labor times from Section 02 of the Service Labor Times Standard Manual. NOTE: Using incorrect service parts on the braking system could impair brake performance.
2 Affected Products
Vehicle
MAKE | MODEL | YEAR |
FORD | F-150 | 2021-2022 |
1 Associated Document
Manufacturer Communications
SSM 51590
2021-2022 F-150 (P702) (FD)
2021-2022 F-150 Equipped With Light Duty Electric Park Brake Caliper – Squeal Noise From Rear Brakes When Applied At Low or High Speed
https://www.nhtsa.gov/recalls?nhtsaId=10236024
NHTSA ID Number: 10233746
Manufacturer Communication Number: SSM 51471
Summary
Some 2021-2022 F-150 vehicles equipped with light duty electric park brake calipers (minor feature code FAJAK) may exhibit a squeal noise from the rear brakes after sitting for 8 hours or more. To confirm a vehicle is built with minor feature code FAJAK, review the build information by double-clicking the vehicle identification number in the upper left-hand corner in the Professional Technician System (PTS). To correct this condition, replace rear brake disc (ML1Z-2C026-C) and rear brake pads, caliper pin bolts, brake pad clips, and retraction springs (ML3Z-2200-E) on both sides of the vehicle. Refer to Workshop Manual Section 206-04 Rear Disc Brake. For claiming, use causal part number 2552 and applicable labor times from Section 02 of the Service Labor Times Standard Manual. NOTE: Using incorrect service parts on the braking system could impair brake performance.
1 Associated Document
Manufacturer Communications
SSM 51471
2021-2022 F-150 Equipped With Light Duty Electric Park Brake Caliper – Squeal Noise From Rear Brakes When Applied At Low or High Speed
https://www.nhtsa.gov/recalls?nhtsaId=10233746
NHTSA ID Number: 10233651
Manufacturer Communication Number: SSM 51402
Summary
Some 2021-2022 F-150 vehicles equipped with light duty electric park brake calipers (minor feature code FAJAK) may exhibit a squeal noise from the rear brakes after sitting for 8 hours or more. To confirm a vehicle is built with minor feature code FAJAK, review the build information by double-clicking the vehicle identification number in the upper left-hand corner in the Professional Technician System (PTS). To correct this condition, replace rear brake disc (ML14-2A315-BC) and rear brake pads, caliper pin bolts, brake pad clips, and retraction springs (ML3Z-2200-E) on both sides of the vehicle. Refer to Workshop Manual Section 206-04 Rear Disc Brake. For claiming, use causal part number 2552 and applicable labor times from Section 02 of the Service Labor Times Standard Manual. NOTE: Using incorrect service parts on the braking system could impair brake performance.
1 Associated Document
Manufacturer Communications
SSM 51402
2021-2022 F-150 Equipped With Light Duty Electric Park Brake Caliper – Squeal Noise From Rear Brakes When Applied At Low or High Speed
https://www.nhtsa.gov/recalls?nhtsaId=10233651
