© Copyright 2023 Ford Motor Company
Stacy L. Balzer Ford Motor Company
Operating Director P. O. Box 1904
Service Engineering Operations Dearborn, Michigan 48121 Ford Customer Service Division September 20, 2023
TO: All U.S. Ford and Lincoln Dealers
SUBJECT: Customer Satisfaction Program 23B25 Certain 2022 Model Year Mustang GT 500 and 2023 F-150 Raptor R Vehicles Engine Valve Covers Replacement
PROGRAM TERMS
This program will be in effect through September 30, 2024. There is no mileage limit for this program.
AFFECTED VEHICLES Vehicle Mustang GT 500 F-150 Raptor R Model Year
2022
2023 Assembly Plant
Flat Rock Assembly
Dearborn Build Dates October 21, 2021, through November 9, 2022
April 29, 2022, through March 9, 2023 US population of affected vehicles: 4,240. Affected vehicles are identified in OASIS and FSA VIN Lists.
Note: Some vehicles may be in the process of being repaired at the plant. Monitor OASIS before opening an RO and/or beginning a repair. Parts purchased for an FSA can be returned for credit if required. See the EXCESS STOCK RETURN details in Labor Allowances and Parts Ordering Information for more information.
NOTE: The following Special Service Message (SSM) includes the same component replacements as contained in this FSA:
• SSM 51811
Therefore, 23B25 will be closed automatically when repairs for the SSM are performed.
REASON FOR THIS PROGRAM
Some of the affected vehicles may exhibit an engine valve cover oil leak around the spark plug wells caused by excessive movement of the spark plug seals.
SERVICE ACTION
Dealers are to replace the engine valve covers. This repair must be performed on all affected vehicles at no charge to the vehicle owner.
OWNER NOTIFICATION MAILING SCHEDULE
Owner letters are expected to be mailed the week of October 2, 2023. Dealers should repair any affected vehicles that arrive at their dealerships, whether or not the customer has received a letter. ATTACHMENTS
• Administrative Information
• Labor Allowances and Parts Ordering Information
• Technical Instructions
• Mobile Service Repair Assessment
• Mobile Repair/Vehicle Pickup and Delivery Record
• Owner Notification Letter
QUESTIONS & ASSISTANCE
For questions and assistance, contact the Special Service Support Center (SSSC) via the SSSC Web Contact Site. The SSSC Web Contact Site can be accessed through the Professional Technician System (PTS) website using the SSSC link listed at the bottom of the OASIS VIN report screen or listed under the SSSC tab. Sincerely, Stacy L. Balzer © Copyright 2023 Ford Motor Company Customer Satisfaction Program 23B25
Administrative Information
Page 1 of 3 MOBILE SERVICE REPAIR ASSESSMENT LEVEL
– Not a Mobile Service Repair
OASIS ACTIVATION
OASIS will be activated on September 20, 2023.
FSA VIN LISTS ACTIVATION
FSA VIN Lists will be available through https://web.fsavinlists.dealerconnection.com on September 20, 2023. Owner names and addresses will be available by October 20, 2023.
NOTE: Your FSA VIN Lists may contain owner names and addresses obtained from motor vehicle registration records. The use of such motor vehicle registration data for any purpose other than in connection with this program is a violation of law in several states, provinces, and countries.
Accordingly, you must limit the use of this listing to the follow-up necessary to complete this service action.
SOLD VEHICLES
• Owners of affected vehicles will be directed to dealers for repairs.
• Immediately contact any of your affected customers whose vehicles are not on your VIN list but are identified in OASIS. Give the customer a copy of the Owner Notification Letter (when available) and schedule a service date.
• Correct other affected vehicles identified in OASIS that are brought to your dealership.
• Dealers are to prioritize repairs of customer vehicles over repairs of new and used vehicle inventory.
STOCK VEHICLES
• Correct all affected units in your new vehicle inventory before delivery.
• Use OASIS to identify any affected vehicles in your used vehicle inventory.
BRANDED / SALVAGED TITLE VEHICLES
Affected branded/salvaged title vehicles are eligible for this service action.
OWNER REFUNDS
Refunds are not approved for this program.
RENTAL VEHICLES
Rental vehicles should not be required for this program. If you have a unique owner circumstance or multiple programs, a rental vehicle may be approved. Please contact the SSSC via the SSSC Web Contact Site. © Copyright 2023 Ford Motor Company Customer Satisfaction Program 23B25
Administrative Information
Page 2 of 3 PICK-UP AND DELIVERY- Participating Dealers
Dealers participating in the Remote Experience Program:
• Refer to EFC12071, 2023 Remote Experience Program, Pickup & Delivery (PDL) Offset section for additional details.
PICK-UP AND DELIVERY- Non-participating Dealers
Dealers not participating in the 2023 Remote Experience Program for Pick-up & Delivery are authorized to claim unique services for completing this program.
• Dealers are authorized to claim one-half labor hour per repair for vehicle pick-up & delivery services. Refer to Labor Allowances for details.
• Dealers must retain a Vehicle Pick-up & Delivery Record with the repair order documentation.
ADDITIONAL REPAIR (LABOR TIME AND/OR PARTS)
Additional repairs identified as necessary to complete the FSA should be managed as follows:
• For related damage and access time requirements, refer to the Warranty and Policy Manual / Section 6 – Ford & Lincoln Program Policies / General Information & Special Circumstances for FSAs / Related Damage.
• For vehicles within new vehicle bumper-to-bumper warranty coverage, no SSSC approval is required, although related damage must be on a separate repair line with the “Related Damage” radio button checked.
o Ford vehicles – 3 years or 36,000 miles
• For vehicles outside new vehicle bumper-to-bumper warranty coverage, submit an Approval Request to the SSSC Web Contact Site before completing the repair.
CLAIMS PREPARATION AND SUBMISSION
• Claim Entry: Enter claims using Dealer Management System (DMS) or One Warranty Solution (OWS) online.
o When entering claims:
▪ Claim type 31: Field Service Action
▪ Sub Code: 23B25
▪ Customer Concern Code (CCC): L65 Engine Leaks Oil
▪ Condition Code (CC): D8 Failed Gasket/Seal
▪ Causal Part Number: 6582, Quantity 0
o For additional claims preparation and submission information, refer to the Recall and Customer Satisfaction Program (CSP) Repairs in the OWS User Guide. © Copyright 2023 Ford Motor Company Customer Satisfaction Program 23B25
Administrative Information
Page 3 of 3 • Related Damage/Additional labor and/or parts: Must be claimed as Related Damage on a separate repair line from the FSA with the same claim type and subcode as described in the Claim Entry above.
IMPORTANT: Click the Related Damage Indicator radio button.
• Pickup & Delivery:
o Dealers participating in the Remote Experience Program –
▪ Refer to EFC12071, 2023 Remote Experience Program, Pickup & Delivery (PDL) Offset section for additional details.
o Dealers NOT participating in the Remote Experience Program –
▪ Dealers are authorized to claim one-half labor hour per repair for vehicle pick- up and delivery services.
▪ Dealers must retain a Vehicle Pick-up and Delivery Record with the repair order documentation.
• Additional parts not listed in the parts section: Additional parts such as RTV sealant may be submitted on the same repair line on which the FSA is claimed.
o Program Code: 23B25
o Misc. Expense: OTHER
o Misc. Expense: Claim up to $25 © Copyright 2023 Ford Motor Company Labor Allowances and Parts Ordering Information
Page 1 of 2 Customer Satisfaction Program 23B25 LABOR ALLOWANCES
Description Labor Operation Labor Time
Replace both engine valve covers – F-150 Raptor R 23B25B 1.6 Hours Replace both engine valve covers – Mustang GT 500 without Track Pack 23B25C 3.5 Hours Replace both engine valve covers – Mustang GT 500 with Track Pack 23B25D 3.8 Hours Vehicle Pick-up and Delivery Allowance:
This allowance is only for non-eligible 2023 Remote Experience Program Dealers.
NOTE: This allowance is for dealer-performed vehicle pick- up/delivery for dealership repairs only. Can only be claimed once, regardless of outstanding FSAs repaired.
PARTS REQUIREMENTS / ORDERING INFORMATION Part Number Description 23B25PP Order 0.5 Hours Claim KR3Z-6582-G KR3Z-6582-E NR7Z-6758-A Valve Cover – RH Valve Cover – LH
PCV Hose – F-150 Raptor R only Quantity
1
1
1 Quantity
1
1
1 Order your parts requirements through normal order processing channels. To guarantee the shortest delivery time, an emergency order for parts must be placed.
DEALER PRICE
For the latest prices, refer to DOES II. © Copyright 2023 Ford Motor Company Labor Allowances and Parts Ordering Information
Page 2 of 2 Customer Satisfaction Program 23B25 PARTS RETENTION, RETURN, & SCRAPPING
Follow the provisions of the Warranty and Policy Manual, Section 1 – WARRANTY PARTS RETENTION AND RETURN POLICIES. If a replaced part receives a scrap disposition, the part must be scrapped by all applicable local, state, and federal environmental protection and hazardous material regulations. Federal law prohibits selling motor vehicle parts or components that are under safety, compliance, or emissions recall.
EXCESS STOCK RETURN
The excess stock returned for credit must have been purchased from the Ford Customer Service Division by Policy Procedure Bulletin 4000.
REPLACED FSA PARTS INSPECTION AND SIGN OFF
Effective March 1ˢᵗ, 2021, all parts replaced as part of an FSA repair with a repair order open date of March 1ˢᵗ, 2021, or later must be inspected and signed off on the repair order by a member of your dealer’s fixed operations management team or an employee the task has been delegated to. If the task is to be delegated to a non-management employee, the employee needs to be someone other than the technician who completed the repair and needs to understand the importance of completing this task consistently and accurately.
• All parts replaced as part of an FSA repair should be returned to the parts department following the Warranty Parts Retention and Return Policies.
• Inspect the replaced parts to verify the FSA repair was completed.
• If the FSA repair is found to be complete, the designated employee signs the repair order line or parts return stamp area (electronic or hand-signed) for the FSA repair indicating the parts were inspected and validated to have been replaced.
• After the parts have been inspected, they should be handled based on the guidance in the parts status report in the Online Warranty System (Hold, Return, CORE, Scrap, etc.). Please visit FMCDEALER > PARTS & SERVICE > WARRANTY ADMINISTRATION & WARRANTY PARTS RETURN for the latest Immediate Scrap List information.
• This process is subject to review during warranty audits for FSA repairs with a repair order open date of March 1ˢᵗ, 2021, or later. Any eligible FSA claims requiring parts replacement found not to have been inspected and signed off during a warranty audit will be subject to chargeback and consideration for enrollment into the Dealer Incomplete Recall Repair Process.
Note: Other approvals (electronic or handwritten) for add-on repair lines, dealer-owned vehicle repairs, and repeat repairs do not qualify as FSA parts inspection approvals. The post-repair FSA parts inspection process (electronic or handwritten) is independent of other warranty approval requirements. The approval by the designated employee implies that the FSA parts were found to be replaced and must be able to be identified on the Repair Order. If multiple FSAs require approval on a single Repair Order, each applicable occurrence will require individual post-repair approval by the designated employee. © Copyright 2023 Ford Motor Company Mobile or Pick-Up and Delivery Repair Record
Page 1 of 1 23B25 MOBILE REPAIR / VEHICLE PICK-UP AND DELIVERY RECORD VIN received (check one):
☐ Mobile Repair
☐ Pick-up and/or delivery service
As outlined below for the 23B25 Field Service Action program. ☐ Mobile Repair – Date: OR
☐ Pick-up – Date: ☐ Delivery – Date: Repair Order # Repair Order Date Service Manager Signature Date Mobile Service Repair Assessment
Page 1 of 2 Customer Satisfaction Program 23B25 Mobile Service Repair Assessment Assessment levels have been identified to help determine the ease of performing eligible mobile service repairs for a Field Service Action (FSA) outside of the dealership service facility. Dealer Bulletin
Within Attachment I of the dealer bulletin a mobile service repair assessment level(s) will be provided. These assessment levels have been determined using the amount of time, equipment and labor identified to perform the intended service action. Assessment Levels
– Mobile Reprogramming
– Light Mobile Service
– Enhanced Mobile Service
– Advanced Mobile Service
– Wheel and Tire Mobile Service
– Not a Mobile Service Repair Description of each level that is used to determine the overall assessment.
– Mobile Reprogramming
• Module Programming or similar type services
• Minimum tools maybe required other than an IDS/FDRS setup
• FDRS programming that requires internet connection (wi-fi or mobile hotspot)
• Make sure vehicle has a charge port to ensure battery voltage is maintained during flashing of the module(s)
• Repairs not greater than 1 hour in length (including time to wait for programming)
Note: The location will need a charging station or wall box to maintain the 12-volt battery. – Light Mobile Service
• Interior repair procedures that do not require seat, dash, or headliner removal
• Under hood repairs that do not require large component removal
• Exterior repairs that do not require large component/panel removal
• Repairs may require standard hand tools (Access to a Technician starter kit or similar) Mobile Service Repair Assessment
Page 2 of 2 Customer Satisfaction Program 23B25 – Enhanced Mobile Service
• A two-person process is required anytime a procedure requires work under the vehicle
• Brake Inspection and Brake Repair/Replacement
• Limited Suspension Component replacement (no alignment)
• Under Vehicle access for limited repairs (no large component removal)
• Vehicle Check Up – VCU
• Pre-Delivery Inspection – PDI
• Used Car Inspection/Presale Inspection
• May require floor jack, jack stands, and impact tools
Note: Wheel lock may be required. – Advanced Mobile Service
• Fluid Exchange/Oil Change
• Light Repairs
• Brake Hydraulic Repairs – Wheel and Tire Mobile Service
• Tire Removal from Wheel
• Tire Balancing
• Tire Repair
Note: Specialized Mobile Service unit and equipment including Tire balancer and Tire Changer required. – Not a Mobile Service Repair
• Large component removal
• BEV Battery Replacement
• Requires a vehicle hoist – to complete the repair (more than inspection)
• Required vehicle alignment
• Requires significant vehicle disassembly
• Repairs greater than 2-3 hours
• Any repairs that require M-Time
• Includes a service procedure where the vehicle owner may be distressed about the state of their vehicle ECHNICAL INSTRUCTIONS
AGE 1 OF 1 CUSTOMER SATISFACTION PROGRAM 23B25
CPR © 2023 FORD MOTOR COMPANY DEARBORN, MICHIGAN 48121
09/2023
CERTAIN 2023 MODEL YEAR F-150 RAPTOR R AND 2022 MODEL YEAR
MUSTANG GT 500 VEHICLES — ENGINE VALVE COVERS REPLACEMENT SERVICE PROCEDURE
NOTICE: During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces, that enters the oil passages, coolant passages or the oil pan, can cause engine failure. 1. Remove and replace the Valve Cover Left Hand (LH) and the Valve Cover Right Hand (RH). Follow Workshop Manual (WSM) Proceudres in Section 303-01F (Raptor R) or 303-01C (Mustang GT 500). IMPORTANT NOTE: Federal law prohibits selling motor vehicle parts or components that are under safety, compliance, or emissions recall. Unless a part is requested to be returned to Ford, all parts replaced under this FSA must be scrapped in accordance with all applicable local, state and federal environmental protection and hazardous material regulations. Refer to the Parts Retention,
Return, & Scrapping section of the FSA dealer bulletin for further information

**************************************************************************************************************

**************************************************************************************************************
