NHTSA ID Number: 10183414
Manufacturer Communication Number: TSB 20-2370
Summary
Some 2020 F-53 Motorhome Chassis vehicles equipped with a 7.3L engine may exhibit an illuminated malfunction indicator lamp (MIL) with a misfire or lack of power with diagnostic trouble codes (DTC) P0300, P0316, and/or P0301-P0304 built on or before 28-Sep-2020. This may be due to damaged spark plug wire(s). To correct the condition, follow the service procedure to modify the passenger side engine compartment air baffle and replace the engine spark plug wires.
2020 F-53 Motorhome Chassis
Engine: 7.3L
Issue: Some 2020 F-53 Motorhome Chassis vehicles equipped with a 7.3L engine may exhibit an illuminated malfunction indicator lamp (MIL) with a misfire or lack of power with diagnostic trouble codes (DTC) P0300, P0316, and/or P0301-P0304 built on or before 28-Sep-2020. This may be due to damaged spark plug wire(s). To correct the condition, follow the service procedure to modify the passenger side engine compartment air baffle and replace the engine spark plug wires.
Action: Follow the Service Procedure steps to correct the condition on vehicles that meet all of the following criteria:
- 2020 F-53 Motorhome Chassis
- 7.3L engine
- Illuminated MIL with DTCs P0300, P0316, P0301, P0302, P0303 and/or P0304 with a misfire or lack of power
NOTE: Part quantity refers to the number of that service part number required, which may be different than the number of individual pieces. Service part numbers contain 1 piece unless otherwise stated. “As Needed” indicates the part is required but the number may vary or is not a whole number; parts can be billed out as non-whole numbers, including less than 1.
Parts
| Description | Quantity | Part Number | |
| Package Contains 1 Piece, 8 Pieces Required | Ignition Wire | 8 | LC3Z-12286-C |
Service Procedure
1. Locate the passenger side engine compartment baffle. Does the baffle completely cover the area between the radiator assembly and the battery try as shown in Figure 1?
(1). Yes – proceed to Step 2.
(2). No – this article does not apply. Refer to the Powertrain Control Emission Diagnosis Manual (PC/ED) for normal diagnosis.
Figure 1
2. Trim the engine cooling baffle on the passenger side using a suitable cutting tool. (Figures 2-4)
Figure 2
| Item | Description |
| 1 | 297 mm |
| 2 | 295 mm |
Figure 3
Figure 4
3. Replace all 8 spark plug wires on the engine. Refer to the Workshop Manual (WSM), Section 303-07.
2 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
FORD | F-53 | 2020 |
| FORD | F53 | 2020 |
1 Associated Document
Manufacturer Communications
20-2370
09 November 2020
MC-10183414-0001.pdf 445.177KB
