Updated Diagnostic Procedure For The Intergrated Wheel End (IWE) System – 2019-2020 Ford F-150/Expedition & Lincoln Navigator

NHTSA ID Number: 10172986

Manufacturer Communication Number: SSM 48630

Summary

SSM 48630 – 2019-2020 F-150/Expedition/Navigator – Updated Diagnostic Procedure For The Intergrated Wheel End (IWE) System

Some 2019-2020 F-150/Expedition/Navigator four wheel drive vehicles may exhibit a grinding/clicking/ratcheting noise from front axle area in 2H mode under acceleration or heavy loads. The WSM diagnostic routine for the IWE vacuum system has been updated with new leak specifications and a more efficient diagnostic process. Refer to Workshop Manual (WSM), Section 308-07A > Symptom Chart – NVH for the symptom Grinding/clicking/ratcheting noise from front axle in 2H mode under acceleration or heavy loads.

2 Affected Products

Vehicle

FORD

F-150

2019-2020

SSM 48630 – 2019-2020 F-150/Expedition/Navigator – Updated Diagnostic Procedure For The Intergrated Wheel End (IWE) System
