NHTSA ID Number: 10226929
Manufacturer Communication Number: TSB 22-2395
Summary
Some 2022-2023 F-150 Lightning vehicles may exhibit a ting, pop or clicking noise from the front or rear wheel hub when accelerating or applying brakes or when shifting between drive/reverse (torque reversals). This condition may be caused by stick/slip between the hub and half shaft interface, during the torque reversals creating the ting/pop or clicking noise. To correct the condition, follow the Service Procedure to install the new anti-ting washer between the wheel hub and axle shaft and reassemble.
Model:
Ford
2022-2023 F-150 Lightning |
Issue: Some 2022-2023 F-150 Lightning vehicles may exhibit a ting, pop or clicking noise from the front or rear wheel hub when accelerating or applying brakes or when shifting between drive/reverse (torque reversals). This condition may be caused by stick/slip between the hub and halfshaft interface, during the torque reversals creating the ting/pop or clicking noise. To correct the condition, follow the Service Procedure to install the new anti-ting washer between the wheel hub and axle shaft.
Action: Follow the Service Procedure to correct the condition on vehicles that meet all of the following criteria:
Parts
Service Part Number | Quantity | Description | Unit of Issue | Piece Quantity |
W707772-S441 | 1 | Wheel Hub Nut | 4 | 2 Per Affected Axle |
W706890-S439 | 2 Per Affected Axle | Wheel Hub Bolt | 4 | 8 Per Affected Axle |
AL1Z-7G273-A | 2 Per Affected Axle | Anti-Ting Washer | 1 | 2 Per Affected Axle |
Parts
Parts To Inspect And Replace Only If Necessary
Service Part Number | Quantity | Description | Unit of Issue | Piece Quantity |
W719687-S439 | 1 | Rear Caliper Bolt | 4 | 4 |
W720613-S439 | 1 | Front Caliper Bolt | 4 | 4 |
Quantity refers to the amount of the service part number required to repair the vehicle.
Unit of Issue refers to the number of individual pieces included in a service part number package.
Piece Quantity refers to the total number of individual pieces required to repair the vehicle.
Service Procedure
1. Drive the vehicle to verify the concern, accelerate/apply brakes or shift from forward to reverse (torque reversals).
2. Does the vehicle exhibit ting, pop or clicking noise from the front or rear?
(1). Yes – add the anti-ting washer to both left and right halfshaft to hub interface for front and/or rear of the vehicle that exhibits the noise. (Figure 1) Refer to the Workshop Manual (WSM) 204-02 Rear Suspension – Wheel Bearing and Wheel Hub > Electric Procedure or WSM 204-01B Front Wheel Bearing and Wheel Hub. Install the anti-ting washer between the wheel hub and axle shaft interface and reassemble.
Figure 1
(2). No – this article does not apply. Refer to the WSM, for normal diagnostics.
3 Affected Products
Vehicles
MAKE | MODEL | YEAR |
FORD | F-150 | 2023 |
FORD | F-150 BEV | 2022 |
FORD | F-150 LIGHTNING | 2022 |
1 Associated Document
Manufacturer Communications
22-2395
28 November 2022
https://www.nhtsa.gov/recalls?nhtsaId=10226929
MC-10226929-0001.pdf 312.765KB
