NHTSA ID Number: 10054992
Manufacturer Communication Number: TSB-14-0013
Summary
FORD: SOME VEHICLES MAY HAVE A BROKEN LATCH OR THE LATCH HOUSING IS CRACKED. MODEL 2013 C-MAX, 2013-2014 ESCAPE. *PE
4 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| FORD | C-MAX ENERGI | 2013 |
| FORD | C-MAX HYBRID | 2013 |
| FORD | ESCAPE | 2013-2014 |
FORD:
2013 C-MAX
FORD:
2013-2014 Escape
ISSUE:
Some 2013-2014 Escape built on or before 11/4/2013 and 2013 C-MAX vehicles built on or before 11/5/2013 may exhibit a broken center console latch or latch housing cracked.
ACTION:
Follow the Service Procedure Steps to correct the condition.
SERVICE PROCEDURE
- Remove the armrest lid inner liner with a plastic trim tool. Start at the top of the lid and work down each side. (Figures 1-3)
Figure 1 – 14-0013
- Save the spring loaded latch handle and rod assembly. (Figure 4)
Figure 2 – 14-0013
- Remove the latch housing from the armrest. (Figure 5)
Figure 3 – 14-0013
- Install the new latch housing. Torque the 3 fasteners to 1.9 Nm +/- 0.3 Nm (16.8 lb-in +/- 2.7 lb-in).
- Snap in the new armrest lid inner liner. (Figure 6)
Figure 4 – 14-0013
- If the spring and rod assembly were loose from the handle assembly, install the spring into the handle slots on both sides and slide the rod through. (Figures 7 and 8)
Figure 5 – 14-0013
- Install the spring loaded latch handle into the latch housing. (Figures 9 and 10)
Figure 6 – 14-0013
| PART NUMBER | PART NAME |
| CJ5Z-7806162-A | Latch Housing |
| CJ5Z-7804610-AA | Lid Inner Liner |
1 Associated Document
Service Bulletin Document
TSB-14-0013
https://www.nhtsa.gov/recalls?nhtsaId=10054992
